Connecting DS60 shelves

DD6300 with DS60 cabling

The cabling diagrams in this section show maximum configurations. Not all systems
will have all the disk shelves shown in the diagrams.
Add shelf-to-shelf cables between shelves in a loop and to the controller as shown in
the diagrams.
DS60 cable information
When connecting DS60 shelves, the same cable type connects a controller to a DS60
shelf, or a DS60 shelf to a DS60 shelf.
Table 4 DS60 cables
HD-mini-SAS connector on controller and enclosure
Cable model code
XC-DS60-SAS-3M
XC-DS60-SAS-4M
XC-DS60-SAS-5M
Table 5 DD6300 with DS60 cabling instructions
String I/O - Port
(Loop)
1 I/O 7 - Port 0
1 I/O 7 - Port 1
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Part number
038-004-380-01
038-000-212-00
038-000-214-00
Shelf Port
A controller port 0 of the DS60.
B controller port 0 of the DS60.
Connect Cables and Power On
Cable length
3 m (118 in)
4 m (158 in)
5 m (196 in)
Length
2M
2M

Connecting DS60 shelves

a
27
