CEL-FI RS2 Dual Band Quick Start Manual

Enlarged version

Congratulations on your new

indoor signal solution.

This Cel-Fi system is designed to provide you with significant improve-

ments in coverage as well as 3G data rates.

Setting up the system is extremely simple and consists of placing and

plugging in two components; a Window Unit and a Coverage Unit.

By spending just a few minutes using the instructions in this guide, you

can optimize the installation and get the very most from your new Cel-Fi

System. If you have any trouble during setup, please use the trouble

shooting steps included in this guide.

Need Help?

Visit us at

www.celfihelp.com

for an installation video and other

helpful information regarding

installation and trouble shooting.

In the package you will find:

• Window Unit

• Coverage Unit

• Two Power Adapters

CEL -

FIRS

Quick Start Guide

dUAl bAnd

Table of Contents

Need help?

Do you have a question about the RS2 Dual Band and is the answer not in the manual?

Page 1 Window Unit and a Coverage Unit. By spending just a few minutes using the instructions in this guide, you can optimize the installation and get the very most from your new Cel-Fi System. If you have any trouble during setup, please use the trouble shooting steps included in this guide.
Page 2 Plug in the Window Unit: Take the Window Unit and one power supply out of the box The first step in setting up your Cel-Fi system is to find the spot in your home or office (both power supplies are identical, so you can use either one).
Page 3 Move to a location in your home where you need to have improved coverage. Plug the Coverage Unit into an easily accessible outlet. Wait significant difference in the operation of the Cel-Fi system. Try moving the Window Unit to a couple of different spots to see if until the numeric display stops cycling.
Page 4 CEL - Trouble Shooting FIRS WINDOW Indicator Issue Try This UNIT no lights on Window Unit display. There is no power. 1. Is the unit plugged in? 2. Is there power at the outlet? 3. Try exchanging the power supplies with the Coverage Unit to see if the power supply is defective.
