- Page 1 User’s Guide AR-B1991 Pentium LGA775 High Performance 3D Gaming Motherboard Edition: 1.01 Book Number: AR-B1991-2007/1/5...
- Page 2 Pentium is a registered trademark of Intel Technologies, Inc. Award is registered trademarks of Award Software International, Inc. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies. AR-B1991...
-
Page 3: Table Of Contents
Specifications: ............... 5 What You Have ..............7 Installation .............. 8 System Board Layout............8 Jumper & Header DESCRIPTION ........10 Connection(AR-B1991)........12 Award BIOS Setup..........14 Introduction ................. 14 Starting Setup ..............14 Using Setup................. 15 Main Menu ................16 Advanced BIOS Features ........... - Page 4 User’s Guide 4.10 Boot…................. 26 4.11 Exit Selecting ..............27 AR-B1991...
-
Page 5: Introduction
User’s Guide Introduction 1.1 Specifications: CPU : Intel LGA775 CPU. Chipset : Intel 945G and ICH7. RAM memory : Two DDR2 DIMM Socket support to 2GB. Display Controller : Intel 945G Supports non-interlaced CRT monitors. IDE Interface : One 44pin 2.0mm IDE channel. Compact Flash interface : Supports Two Compact Flash Type II socket... - Page 6 Infineon TPM Management software enables the easy use of the most important trusted computing functions such as authentication,data integrity,system integrity,confidentiality,and availability. The detail of the TPM functions and installation please refer to following web- address and driver CD folder “Infineon TPM” http://www.infineon.com AR-B1991...
-
Page 7: What You Have
User’s Guide 1.2 What You Have In addition to this User's Manual, the board package includes the following items: System board (AR-B1991) User’s Manual Drive CD... -
Page 8: Installation
This chapter describes how to install system. At first, the layout of board is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the board configuration. 2.1 System Board Layout Top Placement AR-B1991... - Page 9 User’s Guide Bottom Placement...
-
Page 10: Jumper & Header Description
DESCRIPTION Short Master Open Slave DESCRIPTION Short Master Open Slave FPIO2 : HDD LED, Reset, PSON Connector. DESCRIPTION DESCRIPTION HDD LED+ HDD LED- RESET-(GND) PSON- (GND) RESET+ PSON+ FPUSB1 : USB4, 5(FPUSB1) Connector. DESCRIPTION DESCRIPTION DATA-(port4) DATA-(port5) DATA+(port4) DATA+(port5) AR-B1991... - Page 11 User’s Guide FAN1, 2, SYSFAN: Fan Connector. DESCRIPTION FAN+ (12V) FANSP CPUFAN: Fan Connector. DESCRIPTION FAN+ (12V) FANSP Control JP17 : Selection COM1 is RS232 or RS422/485 Default setting : 1-2 short JP17 DESCRIPTION RS232 3-4,5-6 RS422 RS485 JP14,JP15 : Selection COM1(CN16 pin 2,3 and pin 6,7) signals are RS232 or RS422/485.
-
Page 12: Connection(Ar-B1991)
User’s Guide Connection(AR-B1991) COM2 : RS-232 Serial port (2.0mmPin Header). DESCRIPTION DESCRIPTION SATA1,3 : Serial ATA Port . DESCRIPTION CN16 : COM1,COM3~6 Connector . AR-B1991... - Page 13 User’s Guide DESCRIPTION DESCRIPTION DCD1 DTR1 DSR1 RTS1 CTS1 DCD3 DTR3 DSR3 RTS3 CTS3 DCD4 DTR4 DSR4 RTS4 CTS4 DCD5 DTR5 DSR5 RTS5 CTS5 DCD6 DTR6 DSR6 RTS6 CTS6 Mouse, Keyboard, VGA, Line Out/In, Mic, Lan2(Giga port),Lan1(10/100Mb port), USB Connector.
-
Page 14: Award Bios Setup
<Ctrl>, <Alt>, and <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to... PRESS F1 TO CONTINUE, DEL TO ENTER SETUP AR-B1991... -
Page 15: Using Setup
User’s Guide 4.3 Using Setup In general, you can use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more details about how to navigate in the Setup program using the keyboard. -
Page 16: Main Menu
(described in Table 3) options IDE Slave Options are in its sub Press <Enter> to enter menu the sub menu of detailed (described in Table 3) options Halt On All Errors Select the situation in No Errors which you want the BIOS AR-B1991... - Page 17 User’s Guide All, but Keyboard stop POST All, but Diskette process and notify you All, but Disk/Key Base Memory Displays the amount of conventional memory detected during boot up Extended Memory Displays the amount of extended memory detected during boot up Total Memory Displays total...
- Page 18 Note that size this size is usually slightly greater than the size of a formatted disk given by a disk checking program. Access Mode Choose the access mode for this hard disk Large Auto Table 2 Hard disk selections AR-B1991...
-
Page 19: Advanced Bios Features
User’s Guide 4.5 Advanced BIOS Features This section allows you to configure your system for basic operation. Figure 3 Advanced menu Hyper-Threading Technology “Enabled” for Windows XP and Linux 2.4.x(OS optimized for Hyper Threading Technology )and “Disable” for other OS(OS not optimized for Hyper Threading Technology) Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up... - Page 20 DVMT Mode This item allows you to choise use fixed or dynamic share memory. Choice: Fixed, DVMT, BOTH DMVT/FIXED Memory Size This item is choise how many big size if you select DVMT Mode is Fixed. Choice: 64MB, 128MB, 224MB. AR-B1991...
-
Page 21: Pnp/Pci Configuration Setup
User’s Guide 4.6 PnP/PCI Configuration Setup ACPI Function This item allows you to enable or disable Advanced Configuration and Power Management ( ACPI) function. The Choice: Enabled, Disabled. ACPI Suspend Type This item allows you to Choose Suspend Type for ACPI function. The Choice: S1(Pos), S3(STR), S1 &... -
Page 22: Pnp/Pci Configuration Setup
This item allows you to determine the IRQ assigned to the ISA bus and is not available to any PCI slot. Legacy ISA for devices compliant with the original PC AT bus specification, PCI/ISA PnP for devices compliant with AR-B1991... -
Page 23: Peripheral
User’s Guide the Plug and Play standard whether designed for PCI or ISA bus architecture. The Choice: PCI Device, Reserved. 4.8 Peripheral Figure 5 Peripheral menu Onboard Serial Port 1/Port 2 Select an address and corresponding interrupt for the first and second serial ports. - Page 24 The Choice: Enabled, Disabled. OnBoard LAN2 Device The Choice: Enabled, Disabled. AC97 AUDIO The Choice: Auto, Disabled. OnChip IDE Device The item contain IDE Device and S-ATA Device. The Choice: Enabled, Disabled. AR-B1991...
-
Page 25: Pc Health
User’s Guide 4.9 PC Health Figure 5 H/W Monitor menu Show system information This item show the system all information to contain voltage, temperature and fan speed. - Page 26 Floppy ………. [ ] LS120 ………. [ ] Hard Disk …. [ ] CDROM … …….[ ] ZIP100 ………. [ ] USB-FDD .. …...[ ] USB-ZIP .. …...[ ] USB-CDROM .. [ ▪ On Board LAN …[ ] Disabled ….. ……[ ] AR-B1991...
- Page 27 User’s Guide 4.11 Exit Selecting Save & Exit Setup Load Optimized Defaults Exit Without Saving Load Fail-Save Default Figure 8 Exit menu Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y”...
- Page 28 When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N) ? N Pressing ‘Y’ loads the default values that are factory settings for Fail-Safe system operations. AR-B1991...
