OWNER'S MANUAL

Installation and Operation

Model:
830-0381
•
WARNING
If the information in these
instructions is not followed
exactly, a fire may result causing
property damage, personal injury,
or death.
• Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
• Do not overfire - If heater or chimney
connector glows, you are overfiring.
Overfiring will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
Installation and service of this appliance should
be performed by qualified personnel. Hearth &
Home Technologies recommends NFI certified
professionals, or technicians supervised by an
NFI certified professional.
www.quadrafire.com
3100-I ACT WOOD INSERT
Advanced Combustion Technology (ACT)
DO NOT DISCARD THIS MANUAL
• Read, understand and
Important operating
a n d m a i n t e n a n c e
instructions included.
CAUTION
follow these instructions
for safe installation and
operation.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in the same room
as appliance
• Alert children and adults to hazards of high
temperatures
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other
combustibles away.
250-6381D
R
Tested and
Listed by
OMNI- Test Laboratories, Inc.
• Leave this manual with
party responsible for
use and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate
poisonous gases (i.e. carbon monoxide).
Beaverton
Oregon USA
C
US
September 1, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3100-I and is the answer not in the manual?

Questions and answers

Related Manuals for Quadra-Fire 3100-I

Summary of Contents for Quadra-Fire 3100-I

  • Page 1: Installation And Operation

    Hearth & Home Technologies recommends NFI certified professionals, or technicians supervised by an NFI certified professional. www.quadrafire.com 3100-I ACT WOOD INSERT CAUTION DO NOT DISCARD THIS MANUAL • Read, understand and follow these instructions for safe installation and operation.
  • Page 2 Manufactured by / Fabriqué par: 1445 N. Highway, Colville, WA 99114 www.quadrafire.com Page  3100-I ACT WOOD INSERT and Welcome to the Quadra-Fire Family we are old-fashioned when it comes to craftsmanship. Each unit is meticulously fabricated and surfaces are hand-finished for last- ing beauty and enjoyment.

  • Page 3: Table Of Contents

    Fan Operating Instructions --------------------------------- 16 Ash Removal -------------------------------------------------- 16 Air Quality ------------------------------------------------------ 17 Air Controls, Primary and Start-up ----------------------- 17 September 1, 2008 3100-I ACT WOOD INSERT TABLE OF CONTENTS MAINTENANCE Plated Surfaces ----------------------------------------------- 18 Glass Cleaning & Replacement --------------------------- 18 Creosote Formation &...

  • Page 4: Dimensions

    TOP VIEW SIDE VIEW Panel Size 44-5/8” Large 50-1/2” Page 4 3100-I ACT WOOD INSERT INSERT DIMENSIONS 27-7/16" (697mm) 22-7/16" (570mm) 8-5/8" (219mm) 5-3/8" (137mm) 12-3/16" (310mm) 38-7/8" (987mm) 23-1/8" (587mm) 20-3/8" (518mm) 7-7//8" (00mm) 26-1/4" (667mm) 30-1/2” 34-1/2” 250-6381D 14-1/8"...

  • Page 5: United States And Canada

    September 1, 2008 3100-I ACT WOOD INSERT CLEARANCES TO COMBUSTIBLES United States and Canada Sidewall to Stove Mantel Clearances *No Mantel Shield with 5"...

  • Page 6: Installation Recommendations

    INSTALLATION RECOMMENDATIONS The Quadra-Fire 3100-I ACT insert has met and surpassed the most stringent emissions standards in the United States. sophistication of the interior firebox design requires that a proper draft be supplied by the chimney, therefore adherence to the follow- ing factors will enable your insert to operate at its optimum capabil- ity.

  • Page 7: General Installation Procedures

    Step (c): Compare proposed system R total of 1.231 to specified R of 0.893. Since proposed system R total is greater than required, the system is acceptable. )(hr)( September 1, 2008 3100-I ACT WOOD INSERT K-factor is given with a required thickness (T) in inches: r-factor is given with a required thickness (T) in inches: R = 1/8"...

  • Page 8: Chimney Requirements

    Page 8 3100-I ACT WOOD INSERT OVALIZING ROUND STAINLESS STEEL Ovalizing round stainless steel liners to acommodate the liner passing through the damper region of a fire- place is an allowable and acceptable practice.

  • Page 9: Installation Options

    Hearth Requirements on page 5 and Zero Clearance Adjustable Support Kit on page 14. MASONRY FIREPLACE USING DIRECT-CONNECT METHOD The Quadra-Fire 3100-I ACT Insert conforms with the UL Standard for Safety 1482 and ULC S628 (Canada) in all respects, and is approved to UL & ULC safety standards for installation and use within a fireplace with a masonry chimney in accordance with NFPA No.

  • Page 10: Factory Built Zero Clearance Fireplace

    FACTORY BUILT ZERO CLEARANCE FIREPLACE The Quadra-Fire 3100-I ACT Wood Stove Insert is listed to UL 1482 Standard and approved for installation into listed factory built zero clearance fireplaces listed to UL 127 con- forming to the following specifications and instructions:...

  • Page 11: Canadian Masonry & Heat Circulating

    Secure the liner with the supplied hex head bolts 1/4-20-3/4. NOTE: Tabs are shipped from factory in a flat position. Bend upwards 90 degrees. September 1, 2008 3100-I ACT WOOD INSERT INSTALLATION IN CANADA MASONRY and HEAT-CIRCULATING NOTE: In Canada when using a factory-built chimney it must be safety listed, Type UL 103 HT CLASS "A"...

  • Page 12: Panel & Trim Set

    6. Install locknut. Caution! Do not overtighten locknut. Door handle needs to move smoothly. 7. Install spring handle turning counter- clockwise to desired location on handle. Page 12 3100-I ACT WOOD INSERT Part No. Size SP-31S-NL 50-1/2” x 34-1/2” SP-31L-NL...

  • Page 13: Fan (Blower) Assembly

    9. Replace Screens. 10.Route power cord away from the unit. DO NOT route power under or in front of unit. September 1, 2008 3100-I ACT WOOD INSERT Part No. 831-1101 Strain Relief Location, Holding Together Power Cord and Fan Motor...

  • Page 14: Zero Clearance Adjustable Trim Support

    NOTE: 3/8” ( 9.5mm) thick tile or like material can be cut to size and fit under lip of top trim edge for a decora- tive touch. See Figure 14C. Page 14 3100-I ACT WOOD INSERT EXPLODED VIEW OF SCISSORS DOUBLE-SIDED TAPE EXPAND SCISSORS TO DESIRED HEIGH T INSTALL FRONT TRIM LAST.

  • Page 15: Operation

    We recommend that you open a window until the odor dissipates and the paint is cured. September 1, 2008 3100-I ACT WOOD INSERT OPERATION WOOD SELECTION AND STORAGE...

  • Page 16: Operating Tips

    If the ashes are disposed of by burial in soil or otherwise locally dispersed, they should be retained in the closed container until all cinders have thoroughly cooled. Always treat ashes as if they contain hot coals. Page 16 3100-I ACT WOOD INSERT OPERATING TIPS Primary Control Pull to Stop 1”...

  • Page 17: Air Quality

    Your 3100-I ACT, like any other appliance, must be properly operated in order to insure that they perform the way they are designed to perform. Improper operation and maintenance may cause any wood burning unit to release more particulate, adversely affecting the environment.

  • Page 18: Maintenance

    Reconnect the pipe and reinstall the insert following instal- lation instructions in this manual on page 9. Page 18 3100-I ACT WOOD INSERT MAINTENANCE CARE AND CLEANING OF GLASS WARNING! DO NOT OPERATE WITH BROKEN WARNING! DO NOT CLEAN GLASS WHEN HOT.

  • Page 19: Brick Replacement

    BRICK REPLACEMENT INSTRUCTIONS The firebox of your Quadra-Fire 3100-I ACT Insert is lined with high quality firebrick which has exceptional insulating proper- ties. There is no need for a grate, simply build a fire on the firebox of your insert.

  • Page 20: Exploded Views

    Item Trim Ring, Louver Manifold Tubes, Back (3) Manifold Tube, Front (1) Spring Handle, 1/4” (2) Blower Assembly Louver Assembly Page 0 3100-I ACT WOOD INSERT EXPLODED VIEW Description Item Screen, Left/Right (interchange- able) Speed Control Baffle, Fiberboard Blanket, Ceramic...

  • Page 21: Parts & Accessories Lists

    Spring Handle, Air Control, 1/4, Nickel Spring Handle, Door, 1/2”, Gold Spring Handle, Door, 1/2”, Nickel Trim Ring for Door, Gold Trim Ring for Door, Nickel September 1, 2008 3100-I ACT WOOD INSERT SERVICE PARTS Part Description Alphabetical Order 250-638D 831-1800...
  • Page 22 Panel Set, Large, Nickel, 34-1/2”h x 50-1/2”w Zero Clearance Adjustable Trim Support, 9” x 45”, 2”-10” high Zero Clearance Adjustable Trim Support, 12” x 50”, 2”-10” high Page  3100-I ACT WOOD INSERT Part Description Alphabetical Order Item Door Handle...

  • Page 23: Service & Maintenance Log

    3100-I ACT WOOD INSERT Service And Maintenance Log Date of Service Performed By Description of Service 250-638D Page 23 September 1, 2008...
  • Page 24 3100-I ACT WOOD INSERT Service And Maintenance Log (Cont’d) Date of Service Performed By Description of Service Page 4 250-6381D September 1, 2008...

  • Page 25: Homeowner's Notes

    3100-I ACT WOOD INSERT Homeowner’s Notes 250-638D Page 5 September 1, 2008...

  • Page 26: Warranty Policy

     Noise resulting from minor expansion, contraction, or movement of certain parts is normal and complaints related to this noise are not covered by this warranty. 4021-645A 09-01-08 Page 26 3100-I ACT WOOD INSERT Wood Pellet Electric Wood...
  • Page 27 If warranty service is needed, you should contact your installing dealer. If the installing dealer is unable to provide neces- sary parts or components, contact the nearest authorized HHT dealer or supplier. 4021-645A 09-01-08 September 1, 2008 3100-I ACT WOOD INSERT 250-638D Page 7...

  • Page 28: Contact Information

    • Read, understand and follow these instruci- tons for safe installation and operation. • Leave this manual with party responsible for use and operation. Your Records for Model: 3100-I ACT Wood Insert DEALERSHIP ______________________________________ _______________________________________ _______________________________________ DEALER TELEPHONE:...
