Pin Kit - Assa Abloy Pyramid Owner's Manual

Pin Kit

Pin Kit
Pin Kit - Includes Follower and Tweezers
How to Order:
` Pyramid High Security: PK-20-HS
Pyramid Security: PK-20-PS
Pin Kit Contents
LENGTH BOTTOM MASTER
.031" 2
.047" 3
.063" 4
.078" 5
.094" 6
.110" 7
.126" 8
.139" 0
.141" 9
.155" 1
.157"
.171" 2
.173"
.187" 3
.189"
.202" 4
.204"
.218" 5
.220"
.234" 6
.236"
.250" 7
.252"
.265" 8
.267"
.281" 9
.283"
.299"
PINS (SPECIFY SIZE)
QTY. PART NO.
Vial of 100 695F25(Length)
Vial of 100 695F24(Length)
Vial of 100 628F107-142
Vial of 100 628F107-236
Vial of 20 630F494
The warranty on Corbin Russwin products becomes void if the product is modified in any way, regardless of whether the modifications causes or contributes to any alleged defect. If a
Corbin Russwin product is modified it may no longer meet industry certification and quality control standards applicable to the original product and is no longer a genuine Corbin Russwin product.
Copyright © 2006-2018, Corbin Russwin, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Corbin Russwin is
prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Follower
How to Order
Separately: CT20
OR
BUILD-UP TOP IC - TOP
-8
-7 9
-6 8
-5 7
-4 6
-3 5
-2 4
-1 A 3
0 2
+1 1
+2 0
+3 B
+4
+5 C
+6
+7
+8
+9
DESCRIPTION
Top Pins
Bottom Pins
Top Pins A - BRP
Top Pins C - BRP
Side-Pin
14
14
Owner's Manual
Owner's Manual
Tweezers
How to Order
Separately: CT19
PK-20-HS
PK-20-HS
and
PART NO.
PK-20-PS
QTY
100 695F257031 695F252031
100 695F257047 695F252047
100 695F257063 695F252063
100 695F257078 695F252078
100 695F257094 695F252094
100 695F257110 695F252110
100 695F257126 695F252126
100 695F247139 695F244139
100 695F257141 695F252141
100 695F247155 695F244155
100 695F257157 695F252157
100 695F247171 695F244171
100 695F257173 695F252173
100 695F247187 695F244187
100 695F257189 695F252189
100 695F247202 695F244202
100 695F257204 695F252204
100 695F247218 695F244218
100 695F257220 695F252220
100 695F247234 695F244234
100 695F257236 695F252236
100 695F247250 695F244250
100 695F257252 695F252252
100 695F247265 695F244265
100 695F257267 695F252267
100 695F247281 695F244281
100 695F257283 695F252283
100 695F257299 695F252299
CYLINDER PARTS
DESCRIPTION PART NO.
Tumbler Springs 697F50
Spring Cover 217F43
IC Spring Cover 217F44
Follower .496 CT20
Tweezers CT19
Blocking Plate 696F42
PK-20-PS
PART NO.
PK-20HS Qty.
100
100
20
1
1
20
