AR-B1790 MANUAL
Version 1.01
1. SETTING UP THE SYSTEM
Page 1 of 6
1.1 PACKING LIST
The quick setup manual
AR-B1790 Embedded ATX Single Board
Software utility CD x 1
FDD Cable x 1 (Optional)
5.25" IDE HDD ATA100 Cable x 1 (Optional)
2.5" IDE HDD Cable x 1 (Optional)
Serial port Cable x 3 (Optional)
1.2 PS2 KEYBOARD & MOUSE (PS/1)
PS /1
12
11
PS2 M ouse
10
9
8
7
6
5
PS2 K eyBoard
4
3
2
1
1.3 PARALLEL & COM1 & VGA PORT (PT1)
13
25
PRINT
1
5
6
9
COM1
1.4 SERIAL PORT (COM2, COM3, COM4)
1
9
10
2
PIN
Signal
PIN
Signal
1
/DCD
2
3
RXD
4
5
TXD
6
7
/DTR
8
9
GND
10
VOLTAGE
AR-B1790 Manual
PIN
Signal
1
KBDATA
2
NC
3
GND
4
VCC
5
KBCLK
6
NC
7
MSDATA
8
NC
9
GND
10
VCC
11
MSCLK
12
NC
1
14
VGA
/DSR
/RTS
/CTS
/RI
COM
