Summary of Contents for Chiayo APEX PRO

Page 1: Operation Manual
APEX PRO Operation manual Multifunctional Wireless Mixer Amplifier CHIAYO ELECTRONICS CO.,LTD.
Page 2 APEX PRO Multifunctional Wireless Mixer Amplifier Please read and follow the instructions in this manual thoroughly to obtain optimum results from this unit. We also recommend that you keep this manual handy for future reference. Safety Precautions  Be sure to read the instructions in this section carefully before use.
Page 3 The Modules Compartment can be user configurable and user can access the battery compartment to change battery. Without the CD/Bluetooth-MP3 player, APEX PRO can be configured with up to 6 modules, among which one can be repeater transmitter/MP3/Bluetooth module. However, when CD/Bluetooth-MP3 module is installed, only 4 module slots will be available.
Page 4 APEX PRO Multifunctional Wireless Mixer Amplifier Parts and functions ① 1. Microphone/Line volume control 11. Line in socket (3.5mm) ① 2. MIC/LINE level switch 12. Line in socket (combo) ① 13. Tone control (Treble) 3. Microphone/Line input ② 14. Tone control (Middle) 4.
Page 5 Instructions Using the wired microphone Plug a wired microphone with a 6.3mm or XLR connector to MIC 1 or MIC 2. Switch MIC/LINE level to MIC position. Turn on master POWER and then adjust its individual volume control to a desired level. Bass/Middle/Treble tone and reverb levels can be adjusted by individual controls.
Page 6 APEX PRO Multifunctional Wireless Mixer Amplifier Using the electronic instrument (1) Plug an electronic guitar / keyboard with a 6.3mm or XLR connector to MIC 1 or MIC 2. Switch MIC/LINE level to LINE position. Turn on master POWER and then adjust its individual volume control to a desired level..
Page 7 Instructions Using the electronic instrument (2) Plug an electronic guitar / keyboard with a 6.3mm or XLR connector to the COMBO jack of LINE IN. Turn on master POWER and then adjust its individual volume control to a desired level. Bass/Middle/Treble tone levels can be adjusted by individual controls.
Page 8 APEX PRO Multifunctional Wireless Mixer Amplifier Music audio input- MP3/MP4/DVD player Plug the audio cable a 3.5mm phone plug to the 3.5mm jack of LINE IN. Turn on master POWER and then adjust its individual volume control to a desired level.
Page 9 Instructions Music audio input- Computer/notebook Use a USB cable to connect the unit and your PC/Notebook to make APEX PRO the speaker of your device Turn on master POWER and then adjust master volume control to a desired level.. Bass/Middle/Treble tone levels can be adjusted by individual controls.
Page 10 GREEN Activate Bluetooth on your device (phone, tablet, PC..,etc) and pair with external Bluetooth device named “APEX PRO”. After successful linking, you will hear “PAIR COMPLETED. DEVICE CONNECTED” and the pairing indicator will glow green and you can play your music on APEX PRO.
Page 11 Instructions Tone control For wired/wireless microphone(s) and music Operating Voice Priority Voice Priority operation is only necessary when CD/USB/MP3 is playing. When the Voice Priority switch is ON, the ducking function will be activated. While the music is playing, a voice input from either a Wired or Wireless Microphone will temporarily override and lower the volume of the background music and voice could be heard more clearly.
Page 12 APEX PRO could be operated as the MASTER unit in an audio link (wired) configuration. Connect the ACTIVE OUT of the first APEX PRO to the 6.3mm LINE IN of another APEX PRO. The second APEX PRO could be connected to the 6.3mm LINE IN of the third APEX PRO and so forth.
Page 13 Instructions Connecting an external speaker Plug the external speaker’s audio cable with a 6.3mm connector to the speaker input socket of APEX SP or an 4~8Ω load speaker Turn on master POWER and then adjust its individual volume control to a desired level. Bass/Middle/Treble tone levels can be adjusted by individual controls.
Page 14 APEX PRO Multifunctional Wireless Mixer Amplifier Operation of the storage for transmitters and accessories Open the lid. Be careful of the gap between the trolley handle and the lid. Slots ① ④ for handheld transmitters. Slot ⑤ for switching power supply. Slots ⑥...
Page 15 Instructions Maintenance-free Lead Acid battery Guidelines for maintenance-free Batteries: 1. Battery should operate at temperatures between 15°C ~ 50°C. To ensure a longer life span, it should be kept between 5°C ~ 35°C. For optimum result, 20°C ~ 25°C will be ideal. When temperature falls 15 degrees below zero, battery will undergo some changes in its chemical contents and therefore cannot be recharged.
Page 16 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw｜Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan｜Tel: 886-2-27415741｜Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan｜Tel: 886-5-2711000｜Fax: 886-5-5767611...
