Minarik Electric Company
Masters of Control
Installation and Connection Guide
Models MM21036A and MM22036A
Speed Controls for Dancer Pot Applications
These controls are designed for applications that call for dancer
pot control. They feature electronic adjustment of offset and
span, to replace the cumbersome linkage adjustment common
to installations of this type.
Specifications
Drive
Line voltage (-5% + 10%)
Line frequency
Line current, maximum
Horsepower
Armature output
Armature current, maximum
Ambient temperature range
Approximate weight
* Maximum horsepower = 1 and maximum armature current = 10A
when mounted on a suitable heatsink, e.g., Minarik Kit Number
223-0156.
** Maximum horsepower = 2 and maximum armature current = 10A
when mounted on a suitable heatsink, e.g., Minarik Kit Number
223-0156.
MM21036A/MM22036A INSTALLATION GUIDE
MM21036A
115 VAC
50/60 Hz
8A
1/8-1/2*
0-90 VDC
5 ADC*
10° C - 55° C
0.5 lb
Glendale, CA 91201
MM22036A
230 VAC
50/60 Hz
8A
1/2-1**
0-180 VDC
5 ADC**
10° C - 55° C
0.5 lb
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MM21036A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Minarik MM21036A

  • Page 1 0.5 lb 0.5 lb * Maximum horsepower = 1 and maximum armature current = 10A when mounted on a suitable heatsink, e.g., Minarik Kit Number 223-0156. ** Maximum horsepower = 2 and maximum armature current = 10A when mounted on a suitable heatsink, e.g., Minarik Kit Number...
  • Page 2 MM21036A/MM22036A INSTALLATION GUIDE Wiring instructions Refer to Figure 1 (page 3) for an illustration of all connections. Motor connections Connect the motor armature to Terminals A1 and A2. If using a shunt-wound field motor, connect the field to Terminals Fl and F2;...
  • Page 3 MM21036A/MM22036A INSTALLATION GUIDE NOTES 1. DO NOT CONNECT FIELD OUTPUT IF USING A PERMANENT MAGNET MOTOR. 2. DO NOT ADD A LINE FUSE TO L2 UNLESS LINE VOLTAGE IS 230 VAC. Figure 1. MM21036A/MM22036A Connections...
  • Page 4 The control is factory calibrated with OFFSET at 0° and SPAN at 300°. The MAX SPD trimpot is adjusted to 85V DC (MM21036A) and 170V DC (MM22036A), at no load. Calibrate the drive using the following procedure: Set the MIN SPD and OFFSET trimpots to zero (full CCW).
  • Page 5: Minimum Speed (Min Spd)

    MM21036A/MM22036A INSTALLATION GUIDE OFFSET OFFSET sets the dancer pot wiper position at which the motor begins to run. This is expressed as the angle of the wiper relative to its fully CCW position. With these controls, the of- fset of the wiper may be set as high as 290° before the motor will run.
  • Page 6: Maximum Speed (Max Spd)

    MM21036A/MM22036A INSTALLATION GUIDE SPAN SPAN is the angle through which the dancer pot wiper must rotate to cover the full speed range that the application requires. The motor will not increase speed at any setting past this angle. The minimum span of the wiper to obtain rated output from these controls is 10°.
  • Page 7 MM21036A/MM22036A INSTALLATION GUIDE To calibrate IR COMP (exact calibration): Turn the IR COMP trimpot full CCW. Set the dancer potentiometer until the motor runs at midspeed without load (for example, 900 RPM for an 1800 RPM motor) A hand held tachometer may be used to measure motor speed.
  • Page 8: Torque Limit (Torque)

    Although TORQUE is set to 120% of maximum drive current rating, continuous operation beyond that rating may damage the motor. If you intend to operate beyond the rating, contact your Minarik representative for assistance. The TORQUE setting determines the maximum torque for accelerating and driving the motor.
  • Page 9 MM21036A/MM22036A INSTALLATION GUIDE Set the dancer potentiometer to the OFFSET position. Remove power from the drive. Remove the lock from the motor shaft. 10. Remove the ammeter in series with the motor armature. The control is now calibrated.
  • Page 10 MM21036A/MM22036A INSTALLATION GUIDE Notes...
  • Page 11 MM21036A/MM22036A INSTALLATION GUIDE Notes...
  • Page 12 MM21036A/MM22036A INSTALLATION GUIDE 901 East Thompson Avenue Glendale, California 91201-2011 Tel.: 1-800-MINARIK (646-2745) Fax: 1-800-394-6334 www.minarikcorp.com Document Number 250-0103, Revision 2 Printed in the U.S.A – 6/01 U.S.A. $10.00, Outside U.S.A. $11.00...
