Tennant 5200 Operator's Manual
  1. Manuals
  2. Brands
  3. Tennant Manuals
  4. Floor Machine
  5. 5200
  6. Operator's manual
Tennant 5200 Operator's Manual

Tennant 5200 Operator's Manual

Hide thumbs Also See for 5200:
Table of Contents

Advertisement

Quick Links

5200
Automatic Scrubber
Models:
Operator Manual
EN
612954
612955
EN
612999
Rev. 00 (01-02)
Home Find... Go To..

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5200 and is the answer not in the manual?

Questions and answers

Related Manuals for Tennant 5200

Summary of Contents for Tennant 5200

  • Page 1 5200 Automatic Scrubber Models: Operator Manual 612954 612955 612999 Rev. 00 (01-02) Home Find... Go To..

  • Page 2: Table Of Contents

    ....EC DECLARATION OF CONFORMITY FOR MACHINERY (Directive 89//392/EEC,Annex II, sub A) TENNANT N.V. model: 5200 nr.: 612954 / 612955 Address: Industrielaan 6 5405 AB – is in conformity with the provisions of the Machinery Directive ( Directive 89/392/EEC), P.O.

  • Page 3: Safety Precautions

    Report machine damage or faulty operation immediately. – Follow mixing and handling instructions on chemical containers. 4. Before leaving or servicing machine: – Stop on level surface. – Turn off machine. – Set parking brake, if equipped. 5200 (02–01) Home Find... Go To..

  • Page 4: Machine Components

    25. Scrub Head Skirt 11. Adjustable Control Console Levers 26. Wall Rollers 12. Brush Lift Lever 27. Rear Fill Port 13. Brush Lift Foot Lever 28. Vacuum Hose 14. Parking Brake (Auto. Drive Models) 29. Battery Compartment 5200 (02–01) Home Find... Go To..

  • Page 5: Machine Installation

    Recommended Battery Specifications: Two 12 volt deep cycle 130 amp hour batteries. NOTE: Only models with automatic drive are Tennant Part Number #130869. Maximum battery equipped with a parking brake. dimensions are 180 mm W (7.13 in.) x 330mm L (13 1.

  • Page 6: Machine Setup

    (Figure 7). 1. Turn machine off. 2. Lower brush head. Step down firmly on top pedal and push pedal forward to lower (Figure 5). 5200 (01–02) Home Find... Go To..

  • Page 7: Filling Solution Tank

    (three settings). Squeeze together two below the fill port has 19L (5 gal) increment levers under console to raise or lower control grips markers to indicate amount of water in tank (Figure 12). (Figure 10). 5200 (01–02) Home Find... Go To..
  • Page 8 5. Turn machine power on by turning key. 6. Turn vacuum switch to the ‘‘ON” position. 7. Push solution flow lever forward to desired solution flow. Solution will immediately begin to flow once lever is activated (Figure 15). FIG. 17 5200 (01–02) Home Find... Go To..

  • Page 9: While Operating Machine

    Brush motor circuit breaker button is located at rear control console (Figure 21). FIG. 19 ATTENTION: Do not continue to run machine when battery meter needle is in the red zone, battery damage will result. FIG. 21 5200 (02–01) Home Find... Go To..

  • Page 10: Draining Tanks

    1. Pull clear gallon marker hose off hose barb at rear 1. Transport machine to a well ventilated area when of machine and drain solution into floor drain or charging. bucket (Figure 23). 2. Turn key off. 3. Set parking brake, if equipped. 5200 (02–01) Home Find... Go To..

  • Page 11: Battery Charging

    FIG. 26 NOTE: Once the charger is connected to the machine, machine becomes inoperable. 7. Plug charger into grounded wall outlet after connecting charger to machine (Figure 27). 5200 (01–02) Home Find... Go To..

  • Page 12: Maintenance

    After cleaning, apply a coating of clear battery post protectant to terminals and cable 3. Lubricate axle (drive models) and caster grease connections. fittings with a water resistant grease. 4. Check for loose or worn cables. Replace if worn. 5200 (02–01) Home Find... Go To..

  • Page 13: Drive Chain Maintenance

    5. Place tie–down straps over top of machine and secure straps to floor. It may be necessary to install some tie-down brackets to the floor of your trailer or truck. 5200 (NIL) Home Find... Go To..

  • Page 14: Trouble Shooting

    Tighten lid. Vacuum motor is loose. Tighten down vacuum motor. Do not over tighten and damage motor. Battery charge is low. Charge batteries. Do not run machine when battery meter is in the red zone. 5200 (02–01) Home Find... Go To..

  • Page 15: Specifications

    Machine won’t move when Parking brake is set. Release parking brake. twisting control grips. SPECIFICATIONS Model 5200 5200 (Drive Model) LENGTH 119 cm (47in) 119 cm (47 in) WIDTH 55 cm (22 in) 55 cm (22 in) HEIGHT...
