SETPTS Menu
Parameter Choices
Level 2 submenus
SETPT1–SETPT8 OFF
GROSSSP
NETSP
+RELSP
–RELSP
%RELSP
PAUSE
DELAY
WAITSS
COUNTER
AUTOJOG
COZ
INMOTON
INRANGE
–GROSS
–NET
BATCHPR
TIMER
CONCUR
BATCHNG OFF
AUTO
MANUAL
NOTE: See Section 12.0 on page 59 for detailed information on setpoints.
Specifies the setpoint kind.
GROSSSP, NETSP, +RELSP, –RELSP, and %RELSP setpoint kinds can be used as
either batch or continuous setpoints.
PAUSE, DELAY, WAITSS, COUNTER, and AUTOJOG setpoint kinds can only be
used in batch sequences.
COZ, INMOTON, INRANGE, –GROSS, –NET, BATCHPR, TIMER, and CONCUR
setpoint kinds can only be used as continuous setpoints.
See Table 12-1 on page 60 for more information about setpoint kinds.
Batching enable. Set to AUTO or MANUAL to allow a batch sequence to run.
MANUAL requires a BATSTRT digital input, BATSTART EDP command before the
batch sequence can run. AUTO allows batch sequences to repeat continuously.
Table 3-7. Setpoint Menu Parameters
Description
