Polygon Technologies Micro Commander GC0101 User Manual page 16

Follow these steps:
Step 1:
Insert SIM card into unit
Step 2:
Connect Micro Commander to PC via the supplied USB cable
Step 3:
Connect power to the Micro Commander
Step 4:
Run the Utility (Start > All Programs > GSM Commander V7 0101 > Configure GSM Commander)
6.2. Software Tabs
The SmartSetup utility software has been designed to make the configuration process of the Micro
Commander as easy and user-friendly as possibly.
With this in mind the software has been divided into the following tabs:
Numbers
➢
Messages
➢
Behaviour Statements
➢
Settings
➢
IO Names
➢
Lock Setup
➢
Status
➢
© Polygon Technologies. All rights reserved
The software will show this screen when
started. Here you can select whether you
would prefer opening an existing setup from
a file on your PC, retrieve the setup
currently on the Micro Commander, just
open to the main screen or launch an older
version of the software.
Page 16
