TEChNICAL DATA
VECTOR 40 VECTOR 80
Measurement range 0.2 – 40 m* 0.2 – 80 m*
Accuracy ± 1.5 mm** ± 1.5 mm**
Measurement unit m m, in, ft, ft+in
Laser class 2 2
Laser type 650 nm, < 1 mW 635 nm, < 1 mW
Protection type – iP 54
Automatic shut-off of 30 s 30 s
laser
Automatic shut-off of 180 s 180 s
device
Battery life up to 5000 up to 5000
measurements*** measurements***
Battery type 2 x AAA 1.5 V 2 x AAA 1.5 V
Operating temperature 0 – 40 °C 0 – 40 °C
storage temperature -10 – 60 °C -10 – 60 °C
Dimensions 120 x 48 x 27 115 x 52 x 32
Weight, 120 g 140 g
including batteries
* Depending on the ambient conditions in the workplace.
** This degree of precision applies when measuring distances of between 0.2 and
10 m. When measuring distances of between 10 m and 80 m, the maximum
tolerance may decrease by 0.1 mm/m.
*** When operated at room temperature.
sOLA-Messwerkzeuge GmbH
Unteres Tobel 25
A-6840 Götzis
Tel: +43 (0)5523 53380-0
Fax: +43 (0)5523 53385
sola@sola.at
www.sola.at
ing. Guido scheyer
sOLA-Meßwerkzeuge GmbH & Co.
Wannental 50
D-88131 Lindau
Tel: +49 (0)8382 28585
Fax: +49 (0)8382 977002
sola@sola.de
www.sola.de
sOLA suisse AG
Grenzstrasse 24
CH-9430 st. Margrethen
Tel: +41 (0)71740 1616
Fax: +41 (0)71740 1818
info@solasuisse.ch
www.solasuisse.ch
ORDERING INFORmATION
Includes:
Laser-Range Finder VECTOR 40


2 x 1.5 V (AAA) batteries


1 Belt clip


1 Operating manual CD


VECTOR 40 item no. 71020101
Includes:
Laser-Range Finder VECTOR 80


2 x 1.5 V (AAA) batteries


1 Belt bag


1 Operating manual CD


VECTOR 80 item no. 71021101
ACCESSORIES
For detecting laser points in
unfavourable light conditions or at
greater distances of up to 80 m.
Laser goggles LB RED item no. 71124501
Target ZS RED item no. 71126401
Further information regarding the accessories
can be found at www.sola.at
EASy TO OpERATE
Your most frequently used measuring functions are ready
to use at the touch of a button. The display offers fast and
intuitive navigation through the other function levels and
settings.
4-row display Large keys,
+ backlight
optimum layout
Measuring right into the Easy grip thanks to the
corners (VECTOR 80) combination of plastic and
soft-touch components
VECTOR 40 / 80
LASER RANGE FINDER
UsEFUL. PRACTiCAL. ACCURATE.
