5500/5520
Automatic Scrubber
Operator Manual
EN
Model No.s:
M55005003
M55205003
EN
612820
Rev. 01 (02 02)
Home
Find... Go To..

Advertisement

Table of Contents
loading

Related Manuals for Tennant 5500

Summary of Contents for Tennant 5500

  • Page 1 5500/5520 Automatic Scrubber Operator Manual Model No.s: M55005003 M55205003 612820 Rev. 01 (02 02) Home Find... Go To..

  • Page 2: Table Of Contents

    ..... . EC DECLARATION OF CONFORMITY FOR MACHINERY (Directive 89//392/EEC,Annex II, sub A) TENNANT N.V. model: 5500/5520 nr.: M55005003, M55205003 Address: Industrielaan 6 5405 AB – is in conformity with the provisions of the Machinery Directive ( Directive 89/392/EEC), P.O.

  • Page 3: Safety Precautions

    Report machine damage or faulty operation immediately. – Follow mixing and handling instructions on chemical containers. 4. Before leaving or servicing machine: – Stop on level surface. – Turn off machine. – Set parking brake. 5500/5520 (02–01) Home Find... Go To..

  • Page 4: Machine Components

    Left Side Battery Charge Brush Motor Meter Circuit Breaker Reverse Brush Vacuum Brush Pressure Motor Circuit Meter Squeegee Up Breaker Less Brush Pressure Solution Flow Main Power More Brush Squeegee Down Circuit Breaker Pressure 5500/5520 (02–02) Home Find... Go To..

  • Page 5: Machine Installation

    (Figure 3). 6. Turn key and main switch on and check battery meter charge level. Charge if necessary (See BATTERY CHARGING). FIG. 1 2. Turn all switches to the OFF position and remove key. 5500/5520 (02–02) Home Find... Go To..

  • Page 6: Machine Setup

    4. Unfasten black latch at front of machine and hinge open skirt housing to access motor hub (Figure 8). FIG. 5 3. Tighten thumb knobs securely. 4. Connect vacuum hose from machine to squeegee assembly (Figure 6). FIG. 8 5500/5520 (02–02) Home Find... Go To..

  • Page 7: Filling Solution Tank

    Check battery meter charge level to ensure squeegee and brush when transporting. batteries are fully charged (See BATTERY 2. Turn off key. CHARGING). Check condition of pads or brushes. Check condition of squeegee blades. 5500/5520 (02–01) Home Find... Go To..
  • Page 8 NOTE: The brushes and solution flow will not start until control grips are rotated. 7. Before starting, turn speed control knob to FIG. 17 slowest speed (Figure 15). 11. To stop machine, release control grips. 5500/5520 (02–02) Home Find... Go To..

  • Page 9: While Operating Machine

    FIG. 20 11. While cleaning, view clear tube gallon marker for remaining cleaning solution. Each mark on hose indicates19L (5 gal). 5500/5520 (02–02) Home Find... Go To..

  • Page 10: Circuit Breakers

    (Figure 22). NOTE: If using a bucket to drain machine, do not use same bucket for filling solution tank. This will prevent possible solution line clogs. 5500/5520 (02–01) Home Find... Go To..

  • Page 11: Battery Charging

    DO caps securely and to wipe off the top of batteries NOT overfill. Batteries can overflow during with a clean cloth. charging due to expansion. Replace cell caps before charging (Figure 25). 5500/5520 (02–02) Home Find... Go To..

  • Page 12: Machine Maintenance

    Electrical component damage may Check drive, vacuum and brush motors for carbon result. brush wear, replace brushes if worn to a length of 1cm (0.38 in) or less. 6. Recharge batteries if needed. 5500/5520 (02–02) Home Find... Go To..

  • Page 13: Battery Maintenance

    FOR SAFETY: When using machine, go slow on inclines and slippery surfaces. 1. Remove squeegee from machine and raise scrub head. Leave pad or brush installed. 2. Load machine using a recommended loading ramp. 5500/5520 (02–02) Home Find... Go To..

  • Page 14: Trouble Shooting

    Calibrate knob and retighten screw. Short run time. Batteries not fully charged. Charge batteries. Bad cell in one or more batteries. Replace battery. Batteries need maintenance. See BATTERY MAINTENANCE. Faulty charger. Replace battery charger. 5500/5520 (09–01) Home Find... Go To..

  • Page 15: Specifications

    Contact Service Center. Battery charge level is low. Charge batteries. Do not run machine when battery meter is in the red zone. SPECIFICATIONS MODEL 5500 5520 LENGTH 1270 mm (50 in) 1270 mm (50 in) WIDTH 660 mm (26 in)
