- Page 1 Instructions for Use Pressgun 6B press machine with mains connection for all Viega system press jaws, rings, chains and (hinged) adapter jaws with PT2 interface Model 2295.5...
-
Page 2: Table Of Contents
3.3 Carrying out the pressing process 3.4 Aborting the pressing process 3.5 Care and maintenance 3.5.1 Cleaning the press tools 3.5.2 Performing checks 3.6 Disposal Appendix 4.1 Warranty 4.2 EC Declaration of Conformity 4.3 Service partners Pressgun 6B press machine with mains connection... -
Page 3: About These Instructions For Use
This symbol warns of possible life-threatening injury. WARNING! This symbol warns of possible serious injury. CAUTION! This symbol warns of possible injury. NOTICE! This symbol warns of possible damage to property. This symbol gives additional information and hints. Pressgun 6B press machine with mains connection... -
Page 4: About This Translated Version
The information about the products, their properties and application technology are based on the current standards in Europe (e.g. EN) and/or in Germany (e.g. DIN/DVGW). Pressgun 6B press machine with mains connection... -
Page 5: Note On Use Of Abbreviated Terms
Viega system press tool Press tool Combinations of for example: Press machine and press jaws Press machine with hinged adapter jaws and press ring or press chain Press machine and press-in attachment tool Pressgun 6B press machine with mains connection... -
Page 6: Product Information
Power tools create sparks which may ignite the dust or fumes. c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Pressgun 6B press machine with mains connection... - Page 7 Loose clothes, jewellery or long hair can be caught in moving parts. g) lf devices are provided for the connection of dust extraction and col‐ lection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. Pressgun 6B press machine with mains connection...
- Page 8 This will ensure that the safety of the power tool is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers. Pressgun 6B press machine with mains connection...
-
Page 9: Intended Use
The Viega system press machine Pressgun 6B is intended for pressing press connectors into the respective piping systems. In combination with Viega system press jaws, chains or rings, the press tool is suitable for use with all Viega plumbing and heating installation systems up to and including dimension 108, as well as Megapress press connectors in dimensions ⅜... - Page 10 Retaining bolt Retaining bolt lever Start button Reset button Gripping surfaces on the press machine ▶ To avoid injuries during pressing, hold the press machine in both hands as shown in the picture. Pressgun 6B press machine with mains connection...
-
Page 11: Technical Data
Oscillation level < 2.5 m/s Power transmission hydraulic Thrust on piston 32 kN Switch-on duration Maximum three pressings per minute Permitted continuous operation ≤ 30 min measurement uncertainty 3 dB(A) measurement uncertainty 1.5 m/s Pressgun 6B press machine with mains connection... -
Page 12: Operating Mode
2.4.3 Operating mode The Viega Pressgun 6B is an electro-hydraulically operated press machine. Pressing the start button and keeping it pressed triggers pressing. The hydraulically operated roller head moves forwards into the press jaw and closes it with a power of 32 kN. - Page 13 ‘Aborting the pressing process’ on page 17. Rotatable cylinder head The press jaw fixture in the front part of the cylinder head is 180° rotat‐ able to allow for flexible alignment of the press jaws to the pressing point. Pressgun 6B press machine with mains connection...
-
Page 14: Handling
Risk of device damage due to failure to fully lock the retaining bolt! If the retaining bolt is not fully inserted and locked, the cylinder may tear during pressing. Ensure that the retaining bolt is locked before starting pressing. Pressgun 6B press machine with mains connection... - Page 15 ▶ Slide the retaining bolt in as far as it will go and turn the retaining bolt lever by 180° to return it to its snap-in position. Pressgun 6B press machine with mains connection...
-
Page 16: Carrying Out The Pressing Process
Ensure that there is enough space on the press point. Keep the press jaw contour and the area around the press point free from dirt and any objects that could hinder complete pressing. Pressgun 6B press machine with mains connection... -
Page 17: Aborting The Pressing Process
Aborting the pressing process When the roller head has not touched the press jaw yet and the press machine has not yet built up any pressing force: ▶ Release the Start button to interrupt the pressing. Pressgun 6B press machine with mains connection... -
Page 18: Care And Maintenance
The tools are subject to normal wear and tear; for this reason, they must be maintained in regular intervals. The maintenance and servicing of the tools must be carried out by service partners authorised by Viega. Maintenance interval The next maintenance date is indicated on the press machine. Have the machine maintained at least every two years. -
Page 19: Performing Checks
Do not dispose of the press machine in household waste and do not scrap it. For environmentally compatible disposal, send the press machine to your local service partner or pass it to a recycling company. Pressgun 6B press machine with mains connection... -
Page 20: Appendix
Appendix Appendix Warranty The warranty period for the Viega system tools, such as press machines, press jaws, press rings, Steptech punches, pipe cutters, cali‐ brators etc. is in accordance with national statutory provisions appli‐ cable in the country where your headquarters is based. However, it is at least two years from the date of purchase and transfer of risk. -
Page 21: Ec Declaration Of Conformity
Appendix EC Declaration of Conformity Fig. 3: EC Declaration of Conformity Pressgun 6B Service partners For maintenance and repair of the press tools, contact the service partner in your country. Pressgun 6B press machine with mains connection... - Page 22 102 Kleisthenous & Papafiessa Str, 153 44 Athens A.E.T.E. +30 (210) 604945 4 / astathis@ergon.com.gr Elmes KG Via Artigianale Nord, 6, 39044 Neumarkt +39 (0471) 813399 / info@elmes.it O.R.E. s.r.l. Via Sassonia, 16/G, 47900 Rimini +39 (0541) 741003 / info@oreutensili.com Pressgun 6B press machine with mains connection...
- Page 23 Unit K, Ashley Drive Bothwell, G71 8BS Glasgow Depot 190 +44 (1698) 740047 / angela.hepburn@vpplc.com Broughton Plant Hire Unit 10, Trade City, Ashton Road, RM3 8UJ Romford, Essex +44 (1708) 383350 / steve@mbroughtonltd.co.uk Pressgun 6B press machine with mains connection...
- Page 24 Viega Supply Chain GmbH & Co. KG service-technik@viega.de viega.com INT • 2020-10 • VPN180427...
