Sola FCL Operating Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Enlarged version
FCL
D
Gebrauchsanweisung
5 . . . . 12
GB
Operating instructions
13 . . . . 20
F
Mode d'emploi
21 . . . . 28
I
Instruzioni d'uso
29 . . . . 36
E
Instrucciones de uso
37 . . . . 44
NL
Gebruiksaanwijzing
45 . . . . 52
Zubehör
Accessories / Accessories / Accesorios / Tillbehör / Tilbehør / Lisävarusteet
A
A
. . . . . . . . . . . . . . . . . LB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sola FCL

Summary of Contents for Sola FCL

  • Page 1 Zubehör Accessories / Accessories / Accesorios / Tillbehör / Tilbehør / Lisävarusteet Gebrauchsanweisung 5 ..12 Operating instructions 13 ..20 Mode d’emploi 21 ..28 Instruzioni d’uso 29 ..36 Instrucciones de uso 37 .

  • Page 3: Table Of Contents

    6. Operation ..........17 7. Checking and adjusting the FCL ......17 8.

  • Page 4: Safety Instructions

    3. Description The numbering of the device elements refers to the display of the device on the graphics page. On/Off switch Adjustment wheels Vial Laser beam output Battery cover 4. Safety instructions Before using the device, please read the operating manual and safety instructions in full, and apply them carefully in practice.
  • Page 5 Improper use • Using the product without having received instructions. • Using the product for purposes other than those for which it is intended. • Disabling safety equipment and removing instruction and warning signs. • Opening any part of the device, except for the battery compartment. •...

  • Page 6: Technical Data

    5. Technical data Laser class: 2, according to EN 60825-1 ≤ 1.0 mW, 635 nm Laser type: Max. measuring tolerance: 0.3 mm/m Operating range: (approx) r = 10 m, depending on the light conditions at the workplace Laser diodes: 4 x 635 nm semiconductor diodes Crossing angle: 90°...

  • Page 7: Operation

    First you must remove the battery cover from underneath the laser. When the battery cover has been removed, you have access to the battery housing. 4 AA batteries are used for the FCL. Alkaline batteries are recommended for optimum operating time.

  • Page 8: Cleaning

    8. Guarantee The manufacturer guarantees the original buyer, as named on the guarantee card, that the product shall remain free of manufacturing defects for a period of two years after purchase. This guarantee is limited to repair and / or replacement, according to the manufacturer’s choice.

  • Page 9: Disposal

    10. Disposal Measuring tools, accessories and packaging should be disposed of in an envi- ronmentally sound manner, i.e. recycled. Only for countries of the EU Do not dispose of the laser device, along with your household waste! According to the European Directive 2002/96/EC all unwanted electrical and electronic devices must be collected separately for specialist disposal.
