MM23071A-0862
Connection Guide
This Guide assumes that the user has installed the
MM23071A-0862 drive per user's manual 250-0091.
This installation must be completed before connecting
and operating the drive. Refer to User's Manual
250-0091, MM20000 Series Drives, for detailed
installation, operation and troubleshooting information.
Connections
Warning
Do not connect this equipment with power applied.
Failure to heed this directive may result in fire or serious
injury.
Minarik strongly recommends the installation of a
master power switch in the voltage input line, as shown
in Figure 1 (page 3). The switch contacts should be rated
at a minimum of 200% of motor nameplate current and
250 volts.
Power and line fusing connections
• Use 18-24 AWG wire for speed adjust potentiometer
wiring. Use 14–16 AWG wire for AC line (L1 and L2)
and motor (A1 and A2) wiring. Use 18 AWG wire for
field (F1 and F2) wire.
MM23071A-0862 Installation Guide
1
Advertisement
Table of Contents
Related Manuals for Minarik MM23071A-0862
Summary of Contents for Minarik MM23071A-0862
- Page 1 MM23071A-0862 Installation Guide MM23071A-0862 Connection Guide This Guide assumes that the user has installed the MM23071A-0862 drive per user’s manual 250-0091. This installation must be completed before connecting and operating the drive. Refer to User’s Manual 250-0091, MM20000 Series Drives, for detailed installation, operation and troubleshooting information.
- Page 2 MM23071A-0862 Installation Guide Line fusing Each MM23071A-0862 is shipped from the factory with two 10A fast blow fuses preinstalled. External line fuses are not required. Replacement fuses, p/n 050-0013, are available from Minarik. Power connections Warning Dynamic braking, inhibit operation and decelerating to a stop (shorting S1 to S2) may not stop a drive that is malfunctioning.
- Page 3 MM23071A-0862 Installation Guide LINE FUSE LINE FUSE Figure 1. Power and Line Fusing Connections...
- Page 4 (L1, L2, F1, F2, A1, A2). Motor connections Minarik drives supply motor voltage from A1 and A2 terminals. It is assumed throughout this manual that, when A1 is positive with respect to A2 , the motor will rotate clockwise (CW) while looking at the output shaft protruding from the front of the motor.
- Page 5 MM23071A-0862 Installation Guide Connect a DC motor to PCB terminals A1 and A2 as shown in Figure 2 (page 6). Ensure that the motor voltage rating is consistent with the drive’s output voltage. Field output connections Warning The field output is for shunt wound motors only. Do not make any connections to F1 and F2 when using a permanent magnet motor.
- Page 6 MM23071A-0862 Installation Guide NOTES: 1. POWER CONNECTIONS OMITTED FOR CLARITY. REFER TO FIGURE 1 ON PAGE 3 FOR POWER CONNECTIONS. 2. REFER TO TABLE 1 ON PAGE 5 FOR ALTERNATE FIELD CONNECTIONS. DO NOT CONNECT FIELD OUTPUT IF USING PERMANENT MAGNET MOTOR.
- Page 7 MM23071A-0862 Installation Guide Operation Refer to User’s Manual 250-0091 for detailed operating information. Before applying power • Verify that no conductive material is present on the printed circuit board. • Ensure that voltage select switch SW501 and armature voltage select switch SW502 are set to the proper positions.
- Page 8 MM23071A-0862 Installation Guide Warranty information This product is covered by Minarik’s unconditional warranty. Refer to User’s Manual 250-0091 or contact your Minarik representative for more information. 901 East Thompson Avenue Glendale, California 91201-2011 Tel: (800) MINARIK (646-2745) Fax: (800) 394-6334 www.minarikcorp.com...
