SPECIFICATIONS

Repl. Lamp Part No.
Repl. Lamp Model No.
Lamp Life Efficiency
PRO-Cell™ Substrate
Frame body between flanges
W L
24-3/4" 30-3/4"
620mm 784mm
Outside dimensions of flanges at both ends
W L
25-3/4" 23"
659mm 585mm
Cover for electronics
W H
18-1/2" 20-1/8"
470mm 510mm
Power
Fuse
Max Air Flow
Max Face Velocity
Lamp Service
UVC Range
PRO-Cell™ Catalyst
Unit Weight
Dimensions
Standard with MERV13 Media Pre Filter and 3 PRO-Cell™ Modules
(1 Master Module [MM], 2 Slave Module [SM])
CFM in W.C.
1200 0.19 47.326
1600 0.26 64.763
2000 0.35 87.181
Flange height
H 1/2" all around
22" 12mm all around
560mm
D
2-7/8"
72mm
110V/60Hz / 1.8 Amps 150watts
220V/50Hz /.09 Amps 150watts
Replace only with AGC-6 Fuse
2500 CFM 70.8 m3/min
720 FPM 220 m/min
46636400
22LAMP
2 Years
Recommended Replacement every 12-24 months
253.7nm
Titanium Dioxide TiO2 - 30,240 in2 195,096 cm2
Honeycomb Aluminum Cells
92 lbs 42 kg
23"H x 31"W x 29"D
585mm H x 787mm W x 737mm D
pa
Cover for MERV13 Pre Filter
W
3-5/16"
84mm
Cover optional formaldehyde or carbon post filter
W
1-1/2"
38mm
2 electric connectors (protruding from covers)
1-1/2" x 1" Dia
38mm x 25mm Dia
H D
19" 1/2"
484mm 12mm
H D
19" 1/2"
484mm 12mm
