Genvex VANVEX R + Manual page 12

Parameter
Airflow
Nominal air flow rate (variable range)
Maximum fan power consumption
Max external static pressure
G - Air duct connections
Minimum volume of room installation
Operating limits
Max air temperature
Min air temperature
Max water temperature
Max water pressure
1.2.7. Fan Curve
Figure 7 – External static pressure vs airflow at different fan speeds.
In order to assure an efficient operation, it is suggested to keep the external pressure
drops below 200 Pa.
12
Unit 190L
m /h
3
W
Pa
mm
m
3
°C
°C
°C
MPa 0,6 or 1,0. Check nameplate
260L
450 (0-800)
85
200
160
30
40
-7
60
