Texecom Mirage DT Petwise Installation Instructions

P e t I m m u n e D u a l Te c h n o l o g y D e t e c t o r
I N S TA L L AT I O N I N S T R U C T I O N S
Best
Manufacturer
ESIIA
1999 & 2000
GOLD
AWARD
EUROPEAN SECURITY
INDUSTRY INNOVATION
AWARDS
T H A N K Y O U F O R V O T I N G T E X E C O M
Ask your distributor today for the new Texecom full colour Product Guide.
QUALITY ASSURANCE
C e r t i f i c a t e N u m b e r : F M 3 5 2 8 5

WARRANTY

5 year replacement warranty.
The Mirage DT Petwise is designed to detect the movement of an intruder
and activate an alarm control panel. As the Mirage DT Petwise is not a complete
alarm system, but only a part thereof, Texecom cannot accept responsibility or
liability for any damages whatsoever based on a claim that the Mirage DT Petwise
failed to function correctly.
Due to our policy of continuous improvement Texecom reserves the right
to change specification without prior notice. All specifications are measured at
20˚C (68˚F).
Document Ref: MDTPet/EU/1.0-3
© 1994 - 2005 Texecom Ltd
6

COVERAGE PATTERNS

104°
-9m -8m -6m -4m -2m 0m 2m 4m 6m 8m
-29'6" -26'2" -19'8" -13'1" -6'7" 0'0" 6'7" 13'1" 19'8" 26'2"
0m 2m 4m 6m 8m 10m
0'0" 6'7" 13'1" 19'8" 26'2" 32'9"
2m
6'7"
0m
0'0"
1

PHYSICAL

116mm
(4.6")
41mm
66mm
(1.6")
(2.6")
4
A B C D E F G H
TAMP ALARM 12V 0V LA RL
IMPORTANT
Ensure Microwave Range is set at correct level for
desired coverage
JP1
MIN MAX
MIN
JP1
MIN MAX
JP1
MIN MAX
MAX
7 MOUNTING HEIGHT AND
SETTINGS
12m
40'0"
10m
32'9"
8m
3.1m
26'2" (10'0")
6m
19'8"
2.5m
4m (8'4")
13'1"
2m
6'7" 2.0m
(6'7")
9m
29'6"
OPTIMUM
12m
HEIGHT
40'0"
DO NOT USE POSITIONS 3 & 4
2

ENVIRONMENTAL

-35°C (-31°F) to +60°C (+140°F)
2.5mm (0.1") ABS
-10°C (14°F) to +55°C (+131°F)
MW ALARM PIR
2
MIN MAX
1
8 ENSURE PCB IS AT THE CORRECT
POSITION
( FOR CHOSEN MOUNTING HEIGHT )
0m 2m
0'0" 6'7" 13'1"
2m
6'7"
0m
0'0"
0m 2m
13'1"
0'0" 6'7"
}
2m
6'7"
0m
0'0"
0m 2m
0'0" 6'7" 13'1"
2m
6'7"
0m
0'0"
0m 2m
0'0" 6'7" 13'1"
2m
6'7"
0m
0'0"
DO NOT USE POSITIONS 3 & 4
3 STANDARDS & APPROVALS
System Standard:
EMC:
RF Immunity:
190g (7oz) approx.
Electrostatic Discharge:
Fast Transient Immunity: No false alarm up to ±4kV.
High Energy Transient
Immunity:
Conducted RF Susceptibility: No false alarm at 10Vrms.
Conducted Emissions:
Radiated Emissions:
Microwave Range:
Type Approvals:
5 REMOTE LED & LATCH INPUT
FUNCTIONS
The latch terminal (see Section 4) can perform several different functions
depending on how it is connected:
LED OFF
Latch connected to Set Positive (SW+, Set+): The LEDs will be disabled while
the system is set. Any detectors triggered while the system is set will indicate
this by permanently lighting the Alarm LED (upon unsetting the system).
Detectors can be reset by taking the latch line high and then low again.
LED ON
Latch connected to Alarm Positive (AL+, A+ve): The first detector activated
while the system is set will indicate this with a slowly flashing Alarm LED
PULSE COUNT
(upon unsetting the system). Detectors which activated subsequently will
indicate this by permanently lighting the Alarm LED. Detectors can be
reset by taking the latch line high and then low again.
The latch input is not suitable for use on entry/exit or walk through zones.
Remote LED: Connect RL to12V to disable the walk test LEDs.
0.3 - 3.0m/s
Connect RL to 0V or leave unconnected to enable the walk test LEDs.
1 - 10ft/s
9

BEWARE OF OBSTRUCTIONS

4m 6m 8m 10m 12m
19'8" 26'2" 32'9" 40'0"
4m 6m 8m 10m 12m
19'8" 26'2" 32'9" 40'0"
4m
6m 8m 10m 12m
19'8" 26'2" 32'9" 40'0"
4m 6m 8m 10m 12m
19'8" 26'2" 32'9" 40'0"
Suggested use: within a BS EN 50131-1 Grade 2 system.
Environmental Class II.
Independently certified to EN 50130-4 : 1996.
No false alarm from 80MHz to 1GHz at 50V/m modulated,
equivalent to a 700W uniform transmittor at 3m (10ft).
Complies with BS EN 61000-4-3 : 1997.
No false alarm up to 8kV
Complies with BS EN 61000-4-2 : 1995.
Complies with BS EN 61000-4-4 : 1995.
No false alarm up to ±2kV.
Complies with BS EN 61000-4-5 : 1995.
Complies with BS EN 61000-4-6 : 1995.
Complies with EN 55022 Class B.
Complies with EN 55022 Class B.
Internal pot to adjust.
Complies with: MPT 1349, I-ETS 300 440, FCC Part 15.
