Installation and Connections
B efore ins ta lling or c onnec ting the unit, plea s e rea d
the following a nd pa ge 2~ 3 of this ma nua l
thoroughly for proper us e.

Caution

The ba c k s ea t pa s s enger mus t fasten the safety belt
before opera ting the unit.
Limitation
The width between the front seats must be
greater that the width of the monitor.
8" LCD Monitor 22cm
The c hink between the front s ea t a nd c enter c ons ole
box mus t be grea ter tha n the thic knes s of the bra c ket
a rms (At least 1.5cm) .
The top c over of the C enter c ons ole box s hould be
opera ted. We propos e tha t the tra ns vers e a xle mus t
be higher tha n the top c over by
B oth s ides of the bra c kets s hould not go beyond the
c a s e edge of C enter c ons ole box a nd too nea r to driver.
Have the wiring and installation done by experts.
The wiring a nd ins ta lla tion of this unit requires
s pec ia l tec hnic a l s kill a nd experienc e. To ens ure
s a fety, a lwa ys c onta c t the dea ler where you
purc ha s ed this unit to ha ve the work done.
Use speci ed accessory parts and install them
securely.
B e s ure to us e only the s pec i ed a c c es s ory pa rts .
U s e of other tha n des igna ted pa rts ma y da ma ge this
unit interna lly or ma y not s ec urely ins ta ll the unit in
pla c e. This ma y c a us e pa rts to bec ome loos e
res ulting in ha za rds or produc t fa ilure.
Arrange the wiring so it is not crimped or
pinched by a sharp metal edge.
R oute the c a bles a nd wiring a wa y from moving pa rts
(like the s ea t ra ils ), s ha rp or pointed edges . This will
prevent c rimping a nd da ma ge to the wiring. If
wiring pa s s es through a hole in meta l, us e a rubber
grommet to prevent the wires ins ula tion from being
c ut by the meta l edge of the hole.
Drilling can cause airborne debris.
Airborne debris c a n c a us e s erious injury to the eyes .
Wea r protec tive eye-wea r when drilling.
15
C enter Armres t Monitor
Make the correct connections.
F a ilure to ma ke the proper c onnec tions ma y
res ult in re or produc t da ma ge.
Use only in cars with A 12 volt negative ground.
(C hec k with your dea ler if you a re not s ure. ) F a ilure
to do s o ma y res ult in elec tric s hoc k or injury due to
elec tric a l s horts .
Do not allow cables to become entangled in
surrounding objects.
Arra nge wiring a nd c a bles in c omplia nc e with the
ma nua l to prevent obs truc tions when driving.
Do not splice into electrical cables.
Never c ut a wa y c a ble ins ula tion to s upply power to
other equipment. Doing s o will exc eed the c urrent
c a rrying c a pa c ity of the wire a nd res ult in re or
elec tric s hoc k.
Do not damage the electrical wire when drilling
holes.
When drilling holes in the c ons ole box for
ins ta lla tion, ta kes prec a utions s o a s not to c onta c t,
da ma ge the elec tric a l wiring. F a ilure to ta ke s uc h
3-5 cm .
prec a utions ma y res ult in re.
Keep small objects as batteries out of the
reach of small children.
S wa llowing them ma y res ult in s erious injury.
If s wa llowed, c ons ult a phys ic ia n immedia tely.
Be sure to disconnect the cable from the (-)
battery post before installing this unit.
This will reduc e a ny c ha nc e of da ma ge to the unit in
c a s e of a s hort-c irc uit.
Be sure to connect the color coded leads
according to the diagram.
Inc orrec t c onnec tions ma y c a us e the unit to
ma lfunc tion or da ma ge to the vehic le's elec tric a l
s ys tem.
When making connections to the vehicle's
electrical system, be aware of the factory
installed components. Do not tap into these leads
to provide power for this unit.
F a ilure to do s o ma y res ult in da ma ge to the unit or
vehic le. When it doubt, plea s e c ons ult your dea ler.
This unit uses female RCA-type jacks for
connection to other units (e.g. ampli er) having
RCA connectors.
You ma y need a n a da ptor to c onnec t other units . If
s o, plea s e c onta c t your a uthorized dea ler for
a s s is ta nc e.

Warning

Precautions:
