BWT TFPKIT Installation And Operating Instructions

T roubleshooting
Leaks:
...Between head and cartridge
(1) Tu rn off the water supply to the filter and dispense water from
drinking water tap until water and airflow stops.
(2) Remove cartridge and inspect o-rings to make sure they are
in place and clean.
(3) Install cartridge and turn on water supply . If it still leaks, con-
tact Technical Support.
...From pushfits
Tu rn off saddle valve and turn on drinking water tap. Remove
tubing from the pushfit inserts on the filter head and ensure
the tube is cut squarely. If so insert the tube back into the
p ushfits ensuring the tube is pushed fully home. Open the
water supply valve, then close tap and check for leaks.
If the leaks persist, or if there are other leaks on the unit, turn
off the water supply then call Technical Support.
...On saddle valve connection
Call Technical Support.
...On tap/tubing connection
Call Technical Support.
NOTE: If leaks persist, or if there are other leaks on system, turn off
water supply . Call our technical support department.
P er formance Data
Model: Taste Fresh Protection
Important Notice: Read this performance data and compare
the capabilities of this system with your actual water treatment
needs.
Test Conditions:
Flow Rate = 0.5 gpm
Inlet Pressure = 60 psi (4.1 bar)
pH = 7.5 ± 1
Temperature = 68º F ± 5º F (20º C ± 2.5º C)
Operating Requirements:
Pressure = 30-125 psi (2.1-8.62 bar)
Temperature = 40º-100º F (4.4º-37.7º C)
Turbidity = 5 NTU Max
Do not use with water that is microbiologically unsafe or
unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
1000R Cartridge
U.S. EPA Avg. Influent Avg.(Max) Effluent
MCL* Concentration Concentration
Standard 42
Chlorine–Class I –** 2.1 ppm 0.02 ppm
Particulates –** 7,108,826 #/ml 15,896 #/ml
(0.5 to<5 µm)
–Class I
Standard 53
†
Cysts 99.95 % 130,750 #/ml 0 #/ml
Reduction (0 #/ml )
T urbidity 0.5 NTU* 37.4 NTU 0.08 NTU
(0.08 NTU)
Lead 0.010 ppb‡ 0.15 mg/L 0.001 mg/L
(6.5 pH) (0.001 mg/L)
Lead 0.010 ppb‡ 0.15 mg/L 0.002 mg/L
(8.5 pH) (0.003 mg/L)
Atrazine 0.003 mg/L 0.0088 mg/L 0.0002 mg/L
(0.0002 mg/L)
Lindane 0.0002 mg/L 0.002 mg/L 0.00005 mg/L
(0.00005 mg/L)
Flow Rate = 1.89 Lpm Capacity = 1892L or 6 Months
* US EPA Maximum Contaminant Level
** No maximum contaminant level
† NSF test requirement of at least 50,000 3–4 micron particles per milliliter .
The 3–4 micron size particle is a surrogate particle for Cryptosporidium
and Giardia cysts.
‡ US EPA Action Level for lead
NOTE: Substances reduced are not necessarily in your water.
Filter must be maintained according to manufacturer's
instructions, including replacement of filter cartridges.
Guarantee
This product is guaranteed for the period of one year from the date of
purchase against any manufacturing fault. The guarantee is only valid if
the product has been installed and used in accordance with the
manufacturers instructions and has not been dismantled or interfered
with in any way . Damage caused to the product or by the product as a
result of failure to use the product in accordance with the
manufacturers instructions is not covered by this guarantee. Under this
guarantee we undertake at our discretion to repair or replace free of
charge the product or any part thereof that is found to be faulty . Costs
associated with the fitting of a replacement product or part or the
removal of the product are not covered by this guarantee. Loss or
damage caused by the product (including consequential loss) is not
covered by this guarantee. This guarantee does not affect your
statutory rights.
Customer Help Line:
01376 334 200
Monday to Friday 08.30 – 17.00 UK Only.
BWT UK Limited,
BWT House,
Coronation Road,
High Wycombe,
Buckinghamshire,
HP12 3SU
Tel: 01376 334 200
Fax: 01376 334 201
Email: sales@bwt-uk.co.uk
All trademarks are protected under European law and must not be reproduced by
third parties without express permission of BWT UK Limited in writing.
As part of BWT's policy of constant product development, BWT reserves the
right to alter product specifications without prior notice.
4
Avg.(Min)
Reduction
99%
T aste Fresh Protection Drinking Water Filter System
99.8%
Installation and Operating Instructions
Model: TFPKIT
99.99%
(99.99%)
Specifications
99.96%
Pressure Range: 30–125 psi (2.1–8.62 bar)
(99.95%)
99.3%
Temperature Range: 40–100°F (4.4–37.7°C)
(99.3%)
Rated Service Flow: 1.9 Lpm
98.6%
Filter Capacity: 1893 L
(98%)
97.7%
(97.7%)
Parts Included:
(97.5%)
•
Filter head with built-in mounting bracket, and
(97.5%)
compression fittings
•
1000R filter cartridge
•
Screws for mounting bracket
•
Saddle tapping valve with tube attached
•
Drinking water tap with tube attached
•
6.35 mm (1/4") plastic tubing
Tools Required
•
Phillips Screwdriver
•
Towel
•
Drill
•
Tape Measure
Optional Materials
•
6.3 & 12.7 mm (1/4" & 1/2") Drill Bit
•
Cone-shaped grinding wheel
Precautions
Do not use with water that is microbiologically
WARNING:
unsafe or of unknown quality without adequate
disinfection before or after the system. Systems
certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
CAUTION: This filter must be protected from freezing, which
can cause cracking of the filter and water leakage.
CAUTION: Because of the product's limited service life and to
prevent costly repairs or possible water damage,
we strongly recommend that the head of the filter
be replaced every ten years. If the head of your filter
has been in use for longer than this period, it should
be replaced immediately . Date the top of any
new head to indicate the next recommended
replacement date.
CAUTION: Turn off water supply to head without cartridge if it must
be left unattended for an extended period of time.
•
For cold water use only .
•
Make certain that installation complies
with all local bylaws and regulations.
•
The contaminants or other substances
removed or reduced by the selected
cartridge are not necessarily in your water.
Ask your local water supplier for a copy of
their water analysis.
•
After prolonged periods of non-use (such as during a
holiday) it is recommended that the system be flushed
thoroughly . Let water run for 2-3 minutes before using.
•
The filter cartridge used with this system has a limited service
life. Changes in taste, odour , colour; and/or flow of the water
being filtered indicate that the cartridge should be replaced.
Installation
•
File or Sandpaper
•
•
P encil
For standard installation on 15mm copper, steel, brass or PVC
• cold water pipe.
3.2 mm (1/8") Drill Bit
•
• Please read all instructions and precautions before installing
Adjustable Wrench
and using your under-sink drinking water system.
•
Numbered diagrams correspond with numbered steps.
1. Selecting the Tap Location
NOTE: The drinking water tap should be positioned with function,
convenience, and appearance in mind. An adequate flat area
is required to allow tap base to rest securely . The tap fits through
a 12mm hole.
CA UTION: Do not attempt to drill through an all-porcelain sink. If
you have an all-porcelain sink, drill through countertop next to
sink. The following instructions apply to porcelain-coated cast iron
and stainless steel sinks only . Consult a professional plumber
about installation on an all-porcelain sink.
Customer Help Line: 01376 334 200
Monday to Friday 08.30 – 17.00 UK Only.
(continued overleaf)
