FOCUS PRO/500/505

Operation manual

Multifunctional Wireless Amplifier
CHIAYO ELECTRONICS CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Focus 500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chiayo Focus 500

  • Page 1: Operation Manual

    FOCUS PRO/500/505 Operation manual Multifunctional Wireless Amplifier CHIAYO ELECTRONICS CO.,LTD.
  • Page 2 FOCUS PRO/505/500 Multifunctional Wireless Amplifier Please read and follow the instructions in this manual thoroughly to obtain optimum results from this unit. We also recommend that you keep this manual handy for future reference. Safety Precautions  Be sure to read the instructions in this section carefully before use. ...
  • Page 3 Instructions Congratulations and thank you for purchasing this multi-functional wireless portable amplifier. To ensure a trouble-free operation, please read the manual thoroughly to fully understand its controls and functions. The rear panel of this portable amplifier is divided into 3 sections: 1.
  • Page 4 While charging, the unit could also be operated simultaneously. The battery types of FOCUS series are listed below: Model FOCUS PRO FOCUS 500/505 Battery type LI-ION LEAD-ACID Specs 16.8V 5.2A...
  • Page 5 Instructions Using the wired microphone Plug a wired microphone with a 6.3mm plug to MIC IN. Turn on master POWER and then adjust its individual volume control to a desired level. Bass/Treble tone levels can be individually adjusted. TONE control...
  • Page 6 FOCUS PRO/505/500 Multifunctional Wireless Amplifier Using the electronic instrument Plug an electronic guitar or keyboard with a 6.3mm plug to AUX IN. Turn on master POWER and then adjust its individual volume control to a desired level. Bass/Treble tone levels can be individually adjusted. TONE control...
  • Page 7 Instructions Connecting an external speaker Plug the external speaker’s audio cable with a 6.3mm connector to the EXT SPAR socket. Bass/Treble tone levels can be individually adjusted. TONE control Tone control For all audio Operating Voice Priority Voice Priority operation is only necessary when CD/USB/MP3 is playing. When the Voice Priority switch is ON, the ducking function will be activated.
  • Page 8 6. Warranty will be void if the battery is not charged for a prolong period as it may lose all its charge and could never be recovered again. CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw|Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan|Tel: 886-2-27415741|Fax: 886-2-27525242...
