- Page 1 AR-B1665 User’s Guide AR-B1665 Socket 370 Pentium III All -In-One EBX Board with Audio, LAN, CRT/LCD, and Mini-PCI User’ s Guide Edition: 1.02 Book Number: AR-B1665-05.0930...
- Page 2 AR-B1665 User’s Guide Table of Contents 0. PREFACE………………………………………………………………………………………………………………………… 3 0.1 COPYRIGHT NOTICE AND DISCLAIMER .............................3 0.2 WELCOME TO THE AR-B1665 CPU BOARD..........................3 0.3 BEFORE YOU USE THIS GUIDE ..............................3 0.4 RETURNING YOUR BOARD FOR SERVICE..........................3 0.5 TECHNICAL SUPPORT AND USER COMMENTS ........................3 0.6 STATIC ELECTRICITY PRECAUTIONS ............................4...
-
Page 3: Preface
0.3 BEFORE YOU USE THIS GUIDE Please refer to the Chapter 1, “Introduction” in this guide, if you have not already installed this AR-B1665. Check the packing list before you install and make sure the accessories are completely included. -
Page 4: Static Electricity Precautions
AR-B1665 User’s Guide 0.6 STATIC ELECTRICITY PRECAUTIONS Before removing the board from its anti-static bag, read this section about static electricity precautions. Static electricity is a constant danger to computer systems. The charge that can build up in your body may be more than sufficient to damage integrated circuits on any PC board. -
Page 5: Introduction
North Bridge. It provides internal AGP 4x performance along with 128-bit 2D Graphics Accelerator, 128-bit 3D Graphics Accelerator and DVD playback with MPEG-2 base. Based on all of the features above, AR-B1665 is an ideal solution for consumers that are looking for high speed performances with flexible option for further upgrade at a reasonable price. -
Page 6: Specifications
Power Consumption: +5VSB @0.3A, +5V@5A (Max), +3.3V@3.3A (Max), +12V@0.5A(Max) Operating Temperature: 0° ~ 60℃ (CPU needs Cooling Fan) 1.2 PACKING LIST In addition to this User's Manual, the AR-B1665 package includes the following items: The quick setup manual 1 AR-B1665 CPU board 1 Hard disk drive adapter cable for 3.5”... -
Page 7: Installation
AR-B1665 User’s Guide 2. INSTALLATION This chapter describes how to install the AR-B1665. At first, the layout of AR-B1665 is shown, and the unpacking information that you should be careful is described. The following lists the jumpers and switches setting for the AR-B1665’s configuration. -
Page 8: Installing The Cpu
AR-B1665 User’s Guide 2.2 INSTALLING THE CPU The AR-B1665 Embedded Board supports a Socket 370 processor socket for Intel Pentium III (FC-PGA/FC-PGA2) and Celeron processors. The Board uses a CPU socket called Socket 370 for easy CPU installation. The CPU should always have a Heat Sink and a cooling fan attached to prevent overheating. -
Page 9: Installing The Memory (Dimm)
AR-B1665 User’s Guide 2.3 INSTALLING THE MEMORY (DIMM) The AR-B1665 Embedded Board supports one 168-pin DIMM socket for a maximum total memory of 512MB in SDRAM type. The memory module capacities supported are 64MB, 128MB, 256MB, and 512MB. Installing and Removing DIMMs To install the DIMM, locate the memory slot on the Embedded Board and perform the following steps: Hold the DIMM so that the two keys of the DIMM align with those on the memory slot. -
Page 10: Connection
AR-B1665 User’s Guide 3. CONNECTION This chapter describes how to connect peripherals, switches and indicators to the AR-B1665 board. 3.1 AUDIO CONNECTOR (AUDIO) SIGNAL SIGNAL LINEOUTR LINEOUTL LINEINR LINEINL BIAS +12V 3.2 HARD DISK (IDE) CONNECTOR (IDE0, IDE1) • 40-Pin hard Disk Connector (IDE0) A 40-pin header type connector (IDE0) is provided to interface with up to two embedded hard disk drives (IDE AT bus). -
Page 11: Parallel Port Connector 1 (Lpt)
GROUND GROUND 3.3 PARALLEL PORT CONNECTOR 1 (LPT) This port is usually connected to a printer. The AR-B1665 includes an on-board parallel port, and accessed through a 26-pin flat-cable connector. Three modes –SPP, EPP and ECP – are supported. Signal... -
Page 12: Serial Ports
AR-B1665 User’s Guide 3.4 SERIAL PORTS • COM1 – COM4 VOLTAGE SELECT (SPJ3, SPJ4) SPJ3 3-5,4-6 :COM3,COM4 :12V(Factory Preset) 1-3,2-4 : 5V 3.5 SERIAL PORT CONNECTOR (COM1, COM2, COM4) Only RS232 1.D C D 6.C T S 2.D SR 7.D T R 3.R X... -
Page 13: Touch Screen Connector (Tsc)
3.12 INFRARED CONNECTOR (IR) The AR-B1665 built-in IrDA port which support Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface. When use the IrDA port have to set SIR or ASKIR model in the BIOS’s Peripheral Setup’s COM 2. Then the normal RS-232 COM 2 will be disabled. -
Page 14: Ethernet Lan Connector (Lan)
8.SPCLK 9.HSYNC 10.SPD 3.16 FLOPPY PORT CONNECTOR (FDD) The AR-B1665 provides a 34-pin header type connector for supporting up to two floppy disk drives. To enable or disable the floppy disk controller, please use the BIOS Setup program. Signal Signal... - Page 15 AR-B1665 User’s Guide Users could test GPIO function under ‘Debug’ program as follow: GPO Example： ;Extended Functions Enable Register o 4e 87 o 4e 87 ;Extended Functions Enable Register o 4e 29 ;select CR29 o 4f 80 ;(Define the PINs as GPIO or Game Port 1) "80"...
-
Page 16: Atx Power Connector (Atx)
AR-B1665 User’s Guide 3.18 ATX POWER CONNECTOR (ATX) 1. 3.3V 11. 3.3V 2. 3.3V 12. -12V 3. GND 13 GND 4. 5V 14 PS-ON 5. GND 15. GND 6. 5V 16. GND 7. GND 17. GND 8. PW-OK 18. –5V 9. -
Page 17: Panel Connector (Panel)
AR-B1665 User’s Guide 3.22 PANEL CONNECTOR (PANEL) POWER BUTTON POWER LED 5. GND 1. VCC 6. PWRBTN 3. PLED RESET BUTTON HARD DISK LED 7. GND 2. VCC 8. RSTSW 4. HD-LED EXTSMI 9. EXTSM# 10. GND 3.23 PCI SLOT (PCI 1) 3.24 MINI PCI SLOT (MPCI 2) -
Page 18: Watchdog Timer
4. WATCHDOG TIMER This section describes the use of Watchdog Timer. AR-B1665 is equipped with a programmable time-out period watchdog timer that enable user to reset the system after a time out occur. Users can use simple program to enable the watchdog timer, and program the timer in range of seconds or minutes, with maximum 255 seconds/minutes. -
Page 19: Bios Console
AR-B1665 User’s Guide 5. BIOS CONSOLE This chapter describes the AR-B1665 BIOS menu displays and explains how to perform common tasks needed to get up and running, and presents detailed explanations of the elements found in each of the BIOS menus. The... -
Page 20: Advanced
AR-B1665 User’s Guide Date & Time Setup Highlight the <Date> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the month, day and year format. Highlight the <Time> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the hour, minute and second format. - Page 21 AR-B1665 User’s Guide PS/2 Mouse Function The setting of Enabled allows the system to detect a PS/2 mouse on boot up. If detected, IRQ12 will be used for the PS/2 mouse. IRQ 12 will be reserved for expansion cards if a PS/2 mouse is not detected. Disabled will reserve IRQ12 for expansion cards and therefore the PS/2 mouse will not function.
-
Page 22: Peripherals
OnBoard Serial Port 3 OnBoard Serial Port 4 These options enable the serial port 1,2,3,and 4 on the AR-B1665 . UART Mode Select The item allows you to determine which InfraRed (IR) function of the onboard I/O chip, this function uses. -
Page 23: Boot
AR-B1665 User’s Guide 5.4 BOOT Boot System Thermal If set to Enable, the system will alarm when the system temperature is beyond the critical temperature. Thermal Active Temperature Set the critical temperature. Thermal Slow Clock Ratio This item is to set up the Operating Frequency of system clock in power saving mode, to set a suitable clock frequency ratio, which between standard CPU clock and CPU clock in power saving mode when the temperature is beyond the critical temperature. -
Page 24: Pc Health
AR-B1665 User’s Guide 5.5 PC HEALTH This section is used to configure power management features. This <Power management Setup> option allows you to reduce power consumption. This feature turns off the video display and shuts down the hard disk after a period of inactivity. -
Page 25: Exit
AR-B1665 User’s Guide 5.6 EXIT This section is used to configure peripheral features. Exit Save & Exit Setup Type “Y” will quit the Setup Utility and save the user setup value to RTC CMOS. Type “N” will return to Setup Utility. -
Page 26: Bios Update
The chips can be electronically reprogrammed, allowing you to upgrade your BIOS firmware without removing and installing chips. The AR-B1665 provides the FLASH BIOS update function for you to easily to update to a newer BIOS version. Please follow these operating steps to update to new BIOS: Step Turn on your system and don’t detect the CONFIG.SYS and AUTOEXEC.BAT files. -
Page 27: Appendix A. Address Mapping
AR-B1665 User’s Guide APPENDIX A. ADDRESS MAPPING IO Address Map I/O MAP ASSIGNMENT 000-01F DMA controller (Master) 020-021 Interrupt controller (Master) 022-023 Chipset controller registers I/O ports. 040-05F Timer control registers. 060-06F Keyboard interface controller 070-07F RTC ports & CMOS I/O ports... -
Page 28: Appendix B. Interrupt Request (Irq)
AR-B1665 User’s Guide APPENDIX B. INTERRUPT REQUEST (IRQ) SETTIN HARDWARE USING THE SETTING System timer Standard 101/102-Key or Microsoft Natural Keyboard Programmable interrupt controller Serial Port (COM2) Serial Port (COM1) IRQ Holder for PCI Steering Floppy Disk Controller Parallel Port (LPT1)
