Connections - Vizualogic ELite Console User Manual

Connections

AV Connectors
Black
Blue
Installation and Connections
Video Input Connector
Green / Yellow
This c onnec tor is us ed in c ombina tion with the video inputs of other video
produc ts (AV hea d out or TV Tuner).
Audio Input Connectors
White(L)
Red ( R)
Thes e c onnec tors a re us ed in c ombina tion with a hea d unit or TV Tuner with
a udio output c onnec tors .
Video Output Connector
Blue / Yellow
This c onnec tor is us ed in c ombina tion with the video inputs of other video
produc ts (AV hea d unit or L C D monitor).
Audio Output Connectors
Brown / White(L)
Thes e c onnec tors a re us ed in c ombina tion with a hea d unit or L C D monitor
Yellow / Red ( R)
with a udio input c onnec tors .
Black GND
C onnec t this line to the vehic leís G ND line.
Red ACC
C onnec t this line to the vehic leís AC C line. (S witc hed 12V, ignition)
The fa c tory defa ult will ha ve a c onnec tor. P lea s e c ut the c onnec tor
before c onnec t to the s ys tem.
CAUTION
( )G ND (B la c k)
(+ )AC C (R ed)
R ea r-S ea t E nterta inment
20
