- Page 1 Instructions for Use Pressgun Picco 6 press machine with battery for all Viega system press jaws, rings and hinged adapter jaws with Picco interface Model 2489.3...
-
Page 2: Table Of Contents
3.4 Aborting the pressing process 3.5 Troubleshooting 3.6 Care and maintenance 3.6.1 Cleaning the press tools 3.6.2 Performing checks 3.6.3 Inspection and maintenance 3.7 Disposal Appendix 4.1 Warranty 4.2 EC Declaration of Conformity 4.3 Service partners Pressgun Picco 6 press machine with battery... -
Page 3: About These Instructions For Use
This symbol warns of possible life-threatening injury. WARNING! This symbol warns of possible serious injury. CAUTION! This symbol warns of possible injury. NOTICE! This symbol warns of possible damage to property. This symbol gives additional information and hints. Pressgun Picco 6 press machine with battery... - Page 4 The marked product must not be disposed of as household waste. Recyclable rechargeable lithium ion batteries, see Ä Chapter 3.7 ‘Disposal’ on page 25 CE marking: Product safety in Europe Direct voltage V d.c. Pressgun Picco 6 press machine with battery...
-
Page 5: About This Translated Version
Viega system press tool Press tool Combinations of for example: Press machine and press jaws Press machine with hinged adapter jaws and press ring Term Abbreviated form Lithium ion rechargeable battery Rechargeable battery Battery charger Charger Pressgun Picco 6 press machine with battery... -
Page 6: Product Information
Power tools create sparks which may ignite the dust or fumes. c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Pressgun Picco 6 press machine with battery... - Page 7 Loose clothes, jewellery or long hair can be caught in moving parts. g) lf devices are provided for the connection of dust extraction and col‐ lection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. Pressgun Picco 6 press machine with battery...
- Page 8 Shorting the battery terminals together may cause burns or a fire. Pressgun Picco 6 press machine with battery...
- Page 9 There is a danger of crushing the Fingers and hands. g) Observe the safety instructions for the cleaning and corrosion protec‐ tion agents used by you. h) Ensure that the workpiece is not under tension. Pressgun Picco 6 press machine with battery...
-
Page 10: Intended Use
The Viega system press machine Pressgun Picco 6 is intended for pressing press connectors into the respective piping systems. In combi‐ nation with Viega press jaws, the press tool is suitable for use with all Viega sanitary and heating installation systems up and including dimen‐... - Page 11 Pressgun 6 Fig. 1: Overview Fixing lug for carrying strap Rotatable cylinder head with holder for press jaws Retaining bolt Retaining bolt lever Status LED Start button Reset button Rechargeable battery compartment Display Pressgun Picco 6 press machine with battery...
- Page 12 Fig. 3: Control elements on the battery charger Rechargeable battery compartment Status LED Gripping surfaces on the press machine ▶ To prevent injury during the pressing, hold the press machine at the gripping surface provided as shown. Pressgun Picco 6 press machine with battery...
-
Page 13: Technical Data
Sound pressure on ear 68.7 dB(A) Oscillation level < 2.5 m/s Power transmission hydraulic Thrust on piston 24 kN Switch-on duration Maximum three pressings per minute measurement uncertainty 3 dB(A) measurement uncertainty 1.5 m/s Pressgun Picco 6 press machine with battery... -
Page 14: Compatible Accessories
Only use original accessories (e.g. rechargeable batteries) with the Viega press tools, as only these were developed and adapted specifi‐ cally for use with the Viega press connector systems. Viega does not check whether accessories from other manufacturers are suitable for use with Viega press tools. -
Page 15: Control Elements And Indicators At The Press Machine
Product information The Pressgun Picco 6 operates with a voltage of 18 V DC. Automatic positive control process The press machine operates by a positively controlled process. This means: The Start button must be pressed until a minimum force is reached. - Page 16 Ä Chapter 3.4 ‘Aborting the pressing process’ on page 21. Rotatable cylinder head The press jaw fixture in the front part of the cylinder head is 270° rotat‐ able to allow for flexible alignment of the press jaws to the pressing point. Pressgun Picco 6 press machine with battery...
-
Page 17: Handling
Store the press machine in a dry, frost-free place in the case pro‐ vided. Protect the press machine and accessories from the following external influences: Impacts Moisture and humidity Dust and dirt Frost and extreme heat Chemical solutions and vapours Pressgun Picco 6 press machine with battery... -
Page 18: Commissioning
The display extinguishes as soon as the button is released again. ▶ Turn the retaining bolt lever of the retaining bolt by 180° to release it from the lock position. ▶ Pull out the retaining bolt. Pressgun Picco 6 press machine with battery... -
Page 19: Carrying Out The Pressing Process
Check the press jaw before use for any visible defect, and if applicable replace the press jaw. Only use press jaws that are the right dimension and are compatible with the press connector system. Pressgun Picco 6 press machine with battery... - Page 20 Ensure that there is enough space on the press point. Keep the press jaw contour and the area around the press point free from dirt and any objects that could hinder complete pressing. Pressgun Picco 6 press machine with battery...
-
Page 21: Aborting The Pressing Process
Then remove the incompletely pressed press connector from the installation and use a new press connector. Aborting the pressing process A pressing can be interrupted in the following situations: Pressgun Picco 6 press machine with battery... -
Page 22: Troubleshooting
The press machine does not carry out pressing. * Remove the incorrectly or incompletely pressed press connector from the installation. ** Send the press machine to your nearest service partner for inspection and maintenance. Pressgun Picco 6 press machine with battery... -
Page 23: Care And Maintenance
The tools are subject to normal wear and tear; for this reason, they must be maintained in regular intervals. The maintenance and servicing of the tools must be carried out by service partners authorised by Viega. 3.6.1 Cleaning the press tools... -
Page 24: Performing Checks
The functional safety and permanent leak tightness of the Viega press connector systems depend primarily on the functional and operational safety of the Viega system press tools, which comprise the Viega press machine plus Viega system press jaw, ring, chain, and hinged adapter jaw. -
Page 25: Disposal
Press jaws and press rings The Viega system press jaws and system press rings have a label showing the date when the next maintenance is due. Respect the main‐ tenance dates in order to guarantee safety and proper function. After completed maintenance, the Viega service partner will apply a new sticker. - Page 26 Ä ‘Regulations from section: Disposal’ on page 6. Observe the requirements on the transport of road and rail freight and of ocean and air freight if sending defective lithium ion rechargeable batteries. Pressgun Picco 6 press machine with battery...
-
Page 27: Appendix
Appendix Appendix Warranty The warranty period for Viega system tools such as press tools, press jaws, press rings, Steptec punches, pipe cutters, calibrating tools etc. is governed by national statutory regulations of the country where you have your seat. However, it is at least two years after purchase and transfer of risk. -
Page 28: Ec Declaration Of Conformity
Appendix EC Declaration of Conformity Fig. 6: EC Declaration of Conformity Pressgun Picco 6 Service partners For maintenance and repair of the press tools, contact the service partner in your country. Pressgun Picco 6 press machine with battery... - Page 29 102 Kleisthenous & Papafiessa Str, 153 44 Athens A.E.T.E. +30 (210) 604945 4 / astathis@ergon.com.gr Elmes KG Via Artigianale Nord, 6, 39044 Neumarkt +39 (0471) 813399 / info@elmes.it O.R.E. s.r.l. Via Sassonia, 16/G, 47900 Rimini +39 (0541) 741003 / info@oreutensili.com Pressgun Picco 6 press machine with battery...
- Page 30 Unit K, Ashley Drive Bothwell, G71 8BS Glasgow Depot 190 +44 (1698) 740047 / angela.hepburn@vpplc.com Broughton Plant Hire Unit 10, Trade City, Ashton Road, RM3 8UJ Romford, Essex +44 (1708) 383350 / steve@mbroughtonltd.co.uk Pressgun Picco 6 press machine with battery...
- Page 31 Viega Supply Chain GmbH & Co. KG service-technik@viega.de viega.com INT • 2020-12 • VPN180426...
