Mounting

• Drive components are sensitive to electrostatic discharge. Avoid
direct contact with the circuit board. Hold the drive by the heat sink
only.
• Protect the drive from dirt, moisture, and accidental contact.
• Provide sufficient room for access to the terminals and calibration
trim pots.
• Mount the drive away from heat sources. Operate the drive within
the specified ambient operating temperature range.
• Prevent loose connections by avoiding excessive vibration of the
drive.
• Mount the drive with its board in either a horizontal or vertical
plane. Eight 0.19" (5 mm) wide slots in the chassis accept #8 pan
head screws. Fasten either the large base or the narrow flange of the
chassis to the subplate.
• The chassis should be earth grounded. Use a star washer beneath
the head of at least one of the mounting screws to penetrate the
anodized surface and to reach bare metal.
