Machine Components - Tennant 5200 Operator's Manual

EN ENGLISH

MACHINE COMPONENTS

5
3
8
1
2
27
12
16
13
17
1. Control Grips
Control Twist Grips (Auto. Drive Models)
2. ON/OFF Key Switch
3. Vacuum ON/OFF Switch
4. Brush ON/OFF Switch
5. Battery Meter
6. Brush Motor Circuit Breaker
7. Speed Thumb Lever (Auto. Drive Models)
8. Squeegee Lift Lever
9. Solution Flow Lever
10. Solution Flow Adjustment Knob
11. Adjustable Control Console Levers
12. Brush Lift Lever
13. Brush Lift Foot Lever
14. Parking Brake (Auto. Drive Models)
4
4
9
7
6
15
11
10
14
26
28
Home Find... Go To..
19
21
22
24
26
15. Recovery Tank Drain Hose
16. Solution Tank Drain Hose with Level Markers
17. Squeegee Assembly
18. Control Console
19. Recovery Tank
20. Recovery Tank Lid
21. Solution Fill Door
22. Safety Lights
23. Rear Drive Wheel
24. Scrub Head
25. Scrub Head Skirt
26. Wall Rollers
27. Rear Fill Port
28. Vacuum Hose
29. Battery Compartment
20
23
25
5200 (02–01)
18
29
