MMBOSS05-24DC-1Q
Quick Start Guide
This Quick Start Guide is intended for customers who are familiar
with installing and operating the MMBOSS series drive. For
calibration, troubleshooting and application notes information,
refer to document number 250-0288, the MMBOSS User's
Manual.

Connections

Warning
Do not install, remove, or rewire this equipment with power
applied. Failure to heed this directive may result in fire or
serious injury.
Do not reverse power input leads or apply reverse voltage at
the drive terminals. The drive will be damaged.
Minarik strongly recommends the installation of a master
power switch in the voltage input line, as shown in Figure 1.
The switch contacts should be rated at a minimum of
200% of motor nameplate current.
Motor
Connect a three-phase, low-voltage brushless motor to PCB
terminals U, V and W, as shown in Figure 1. Connect motor
phase A (or phase 1) to drive terminal U. Connect motor phase
B (or phase 2) to drive terminal V. Connect motor phase C
(or phase 3) to drive terminal W.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMBOSS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Minarik MMBOSS Series

Summary of Contents for Minarik MMBOSS Series

  • Page 1 MMBOSS05-24DC-1Q Quick Start Guide This Quick Start Guide is intended for customers who are familiar with installing and operating the MMBOSS series drive. For calibration, troubleshooting and application notes information, refer to document number 250-0288, the MMBOSS User’s Manual. Connections...
  • Page 2 Connect the DC input power leads to PCB terminals BUS+ and BUS-. Connect the positive (+ or high) lead to BUS+. Connect the negative (- or common) lead to BUS-. Minarik strongly recommends a master power switch for emergency use.
  • Page 3 MMBOSS QUICK START GUIDE TO MOTOR PHASE A PHASE B PHASE C DC VOLTAGE (PHASE 1) (PHASE 2) (PHASE 3) INPUT STOP SWITCH FUSE BUS+ Q501 C501 SW502 60/120 SW501 IL502 IL501 R501 PWR ON FAULT C502 TB502 BUS- MAX SPD GAIN MIN SPD CURRENT LIMIT BRAKE...
  • Page 4 MMBOSS QUICK START GUIDE BRAKE HALL B V REF ENABLE HALL C HALL A BUS+ Q501 C501 SW502 60/120 SW501 IL502 IL501 R501 PWR ON FAULT C502 TB502 BUS- MAX SPD GAIN MIN SPD CURRENT LIMIT BRAKE HALL_B V_REF TB501 ENABLE HALL_C HALL_A...
  • Page 5 MMBOSS QUICK START GUIDE Optional switch connections Connect the following switches to the terminal plug as shown in Figure 3 (page 6). ENABLE/DISABLE switch Install a single-pole, single-throw switch between the ENABLE and COM terminals (Figure 3). Close the switch to disable the drive and coast the motor to a stop.
  • Page 6 MMBOSS QUICK START GUIDE BRAKE ENABLE HALL C ENABLE / DISABLE SWITCH OPEN TO RUN CLOSE TO DISABLE RUN/BRAKE SWITCH CLOSE TO RUN OPEN TO BRAKE C C W DIRECTION SWITCH CLOSE TO CHANGE DIRECTION 10K OHM SPEED ADJUST POTENTIOMETER Figure 3.
  • Page 7 MMBOSS QUICK START GUIDE Operation Before applying power: • Verify that no conductive material is present on the printed circuit board. • Ensure that all jumpers are properly set. Startup 1. Verify that no conductive material is present on the PCB. 2.
  • Page 8 To coast the motor to a stop, remove power to the drive. You may also close the ENABLE/DISABLE switch to coast to a stop. Copyright © 2001 Minarik Corp. 901 E. Thompson Ave. Glendale CA USA 91201-2011 All rights reserved. Document number 250-0314, revision 2. Printed in USA 4/01...
