Installation and Connections
5
Installation of screws:
A Type (Figure 5-1)
P ut the mounting pla te ins ide of the c ons ole box,
a nd x the mounting pla te from outs ide to ins id e
with 4pc s 4x25 s elf-ta pping s c rews . s a me a s right
bra c ket.
B Type (Figure 5-2)
U s e 4x25 s elf-ta pping s c rews a nd s pring
buc kle to x the bra c ket on the both s ides of
the c ons ole box.
6
Drill cable hole.
After you have c hos en the s uita ble pla s tic wa s her,
please drill a 15mm hole with the pla s tic wa s her in the U
brea c h pla c e. (F igure 6)
15mm Cable Hole
7
Fix the transverse axle.
After a djus ting a nd c on rming the width of
tra ns vers e a xle, plea s e us e the Allen K ey to tighten
the 5x12 s c rews . (F igure 7)
8
Assemble the outside cover of the Right/
Left Brackets.
U s e 3x8 s c rews to x the outs ide c over of the
right a nd left bra c ket a rms . (F igure 8)
The a bove shows a ll the ins ta lla tion procedure.
19
C enter Armres t Monitor
A Type
B Type
(F igure 6)
A lle n K e y
(F igure 7)
(F igure 8)
