5.12. Testing the Micro Commander

5.12.1. Status Request
The Micro Commander (even with a blank configuration) has a built-in test feature. If the Micro
Commander receives "TEST GSMC" as an SMS message, it will reply to the number that sent the
message, with the following text:
DT=01/01/2013-12:00:00 < Indicates current date & time of the Micro Commander
Sig=68%
Airt=35
FW=7.14
SN=140101-30225
PWR=On
Batt=13.2V
IN1= 0
OUT1 = 0
Please Note: The airtime remaining will be displayed as "Airt=???" if airtime checking has been
disabled or the incorrect network operator has been chosen in the current setup.

6. CONFIGURATION VIA PC

6.1. Basics
The following is required to configure the Micro Commander:
A PC running Windows XP / Vista / Windows 7 / Windows 8
➢
Setup utility installed on the PC
➢
USB cable
(Provided)
➢
Power supply
(See 5.2)
➢
Antenna
(See 5.5)
➢
SIM card(s)
(See 5.4)
➢
Please note: The Micro Commander will eventually startup if no SIM card is inserted, but there
would be no GSM functionality, which means none of the GSM features will work.
© Polygon Technologies. All rights reserved
< Indicates the received signal strength
< Indicates the amount of airtime remaining
< Indicates the firmware version
< Indicates the serial number
< Indicates status of mains power
< Indicates voltage of battery (if connected)
< Indicates status of inputs 1 and 2 (0 = active, 1 = inactive)
< Indicates status of outputs1 and 2 (0 = active, 1 = inactive)
(Available on the CD supplied with the product)
Page 15
