Installation Guide
Cel-Fi PRO
Coverage Unit with
Cel-Fi PRO X
Cel-Fi PRO X
consists of:
Cel-Fi PRO X
• one
Cel-Fi PRO X
• one
• four locking tabs
NOTE: Cel-Fi PRO SOLD SEPARATELY. To use Cel-Fi PRO X, you MUST have a Cel-Fi PRO
system. The adapters are passive devices specifically tuned for the Cel-Fi PRO, and they allow
the units to link over a cable despite obstacles that would normally prevent signals to pass.
NOTE:
• When Cel-Fi PRO X is used, the "Bars" of signal over the CU icon no longer indicate Coverage
Potential, which should be maximum with Cel-Fi PRO X installed.
• The system may be supplied with a cable, or the installer may supply their own cable that
meets the cable specifications.
• Cel-Fi PRO X will support Cel-Fi PRO wall Mounting Brackets.
sleeve for the Cel-Fi PRO Network Unit
snap-on adapter for the Coverage Unit
Cel-Fi PRO
Network Unit
Cel-Fi PRO X
with
