ADJ 18P HEX IP User Instruction Manual page 21

18P Hex IP
Slave Setting - With this function you can set the unit as a "Slave" in Master-Slave configuration.
1. Plug the fixture in and press the MODE button and press the UP or DOWN buttons until
"Slave" is displayed, and press ENTER.
2. The unit is now set as a "Slave" in a Master-Slave configuration.
Manual Control - With this function you can manually adjust all colors to make your own desired
color.
1. Plug the fixture in and press the MODE button and press the UP or DOWN buttons until
"Menu Manual" is displayed, and press ENTER.
2. Press the UP or DOWN buttons to scroll through dimmer, the 6 colors, and strobe. Press ENTER
and use the UP and DOWN buttons to make adjustments.
3. Once you have made your desired adjustments, press ENTER.
18P Hex IP
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave set-up. In a Master-Slave
set up one unit will act as the controlling unit and the others will react to the controlling units built-in
programs. Any unit can act as a Master or as a Slave however, only one unit can be programmed to
act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR data
cables to link your units together. Remember that the Male XLR connector is the input and the
Female XLR connector is the ouput. The first unit in the chain (master) will use the female XLR
connector only. The last unit in the chain will use the male XLR connector only.
2. Connect the first "Slave" unit to the "Master."
3. Set the "Master" unit to your desired mode of operation. On the "Slave" unit's press the MODE
button and use the UP or DOWN buttons until "Menu Slave" is displayed and press ENTER.
ADJ Products, LLC - www.adj.com - 18P Hex IP User Manual Page 20
Operating Instructions
Master-Slave Configuration
