Acrosser Technology AR-B1423 User Manual

AR-B1423 Manual
Version 1.01

1. SETTING UP THE SYSTEM

1.1 PACKING LIST

The quick setup manual
AR-B1423 CPU board
Hard disk drive interface cable
(2.0 mm pin pitch)
Floppy disk drive adapter cable
4-in-1 adapter cable forCOM1/COM2, parallel,
and VGA
PS/2 Y-type cable
Ethernet adapter cable
Power cable
Software utility CD
Screw kit
Page 1 of 4
1.2 PC/104 CONNECTOR
(1) 64 Pin PC/104 Connector Bus A & B (PC1)
1
2
60 Pin PC/104 Connector
PIN NO SIGNAL PIN NO
1 –IOCHCK 2
3 SD7 4
5 SD6 6
7 SD5 8
9 SD4 10
11 SD3 12
13 SD2 14
15 SD1 16
17 SD0 18
19 IOCHRDY 20
21 AEN 22
23 SA19 24
25 SA18 26
27 SA17 28
29 SA16 30
31 SA15 32
33 SA14 34
35 SA13 36
37 SA12 38
39 SA11 40
41 SA10 42
43 SA9 44
45 SA8 46
47 SA7 48
49 SA6 50
51 SA5 52
53 SA4 54
55 SA3 56
57 SA2 58
59 SA1 60
61 SA0 62
63 GND 64
(2) 40 Pin PC/104 Connector Bus C & D (PC1)
64
1
63
2
40 Pin PC/104 Connector
PIN NO
SIGNAL
1
GND
3
RSTDRV
5
VCC
7
IRQ9
9
Not Used
11
DREQ2
Not Used 13
–ZEROWS
15
(+12V)
17
GND
19
–SMEMW
21
–SMEMR
23
–IOW
25
–IOR
27
–DACK3
29
DREQ3
–DACK1 31
DREQ1
33
–REFRESH
35
SYSCLK
37
IRQ7
39
IRQ6
IRQ5
IRQ4
IRQ3
–DACK2
TC
BALE
VCC
OSC
GND
GND
39
40
SIGNAL PIN NO SIGNAL
GND 2 GND
–SBHE 4 –MEMCS16
LA23 6 –IOCS16
LA22 8 IRQ10
LA21 10 IRQ11
LA20 12 IRQ12
LA19 14 IRQ15
LA18 16 IRQ14
LA17 18 –DACK0
–MEMR 20 DREQ0
–MEMW 22 –DACK5
SD8 24 DREQ5
SD9 26 –DACK6
SD10 28 DREQ6
SD11 30 –DACK7
SD12 32 DREQ7
SD13 34 VCC
SD14 36 –RMASTER
SD15 38 GND
Not Used 40 GND
