- Page 1 Viega Eco Plus washbasin element Instructions for Use for WB with single-hole fitting Model Year built: 8164 from 01/2010 en_INT...
- Page 2 Viega Eco Plus washbasin element 2 from 14...
-
Page 3: Table Of Contents
Product description 2.3.1 Overview 2.3.2 Compatible components 2.3.3 Sound protection 2.3.4 Technical data Accessories Handling Assembly information 3.1.1 Mounting conditions 3.1.2 Installation dimensions 3.1.3 Required tools Assembly 3.2.1 Mounting the element Disposal Viega Eco Plus washbasin element 3 from 14... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
German/European directives specified in this manual: The information herein is not binding for other countries and regions; as said above, they should be understood as a recommendation. Viega Eco Plus washbasin element 5 from 14... -
Page 6: Product Information
Intended use 2.2.1 Areas of use The Viega Eco Plus washbasin element is suitable for mounting on masonry wall constructions and support profiles pursuant to the regula- Ä „Regulations from section: Fields of application / tions in section Mounting conditions“ on page 6 . -
Page 7: Product Description
Product information Product description 2.3.1 Overview Fig. 1: Components and scope of delivery 1 - Viega Eco Plus element 2 - washbasin module 3 - threaded bolt 4 - mounting bracket for drain elbow 5 - connections for wall plates... -
Page 8: Technical Data
With a desired installation depth of 75 mm (see dimension * in dimen- Ä Chapter 3.1.2 „Installation dimensions“ on page 9 ), sional drawing you will require the drain elbow model 8113.21. Viega Eco Plus washbasin element 8 from 14... -
Page 9: Handling
With the construction height, the marked height of the upper edge of the finished floor must be observed. 3.1.2 Installation dimensions Fig. 2: Dimensions The installation depth is achieved with drain elbow model 8113.21 Viega Eco Plus washbasin element 9 from 14... -
Page 10: Required Tools
X2: 440 mm (model 8173) X3 = mounting height 1110 mm or 960 mm Ø10 0 - 2 0 Drill holes. Mount the fixing set with the fork spanner (size 13). 560638_B2 Viega Eco Plus washbasin element 10 from 14... - Page 11 (size 17). 0 - 2 0 0 Remove WC element and drill floor holes. Ø10 Attach element to the floor using the fork spanner (size 13) and the screws and dowels supplied. Viega Eco Plus washbasin element 11 from 14...
- Page 12 Mounting in on-site support profile The element can be inserted into the 50 mm and 75 mm support pro- files. Determine the fixing points. Align element. Mount drain elbow and threaded bolts. Viega Eco Plus washbasin element 12 from 14...
- Page 13 There are only limited possibilities available to remedy errors made during this assembly step, Ä „Construction height“ on page 9 . 0 - 2 0 0 Screw element together laterally with the support profiles. Viega Eco Plus washbasin element 13 from 14...
-
Page 14: Disposal
Make water connections. Double-clad element (2 x 12.5 mm). Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Viega Eco Plus washbasin element 14 from 14...
