M6 X 20
SCREW X6
VISOR
VISOR CLAMP X6
CAP WITH NO LOCK
CAP WITH LOCK
WING KNOB X8
STRAP X4
MOUNTING PAD X4
U BOLT X4
CONNECTOR PLATE
X8
M6 X 55
SCREW X 8
M6 FLAT WASHER
X16
M6 LOCK NUT
X8
BASKET - FRONT HALF
CAP WITH NO LOCK
CAP WITH LOCK
VEHICLE ROOF BAR
BASKET - REAR HALF
ASSEMBLED BASKET
VEHICLE ROOF BAR
ORIENT KNOB WINGS
AS SHOWN BEFORE
INSTALLING CAP
Advertisement
Related Manuals for Kuat VAGABOND-X
Summary of Contents for Kuat VAGABOND-X
- Page 1 CONNECTOR PLATE M6 X 20 SCREW X6 M6 FLAT WASHER M6 X 55 SCREW X 8 BASKET - REAR HALF M6 LOCK NUT VISOR VISOR CLAMP X6 BASKET - FRONT HALF CAP WITH NO LOCK CAP WITH NO LOCK CAP WITH LOCK CAP WITH LOCK WING KNOB X8 ASSEMBLED BASKET...
