8.1.6. IF Power Failure Detected
A statement containing this IF condition, will trigger if the power supplies to the 2.1mm DC jack power
connector on the Micro Commander is interrupted.
The user is able to specify a "Lockout Time" for this statement, which is the time that, after the
statement has triggered, it will not allowed to trigger again until this time has elapsed.
The user is also able to specify a "Hold Time" for this statement, which is the time that the trigger
condition must continuously be true before it will be allowed to trigger.
If the user selects a "Lockout Time" of zero, the statement will only trigger once (will trigger again when
the power is restored and fails again).
Please Note: To use this option, the user needs to have a 12V battery connected to the BATT terminals on
the Micro Commander. The Micro Commander will operate from the battery in the case of a power failure.
8.1.7. IF Power Restored
This trigger condition is the inverse of 8.1.6.
8.1.8. IF Battery Voltage < X
A statement containing this IF condition, will trigger if the battery voltage goes below a preset threshold
level.
The user is also able to specify a "Hold Time" for this statement, which is the time that the trigger
condition must continuously be true before it will be allowed to trigger.
The user is able to specify a "Lockout Time" for this statement, which is the time that, after the
statement has triggered, it will not allowed to trigger again until this time has elapsed.
If the user selects a "Lockout Time" of zero, the statement will only trigger once (will trigger again when
the voltage goes above and below "X").
Please Note: To use this option, the user needs to have a 12V battery connected to the BATT terminals on
the Micro Commander.
The Micro Commander will operate from the battery in the case of a power failure. While the Micro
Commander is powered, the battery will be trickle-charged by the Micro Commander. It is therefore
important to note that the battery level will only be checked while a power-failure is in progress.
8.1.9. IF Prepaid Airtime < X
A statement containing this IF condition, will trigger if the prepaid airtime goes below a preset threshold
level.
The user is able to specify a "Lockout Time" for this statement, which is the time that, after the
statement has triggered, it will not allowed to trigger again until this time has elapsed.
The Micro Commander will check the prepaid airtime balance from time to time, and the statement will
trigger if the balance is below the selected threshold.
Important: Under the "Settings" Tab in the configuration software, you need to have "DO NOT Check
Airtime" Unchecked, which is found in "Edit Settings". Also make sure that the correct network is
selected.
8.1.10. IF time elapsed > X
A statement containing this IF condition, will trigger every X seconds or minutes.
