Final Steps - CODELOCKS CL500 Installation Manuals

Fit the butterfly spindle to the inside, non-code side.
3. Check that the lever handles are correctly fitted for the hand of door. To change the hand of a lever handle, loosen the
grub screw with the small Allen key, reverse the lever handle and fully tighten the grub screw.
4. Take the adaptor kit, item 10, on the contents table. Cut the two M5 countersunk head bolts to length to suit the door
thickness; i.e. door thickness plus a mximum of 10mm (no more than 5mm should enter the front plate). Hold the front plate,
with the three hole neoprene seal, against the door over the protruding spinlde. From the other side of the door, fix the
adaptor plate to the front plate using the two M5 countersunk bolts. Before tightening up the fixings, make sure that the
spindle hole is centrally positioned over the follower. Do not use excessive force.
5. Cut one of the long black socket head screws to the required length for your door. Approximate overall length should be
door thickness plus 25mm, to allow about 10mm of threaded bolt to enter the front plate. Place the neoprene gasket over the
adaptor plate. Use the screw with the 'T' shaped Allen key, to fix the back plate to the front plate through the TOP hole. Using
the 20mm socket head screw fix the back plate through the BOTTOM hole to the adaptor plate. Do not use excessive force.
6. Before closing the door, enter the code and check that the latchbolt retracts when the lever handle is depressed. Now
check the operation of the inside lever handle. If there is any binding of the handles or latch then loosen the top and bottom
bolts and reposition the plates slightly until the correct position is found, and then re-tighten the bolts.
