Mortara ELI 280 User Manual

Mortara ELI 280 User Manual

Resting electrocardiograph
Hide thumbs Also See for ELI 280:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
REF 9515-181-53-ENG Rev C
Manufactured by Mortara Instrument, Inc., Milwaukee, Wisconsin U.S.A.
CAUTION: Federal law restricts this device to sale by or on the order of a physician.
ELI 280
RESTING ELECTROCARDIOGRAPH
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELI 280 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mortara ELI 280

Summary of Contents for Mortara ELI 280

  • Page 1 REF 9515-181-53-ENG Rev C ELI 280 RESTING ELECTROCARDIOGRAPH USER MANUAL Manufactured by Mortara Instrument, Inc., Milwaukee, Wisconsin U.S.A. CAUTION: Federal law restricts this device to sale by or on the order of a physician.
  • Page 2 Mortara Instrument, Inc. Mortara is a registered trademark of Mortara Instrument, Inc. AM12, ELI, E- Scribe, VERITAS, and WAM are trademarks of Mortara Instrument, Inc. DICOM is the registered trademark of the National Electrical Manufacturers Association for its standards publications relating to digital communications of medical information.

  • Page 3: Table Of Contents

    NITIAL TARTUP ..........................29 ALIBRATING THE OUCHSCREEN ISPLAY ..........................29 ONNECTING THE CQUISITION ODULE ................................12 OADING APER ELI 280 ..............................15 OWERING THE ........................... 16 ATTERY AILSAFE ONDITIONS ................................16 OWER TATUS ..............................17 ETTING ATE AND ..............................17...
  • Page 4 ECG A AM12 ....................... 24 CQUISITION AND RINTING WITH ECG A ................................24 CQUISITION 10 S ECG ..............................27 ECONDS OF ECG R ............................27 ONFIGURING THE EPORT ECG S ..............................28 CQUIRED TORAGE ............................... 28 CQUIRING HYTHM TRIPS CONNECTIVITY AND ECG TRANSMISSION ......................... 29 ECG T .................................

  • Page 7: Technical Support And Service

    TECHNICAL SUPPORT AND SERVICE Headquarters Sales Support/ Supplies & Accessories Mortara Instrument, Inc. 7865 North 86th Street Mortara Instrument, Inc. Milwaukee, WI 53224 7865 North 86th Street U.S.A. Milwaukee, WI 53224 Tel: 414.354.1600 U.S.A. Tel: 800.231.7437 Tel: 414.354.1600 Fax: 414.354.4760 Fax: 414.354.4760...

  • Page 8: Notices

    Failure to do so may cause undue failure and possible health hazards. Equipment Identification Mortara Instrument, Inc. equipment is identified by a serial and reference number on the bottom of the device. Care should be taken so that these numbers are not defaced.

  • Page 9: Warranty Information

    Product/s returned to Mortara’s principal place or any other place as specifically designated by Mortara or an authorized distributor or representative of Mortara, and (ii) all risk of loss in transit. It is expressly agreed that the liability of Mortara is limited and that Mortara does not function as an insurer. A purchaser of a Product/s, by its acceptance and purchase thereof, acknowledges and agrees that Mortara is not liable for loss, harm, or damage due directly or indirectly to an occurrence or consequence therefrom relating to the Product/s.
  • Page 10 THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCT/S TO THE EXTENT THAT THE DEFECT IS NOTICED AND MORTARA IS NOTIFIED WITHIN THE WARRANTY P E R I O D . IN N O E V E N T , INCLUDING THE CLAIM FOR NEGLIGENCE, SHALL MORTARA BE LIABLE FOR...

  • Page 11: Warning(S)

    To ensure that electrical safety is maintained during operation from AC (~) power, the device must be plugged into a hospital-grade outlet.  Only use parts and accessories supplied with the device and/or are available through Burdick/Mortara/Quinton.  Patient acquisition devices intended for use with the device include series resistance (9 Kohm minimum) in each lead for defibrillation protection.
  • Page 12 The ELI 280 is a medical device that has been designed to be connected to other devices for the purpose of receiving and transmitting data. Certain measures must be taken to prevent the risk of excessive electric current flow through the operator or patient when connected: ...
  • Page 13 USER SAFETY INFORMATION  The device has not been designed for use with high-frequency (HF) surgical equipment and does not provide a protective means against hazards to the patient.  When the 40 Hz filter is used, the frequency response requirement for diagnostic ECG equipment cannot be met.

  • Page 14: Caution(S)

     The rechargeable internal battery is a sealed lead-acid type and it is totally maintenance free. If the battery appears to become defective, refer to Mortara Instrument Service Department.  Do not pull or stretch patient acquisition device as this could result in mechanical and/or electrical failures.
  • Page 15 USER SAFETY INFORMATION  The display of a thick baseline while using the AM12 acquisition module (square waves on rhythm printout) could be due to an improper auto-calibration. Reconnect the AM12 or power cycle the electrocardiograph.  A square wave on the display and rhythm printout could be due to the WAM, the AM12, or lead wires not being connected to the patient.
  • Page 16 RF sources may interfere with the transmission generated by the device. Mortara Instrument has tested the coexistence of the device with other devices that can interfere such as devices using WLAN, Bluetooth radio, and/or cell phones.

  • Page 17: Symbol Delineation

    EQUIPMENT SYMBOLS AND MARKINGS Symbol Delineation Attention, consult accompanying documents Alternating current Protective earth symbol (appears on inside of unit) Fuse symbol (appears on inside of unit) Telephone line (modem) Network (LAN) Universal Serial Bus (USB) Defibrillator-proof type CF applied part Input ON/OFF (power) ...
  • Page 18 EQUIPMENT SYMBOLS AND MARKINGS Patient Information Initiate Acquisition Of ECG Initiate Printing Of Continuous Rhythm Strip Initiate Transmission Of Records Stop Rhythm Print Out Configuration (Settings) Menu Home (returns user to the real-time acquisition screen)

  • Page 19: Precautions

    GENERAL CARE Precautions  Turn off the device before inspecting or cleaning.  Do not immerse the device in water.  Do not use organic solvents, ammonia-based solutions, or abrasive cleaning agents which may damage equipment surfaces. Inspection Inspect your equipment daily prior to operation. If you notice anything that requires repair, contact an authorized service person to make the repairs.

  • Page 20: Electromagnetic Compatibility (Emc)

    See appropriate EMC table for recommended separation distances between the radio equipment and the device. The use of accessories, transducers, and cables other than those specified by Mortara Instrument may result in increased emissions or decreased immunity of the equipment.
  • Page 21 ELECTROMAGNETIC COMPATIBILITY (EMC) Guidance and Manufacturer’s Declaration: Electromagnetic Emissions The equipment is intended for use in the electromagnetic environment specified in the table below. The customer or the user of the equipment should ensure that it is used in such an environment. Emissions Test Compliance Electromagnetic Environment: Guidance...
  • Page 22 ELECTROMAGNETIC COMPATIBILITY (EMC) Guidance and Manufacturer’s Declaration: Electromagnetic Immunity The equipment is intended for use in the electromagnetic environment specified in the table below. The customer or the user of the equipment should ensure that it is used in such an environment. IEC 60601 Test Compliance Emissions Test...
  • Page 23 ELECTROMAGNETIC COMPATIBILITY (EMC) Recommended Separation Distances Between Portable and Mobile RF Communications Equipment and the Equipment The equipment is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the equipment can help to prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the equipment as recommended in the table below, according to the maximum output power of the communications equipment.

  • Page 24: Introduction

    This manual is intended to provide the user with information about:  Using and understanding the ELI™ 280 electrocardiograph, the touchscreen display, and the function control icons.  Preparing the ELI 280 for use.  Acquiring, printing, and storing an ECG.  Connectivity and transmitting ECGs.

  • Page 25: System Description

    Supported print formats for the ELI 280 include: standard or Cabrera 3+1, 3+3, 6, 6+6, or 12 channel in automatic mode; 3, 6, or 12 channel rhythm strip printing. During rhythm strip printing the user can toggle between the various channels (default leads, limb and chest leads, etc.).

  • Page 26: System Illustration

    INTRODUCTION System Illustration Figure 1-1 Side View Figure 1-2 Writer Handle...

  • Page 27: Rear View

    INTRODUCTION Rear View Figure 1-3 AM12 ECG connector port USB device port USB connector port RJ45 LAN connector port Modem port WLAN antenna connector 100 – 240V power Base View Figure 1-4 Battery Compartment...

  • Page 28: Display Overview

    INTRODUCTION Display Overview The ELI 280 features a 10.1” diagonal LCD color display to preview the ECG waveform and other parameters as explained below. During ECG acquisition, notification messages will also appear on the display. Figure 1-5 Patient Name Speed, Gain and Filter...
  • Page 29 Administrator – the user has been authenticated on the network with their User Name and Password, and the user has been granted Administrator permissions. In addition to Technician permissions, this user may also change the ELI 280’s settings. Battery Indicator: An icon indicating battery charge status displays in the upper right corner.
  • Page 30 These configuration settings become the default setting at power up and for each ECG test unless customized for an individual patient. NOTE: If a format change has been made during a specific test the ELI 280 will return to its default setting for the next patient.

  • Page 31: Specifications

    40,000 s/sec/channel used for pacemaker spike detection; 1000 s/sec/channel used for recording and analysis Optional Functions Mortara VERITAS resting ECG interpretation algorithm with age and gender specific criteria; connectivity with bidirectional communication Perforated Z-fold thermal paper, Smart, A4 or 8.5 x 11” wide, 250...

  • Page 33: Accessories

    ARCHIVAL PAPER ELI 2XX A4 W/HDR CASE ARCHIVAL PAPER ELI 2XX A4 W/HDR CASE 9100-026-52 PAPER ELI 280 Smart Format CASE/12/250 ZFOLD (Spacer not included) ARCHIVAL PAPER ELI 2XX A4 W/HDR CASE 8342-007-02 PAPER TRAY SPACER: required for A4 and Smart paper use.
  • Page 34 POWER CORD CHINESE Manuals Part Number Description 9515-001-50-CD PHYSICIAN'S GUIDE ADULT & PEDIATRIC UM 9515-166-50-CD ELI LINK USER MANUALS 9515-181-51-CD BURDICK ELI 280 USER MANUALS 9516-181-51-ENG BURDICK ELI 280 SERVICE MANUAL Contact your dealer or go to www.burdick.com for more information.

  • Page 35: Equipment Preparation

    EQUIPMENT PREPARATION Initial Startup When powering ON the ELI 280 the system requires the user to set certain configurations prior to obtaining an ECG: Date and time (including daylight savings time selection). Language. AC filter frequency. Height/weight units of measure.

  • Page 36: Loading Paper

    Slide paper tray cover to the right until the cover latches in a locked position. You will hear a sharp click when the cover is properly latched. WARNING: Risk of injury to fingers in paper door or platen drive mechanisms. NOTE: For proper performance of thermal printer, be certain to use Buridck/Mortara/Quinton recommended thermal paper.
  • Page 37 EQUIPMENT PREPARATION Smart and A4 Paper Users To use Smart or A4 paper, please insert the paper tray spacer: Figure 2-3 Slide paper tray spacer towards rear wall of paper tray. Align the bottom four plastic arms with the four openings in the base of the paper tray.
  • Page 38 EQUIPMENT PREPARATION Figure 2-4 The paper tray spacer should be parallel with the rear wall of the paper tray. Figure 2-5 Gently press paper tray spacer in place. Gently press on the top three plastic arms to remove the paper tray spacer.

  • Page 39: Powering The Eli 280

    When line voltage is removed the device immediately switches to battery power. Operating on AC Power  Plug the power cord into an AC wall outlet and into the AC connector on the rear panel of the ELI 280. (Reference Figure 1-3.) ...

  • Page 40: Low Battery Failsafe Conditions

    The ELI 280 automatically turns off after 15 minutes in Stand-by mode when on battery power and no patient is connected. The ELI 280 also turns off when battery voltage becomes too low. The operator can force the ELI 280 to screen.

  • Page 41: Setting Date And Time

    Select Done to save and exit, or Cancel to exit without saving. Select Done again to return to the real-time display. Time Synchronization The SYNC feature allows time synchronization to occur only when the ELI 280 is interfaced to a product which supports ELI Link or E-Scribe. Select from the real-time display.

  • Page 42: Installing The Wlan Antenna

    To use the WAM, refer to the WAM user manual. To use the AM12, refer to the AM12 short-form instruction card. The ELI 280 must be configured at the factory for use with the WAM. If the ELI 280 is configured for use with the WAM, the two devices must be paired to function properly.

  • Page 43: Record An Ecg

    A good minimum-impedance pathway will provide superior noise-free waveforms. High quality silver-silver chloride (Ag/AgCl) electrodes similar to those provided by Mortara are recommended to be used. TIP: Electrodes should be stored in an air-tight container. Electrodes will dry out if not stored properly which will cause loss of adhesion and conductivity.
  • Page 44 RECORD AN ECG For accurate V-lead placement and monitoring, it is important to locate the 4 intercostal space. The 4 intercostal space is determined by first locating the 1 intercostal space. Because patients vary with respect to body shape, it is difficult to palpate the 1 intercostal space with accuracy.

  • Page 45: Patient Demographic Entry

    The patient demographic labels available are determined by the ID format selected from the configuration settings. In addition to short, standard, and long patient ID formats, the ELI 280 also supports a custom ID format. The custom ID format designed in ELI Link or E-Scribe can be downloaded to the ELI 280. Additional information about the custom ID can be found in ECG Directory or in the ELI Link and E-Scribe user manuals.
  • Page 46 Fill in any remaining fields. Touch Done to return to the real time display. NOTE: If ELI Link is configured for DICOM, the DICOM option must be installed on the ELI 280, and its Communication Protocol must be set for DICOM32 or DICOM32ext.
  • Page 47 When the barcode scanner is programmed to parse several demographic values from a barcode, the user may scan the barcode from the main screen. When a barcode is scanned from the main screen and the ELI 280 detects multiple lines of text, it automatically jumps to the patient demographics form and copies the values into the form.

  • Page 48: Ecg Acquisition And Printing With Wam Or Am12

    RECORD AN ECG ECG Display Setup – Individual ECG The Display Setup screen allows the user to set the following display configurations for an individual patient: display format, display speed, display (ECG) gain, and display (ECG) filter. Access these configuration choices by pressing anywhere on the touchscreen’s real-time ECG waveform.
  • Page 49 Low battery detected in the Replace the batteries in the WAM. Searching for WAM WAM not detected. WAM Check WAM proximity to the ELI 280; may be out of range, check WAM AA battery is new and powered OFF, depleted that the WAM is powered ON.
  • Page 50 RECORD AN ECG Press . The real-time ECG view is then replaced with the acquired ECG view. The default real-time ECG view is not available in the acquired ECG view for navigation purposes. NOTE: When Mandatory Fields are configured, and not populated at time of acquisition, and the “Done” button is selected, the user will be presented with a message requiring an acknowledgment prior to proceeding or exiting to home screen.

  • Page 51: Best 10 Seconds Of Ecg

    Configuring the ECG Report The ELI 280 can automatically print up to nine copies of the ECG report following acquisition. Print format, trace speed, ECG gain, ECG filter setting and pacer channel can be set as a default in the Configuration menu, or configured per ECG by touching the red grid screen display.

  • Page 52: Acquired Ecg Storage

    You can print a rhythm strip of the real-time ECG viewed on the display. Rhythm strips from the real-time ECG display can be acquired with the patient connected to the ELI 280 and after patient identification information is entered. A rhythm strip may also be printed without entering the patient ID by NOTE: Printed rhythm acquisitions are not stored in the ELI 280.

  • Page 53: Connectivity And Ecg Transmission

    NOTE: Telephone transmission is available with internal modem only. NOTE: In order to properly connect to telephone lines, the ELI 280 internal modem needs to be set on the proper country code. This is an internal setting and should not be confused with International calling codes.

  • Page 54: Internal Modem Connection

    Select Advanced. Select Modem. Connect an active telephone line cable to the telephone jack, located on the back of the ELI 280. Confirm the telephone number in the configuration settings. Internal Modem Initialization The modem initialization string code is configured for the country where the system was shipped. If the system is relocated to a different country the modem initialization string code will need to be reprogrammed.
  • Page 55 CONNECTIVITY AND ECG TRANSMISSION External Modem Country Code List Country Code Country Code Afghanistan Canary Islands Albania Cape Verde Algeria Cayman Islands American Samoa Central African Republic Andorra Chad Angola Chile Anguilla China Antigua and Barbuda Colombia Argentina Congo Armenia Congo, The Democratic Republic of the Aruba Cook Islands...
  • Page 56 CONNECTIVITY AND ECG TRANSMISSION Country Code Country Code Cambodia French Polynesia Cameroon Gabon Canada Gambia Georgia Korea, Republic of (South Korea) Germany Kyrgyzstan Ghana Lao People's Democratic Republic Gibraltar Latvia Greece Lebanon Greenland Liberia Grenada Libya Guadeloupe Liechtenstein Guam Lithuania Guatemala Luxembourg Guernsey, C.I.
  • Page 57 CONNECTIVITY AND ECG TRANSMISSION Country Code Country Code Niger Nicaragua Nigeria Swaziland Norway Sweden Oman Switzerland Pakistan Syrian Arab Republic Palestine Territory, Occupied Taiwan Panama Tajikistan Papua New Guinea Tanzania, United Republic of Paraguay Thailand Peru Thaiti Philippines Togo Poland Tonga Portugal Trinidad and Tobago...

  • Page 58: Local Area Network (Lan) Connection And Setup

    Ethernet Transmission Status Indicator LEDs The operator can monitor LAN interface connection and data transmission by observing the LEDs (Light Emitting Diodes) located at the system’s external connector. The LEDs can be viewed from the outside (rear) of the ELI 280. LED LOCATION...

  • Page 59: Wireless Local Area Network (Wlan) Connection And Setup

    To set up the ELI 280 for WLAN transmission: Select from the real-time display. Select Advanced. Select WLAN. Configure the ELI 280 for Dynamic Host Communication Protocol (DHCP) or static IP. Wireless security encryption options include:   WEP 128 ...

  • Page 60: Transmission Media Auto-Sync

    WEP Key ID NOTE: The range for the WEP key is 0-3. If the range on your access point is 1-4, then 0 at the ELI 280 maps to 1 on the access point; 1 maps to 2 on the access point, etc.

  • Page 61: Usb Connectivity

    CONNECTIVITY AND ECG TRANSMISSION USB Connectivity Transmission using the USB host port to a USB memory stick USB memory communication media permits storage of patient records to an external USB memory stick. The files will be saved in UNIPRO32 format for transfer to the E-Scribe or a compatible electronic information management system.
  • Page 62 When properly connected, the PC will automatically detect the device and automatically install the drivers.  You will be required to power the ELI 280 on by pressing the On/Off button for a period of three seconds. Transmitting Patient Records to ELI Link ...

  • Page 63: Ecg Directory

    ECG DIRECTORY ECG Directory The standard ECG directory saves up to 40 individual ECG records. The optional expanded memory permits up to 200 ECGs to be stored. To access the ECG directory, select from the real-time display, followed by Directory. Sort the directory by Name or ID by touching the header of choice.

  • Page 64: Reviewing Ecg Records

    ECG DIRECTORY Reviewing ECG Records To review an existing patient ECG record: Select from the real-time display, followed by Directory Navigate to the desired patient record, and select. Select the desired acquired ECG from the sub directory. Once selected the acquired ECG will display. To change the format of the acquired ECG touch the display and select the desired settings for Print Format, Print Speed, Print Gain, Print Filter and Pacer channel.

  • Page 65: Deleting Ecg Records

    Sort, navigate and/or search ECG Orders in the same manner as the ECG Directory. NOTE: Each time orders are downloaded the ELI 280 will automatically refresh the orders list. Orders that have been executed, canceled or deleted will be automatically eliminated.

  • Page 66: Searching Ecg Orders

    The number of pages, as well as the current page, displays to the left of the double arrows. NOTE: The ELI 280 will maintain the last selected queried location used in the search process to help expedite work flow.

  • Page 67: Mwl Query

    Once a query code is selected it will serve as the default query code for that particular ELI 280, or until a different selection is made. Select None to erase the last query code used.

  • Page 68: Patient Demographic Query (Pdq)

    Patient Demographic Query (PDQ) The ELI 280 can query the EMR for patient demographic information via HL7 A19 using the input of up to three demographic criteria (ID, First Name, Last Name, or any combination of the three fields) for those institutions performing unordered ECG tests, or do not have an interface to an electronic ordering system.

  • Page 69: System Settings

    WAM. the ELI 280  Change acquisition module to AM12. TEST WLAN Tests the strength of the radio frequency (RF) signal of the ELI 280 to the wireless network.  System Presents the following system setting Language ADVANCED ...
  • Page 70  Clear flags  Fill Directory  IIR On Print Prints the configuration of the ELI 280. Done Exits the utility and saves the setting. Returns to the previous menu screen Home Exits the menu. Returns to the real-time display...

  • Page 71: Device Passwords

    Administrator password in a location where it can be accessed during an emergency as well as in a backup location in case the primary location is compromised. The ELI 280 is preset with the case-sensitive Administrator password “admin.” To change the Administrator password, see Setting Passwords.

  • Page 72: Configuration Settings: About

    SYSTEM SETTINGS Configuration Settings: About Serial Number This indicator allows the user to see the serial number of the electrocardiograph. Software Version This indicator allows the user to see the software version of the electrocardiograph. Interp This selection allows the user to see whether automatic ECG interpretation is available on the device. Memory Capacity This indicator allows the user to see the storage capacity that the electrocardiograph currently possesses.

  • Page 73: Configuration Settings: Modem

    This indicator allows the user to see if a bar code scanner can be used with the device. Battery Voltage This indicator allows the user to see the ELI 280’s current battery voltage. Security This indicator allows the user to see if the Security features are enabled: ...

  • Page 74: Configuration Settings: System

    SYSTEM SETTINGS Configuration Settings: System Follow these steps to change the ELI 280 system settings: Select from the real-time display. (Enter password if required.) Select Advanced, followed by System. (A password is required to enter Advanced settings.) Make the appropriate configuration changes.
  • Page 75 MM/DD (month/day) or DD.MM (day.month) format. Cart Number This control allows the user to assign an ELI 280 with a cart number from 0 to 65535 in order to identify which device acquired or transmitted a particular ECG.
  • Page 76 ELI Link. NOTE: The LDAP or Active Directory domain for the user accounts and the security groups that are considered ELI technicians and administrators are configured in ELI Link and are not configured or stored on the ELI 280.

  • Page 77: Configuration Settings: Ecg

    Auto Log Off When user authentication is used, this setting specifies the number of minutes the ELI 280 may remain idle before it automatically logs the user off. The device is idle when there is no patient connected and the screen is off. The user may manually put the device into an idle state by lightly pressing the power button.
  • Page 78 SYSTEM SETTINGS NOTE: The plot-frequency filter does not filter the digitized signal acquired for interpretation of the ECG. NOTE: The Filter setting can also be changed for a single ECG by touching anywhere on the ECG waveform in the real-time or acquired view. Interp This selection allows the clinician to turn the ECG interpretation statements On/Off for presentation on the display and/or plotted report.
  • Page 79 Fridericia corrected QT value along with the default linear QTc value. ECG Capture Defines whether or not the ELI 280 will automatically display the Best 10 seconds of data acquired or the last 10 seconds of data acquired. NOTE: The ECG Capture Mode can also be changed for a single ECG by touching anywhere on the ECG waveform in the acquired view.
  • Page 80 Cabrera Defines whether or not the ELI 280 will automatically display the ECG in the Cabrera format. The Cabrera format displays the limb leads in the order aVL, I, -aVR, II, aVF, III, instead of the standard I, II, III, aVR, aVL, aVF, allowing a different presentation of waveform progression in the vertical plane.

  • Page 81: Configuration Settings: Lan

    SYSTEM SETTINGS Rhythm Formats This control allows the user to set the default values for rhythm printing. Set the default rhythm format to 3, 6, 8 or 12-channel printing. NOTE: The Rhythm Print Speed and Format can also be changed for a single ECG by touching anywhere on the ECG waveform in the real time view.

  • Page 82: Configuration Settings: Wlan

    This utility allows the IT professional to enter the sub net address (if DHCP is not selected). SSID Service Set Identifier (SSID) is the name of the wireless network. All ELI 280 electrocardiographs that will transmit to the same network must have the same SSID name. Touch the field to display the touchscreen keyboard.
  • Page 83 Select this mode when the WLAN uses EAP-TLS and client-side X.509 certificates to authenticate devices. Insert a USB flash memory stick into the back of the ELI 280 that contains the X.509 certificate. Touch the Certificates button to enter the Select Certificates screen. Select the appropriate certificates for the Root Certificate File, Private Key File, and Client Certificate File fields.

  • Page 84: Configuration Settings: Date/Time

    Configuration Settings: WAM Selecting WAM allows the clinician to switch between WAM or AM12 patient interface cables. For pairing of the WAM with the ELI 280, please refer to the WAM user manual. Configuration Settings: Service Please refer to the Service manual for definitions and assistance with the Service functions.

  • Page 85: Maintenance And Troubleshooting

    ECG data too noisy to store. directory. Correct noise and try acquisition/storage again. DHCP FAILURE The WLAN module failed to get Contact Mortara Technical Service. an address from DHCP. DPAC FAILURE WLAN failed to initialize. Contact Mortara Technical Service. CAN’T CONNECT TO ACCESS A link to the access point could Ensure the IP address is correct.
  • Page 86 CAN’T CONNECT TO REMOTE A link to the access point was Ensure the IP address is correct. If LINK established, but the link to the problem persists, contact Mortara destination failed. Technical Service. TIME SYNC FAULT Possible incorrect version of Install latest version.

  • Page 87: Touchscreen Troubleshooting Chart

    AC power switch is set to the On position, but the AC power on indicator light does not illuminate and the display is still dark, contact Mortara Technical Support . Electrocardiograph is in Press the On/Standby button to return to Standby Mode active use.

  • Page 88: Power Off The Device

    For information about replacing the battery, please refer to the device’s service manual. Mortara Instrument, Inc. and Burdick recommend that the device be plugged into AC power whenever possible to maximize battery life and for the user to develop a habit of recharging the battery before the unit indicates a “low battery”...

  • Page 89: Cleaning The Thermal Printer

    MAINTENANCE AND TROUBLSHOOTING Cleaning the Thermal Printer To clean the printer Disconnect the power source. Clean the exterior surface of the unit with a damp cloth using a solution of mild detergent diluted in water. After washing, thoroughly dry off the unit with a clean, soft cloth or paper towel. To clean the print head NOTE: Do not let soap or water come into contact with the writer, plugs, jacks, or vents.
