ScanGauge Overview

Package Contents
• ScanGauge
• 6ft OBDII Cable
Front
A
B
Back
Function/Selection Button
A.
Function/Selection Button
B.
Function/Selection Button
C.
Function/Selection Button
D.
E. HOME Button
LCD Display Screen
F.
OBDII Connection Plug
G.
Optional OBDII Connection Plug
H.
• Velcro Strips
®
• User Manual
G
The function buttons are used to make
selections and to navigate the menu
system of the ScanGauge.
Use the HOME Button to quickly get
back to the Home Screen
Displays the information the
ScanGauge records
Primary OBDII connector
Secondary OBDII connector
• Quick Start Guide
C
D
E
F
Side
H
5
Overview
