I N S T R U CT I O N M A N UA L
S200 Series
C E N T R I F U G A L P U M P
F O R M N O . : 9 5 - 0 3 0 8 0
R E V I S I O N : 1 2 / 2 0 1 0
R E A D A N D U N D E R S TA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT.

Advertisement

Table of Contents
loading

Related Manuals for SPX S2045

Summary of Contents for SPX S2045

  • Page 1 I N S T R U CT I O N M A N UA L S200 Series C E N T R I F U G A L P U M P F O R M N O . : 9 5 - 0 3 0 8 0 R E V I S I O N : 1 2 / 2 0 1 0 R E A D A N D U N D E R S TA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT.
  • Page 3 Copyright © 2005, 2010 SPX Corporation. without notice and does not represent a commitment on the All Rights Reserved. part of SPX Corporation. No part of this manual may be reproduced or transmitted in any form or by any means, Revision Date: 12/2010...

  • Page 4: Table Of Contents

    Table of Contents Waukesha Cherry-Burrell Warranty ..................... 6 Shipping Damage or Loss ................6 Warranty Claim ...................6 Safety ......................7 Care of Stainless Steel ................8 Stainless Steel Corrosion ................8 Elastomer Seal Replacement Following Passivation ........8 Introduction ....................9 Factory Inspection ..................9 Receiving Your Pump .................9 Receiving and Inspection ..............9 Pump Characteristics ..................10...
  • Page 5 Complete Seal Kit - Type 4 Seal - Sanitary Pump Model ....50 Class VI Elastomer Kits ..............51 Motor Shaft Shims ..................51 Seal Components All Pumps ...............52 S2045 Components (Close Coupled) ............54 S2065/S2065LV/S2065HV Components (Close Coupled) ......56 S2075 Components (Close Coupled) ............58 S2085/2085LV Components (Close Coupled) ..........60 S2092 Components (Close Coupled) ............62...

  • Page 6: Warranty

    Warranty Waukesha Cherry-Burrell Warranty Seller warrants its products to be free from defect in materials and workmanship for a period of one (1) year from the date of shipment. This warranty shall not apply to products which require repair or replacement due to normal wear and tear or to products which are subjected to accident, misuse or improper mainte- nance.

  • Page 7: Safety

    Waukesha Cherry-Burrell Safety Safety READ AND UNDERSTAND THIS MANUAL PRIOR TO INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT We recommend users of our equipment and designs follow the latest Industrial Safety Standards. At a mini- mum, these should include the industrial safety requirements established by: 1.

  • Page 8: Care Of Stainless Steel

    Care of Stainless Steel Waukesha Cherry-Burrell Care of Stainless Steel Stainless Steel Corrosion Corrosion resistance is greatest when a layer of oxide film is formed on the surface of stainless steel. If film is disturbed or destroyed, stainless steel becomes much less resistant to corro- sion and may rust, pit or crack.

  • Page 9: Introduction

    Waukesha Cherry-Burrell Introduction Introduction Factory Inspection Each Waukesha pump is shipped completely assembled, lubri- cated and ready for use. (Make sure you review “Operation” on page 27 before operating your pump). Receiving Your Pump All ports are covered at the factory to keep out foreign objects during transit.

  • Page 10: Pump Characteristics

    Introduction Waukesha Cherry-Burrell Pump Characteristics The Waukesha S200 Series Pump is built for extremely durable service. The casing, backplate, and impeller/stub shaft are machined from 316L stainless steel for extra strength and resis- tance to line shock and corrosion. Large bearings and shaft pro- vide positive alignment and minimize vibration.

  • Page 11: Motor Adapter

    Waukesha Cherry-Burrell Introduction Motor Adapter • Made of epoxy-coated cast iron • Used to mount a standard NEMA C-face motor onto bearing housing • Used to provide an accurate, rigid shaft alignment • Used in style "B" arrangements Stand • The stand (pedestal) is made of epoxy-coated cast iron.
  • Page 12 Introduction Waukesha Cherry-Burrell Figure 5 - Common Part Identification Table 3: Callout Table for Figure 5 A. Motor Shims L. Tabbed Washer B. Slinger M. O-ring C. L-gasket N. Rotary Seal D. Stationary Seal P. Stationary Seal E. Rotary Seal R.

  • Page 13: Performance Characteristics

    Waukesha Cherry-Burrell Introduction Performance Authorization Characteristics 3A/USDA (Sanitary Models) Standard Construction • Casing: 316L Stainless Steel • Port Connections: S-Line • Backplate: 316L Stainless Steel • Impeller W/Integral Shaft: 316L Stainless Steel • Impeller Retainer: 316L Stainless Steel • Shaft Seal: Single Mechanical, externally-balanced (Type 1) •...

  • Page 14: Operating Parameters

    Introduction Waukesha Cherry-Burrell Elastomers EPDM (FDA approved) Silicone (FDA approved) Teflon Encapsulated (FDA approved) FFKM Finishes/Product Contact Surfaces 15RA 20RA Electropolish Leg Kit See “Motor Mounts” on page 72. Base Mounting Footed C-face motors T-Frame motors. Note: T-Frame motors can be configured with or without bases, couplings or coupling covers.
  • Page 15 Inlet Size Outlet Size Maximum Capacity Model inch (mm) inch (mm) GPM (M3/HR) 1.5 (40) 1.5 (40) 190 GPM (43) S2045 2.0 (50) 1.5 (40) 190 GPM (43) 1.5 (40) 1.5 (40) 195 GPM (44) S2065LV 2.0 (50) 1.5 (40) 195 GPM (44) 2.5 (65)
  • Page 16 2.5 (63) 14.61 (371) NOTE: Figure 6 dimensions for the Inlet, Outlet, items X,Y, and Z are listed in Table 7 on page 17. Table 5: Table of Dimensions for Figure 6, page 15 PUMP SIZE S2045 S2065 S2065LV S2065HV FRAME...
  • Page 17 (mm) inch (mm) inch (mm) inch (mm) 1.5 (38) 1.5 (38) 3.88 (99) 2.56 (65) 1.99 (51) 4.08 (104) S2045 2.0 (51) 1.5 (40) 3.88 (99) 2.56 (65) 1.99 (51) 4.08 (104) S2065 2.5 (64) 2.0 (51) 4.94 (125) 2.68 (68)
  • Page 18 Introduction Waukesha Cherry-Burrell Figure 7 - Style "B" and "C" Less Base Plate Table 8: Table of Dimensions for Figure 7 Inlet Outlet Model inch (mm) inch (mm) Sm Bore Lg Bore Sm Bore Lg Bore inch (mm) inch (mm) inch(mm) inch (mm) 1.5 (40)
  • Page 19 Waukesha Cherry-Burrell Introduction Table 9: Table of Base Size Used on Pedestal-Mounted Centrifugal Pumps Sanitary and Industrial Models Motor HP & RPM PS2065/ PS2045 PS2065LV PS2075 PS2085LV PS2085 PS2092 PS2065HV Up to 5 HP 1750 RPM SM.B. SM.B. SM.B. SM.B. SM.B.
  • Page 20 Introduction Waukesha Cherry-Burrell Figure 8 - Base Channel Dimensions for Pedestal Mounted Centrifugal Pumps Baseplates are available in carbon steel channel base, carbon steel baseplate with feet or stainless steel base- plate with feet. Centrifugal S200 Series Pump and Pedestal Weights Table 10: Base Channel Dimensions for Figure 8 Carbon Steel Carbon Steel...
  • Page 21 Waukesha Cherry-Burrell Introduction Figure 9 - Close Coupled Pump Table 11: Close Coupled Pump (Less Motor and Legs) Pump Model Motor Frame S2045 S2065LV S2065 S2065HV S2075 S2085LV S2085 S2092 lbs (kg) lbs (kg) lbs (kg) lbs (kg) lbs (kg)
  • Page 22 Introduction Waukesha Cherry-Burrell Figure 11 - Pedestal Pump (Less Base and Motor) Table 13: Pedestal Pump (Less Base and Motor) Pump Model S2045 S2065LV S2065 S2065HV S2075 S2085LV S2085 S2092 PEDESTAL llbs (kg) (kg) (kg) (kg) (kg) (kg) (kg) (kg)

  • Page 23: Installation

    Waukesha Cherry-Burrell Installation Installation Unpack all parts of your equipment and inspect for damages that may have occurred during shipping. Report any damage to the carrier. All ports are covered at the factory to keep out foreign objects during transit. If the covers are missing or damaged, remove the pump cover and thoroughly inspect the fluid head.
  • Page 24 Installation Waukesha Cherry-Burrell 5. The pump casing may be rotated with the discharge connec- tion pointing in any direction. The best pump performance will be with the outlet up, to the left, or positions in between; these positions ensure a flooded casing and prevent prob- lems due to air in the system.

  • Page 25: Installations That May Cause Operation Problems

    Waukesha Cherry-Burrell Installation 12. This pump is not self priming. If the pump is installed above the supply liquid level, install a foot valve or other system check valve to keep the system flooded for priming. (Figure 18, item A). 13.

  • Page 26: Flush Seal Option

    Installation Waukesha Cherry-Burrell Flush Seal Option When this option is ordered, a fitting assembly (Figure 20, item A) is supplied for directing a flow of water onto the backplate/seal area. • The water cascade block must be above the seal on the assembled backplate to flow water onto the seal face.

  • Page 27: Cleaning Safety Procedures

    Waukesha Cherry-Burrell Installation Cleaning Safety Manual Cleaning Procedures Address the following considerations when manually cleaning your pump: 1. Do not use toxic and/or flammable solvents. 2. Lock out electrical power and shut off all air prior to cleaning the equipment. WARNING: To prevent an acci- 3.

  • Page 28: Operation

    Operation Waukesha Cherry-Burrell Operation Before proceeding, make sure your pump has been correctly installed as described in “Installation” on page 23. Starting the Pump 1. If pump has a flush seal option, start the flow of flush water (approximately 5 US gallons per hour recommended rate) before operating the pump.

  • Page 29: Priming The Pump With The Feed Source Below Pump Level

    Waukesha Cherry-Burrell Operation Priming the Pump With the Feed Source Below Pump Level The pump will not self-prime if the liquid supply is below the pump level. When the liquid supply is below the pump level, an outside source must be provided for priming. 1.

  • Page 30: Maintenance

    Maintenance Waukesha Cherry-Burrell Maintenance Scheduled Maintenance A routine maintenance program can extend the life of your pump. Make sure to keep maintenance records. These records will help pinpoint potential problems and causes. Routine Maintenance Your scheduled routine maintenance should include the following items: •...
  • Page 31 Waukesha Cherry-Burrell Maintenance 3. Locate shims on the motor shaft and remove them. NOTE: Motor shaft shims may fall off the motor shaft or hang up inside the deflector. Be sure to place all shims back on the motor shaft. CAUTION: Handle the impeller/backplate assembly with care to prevent damage to seal components.

  • Page 32: Inspect Parts

    Maintenance Waukesha Cherry-Burrell 10. Remove four 1/4" hex bolts and stationary seat retainer ring. (See Figure 28, items A and B). 11. Pull the stationary seal and L-gasket out of the backplate. (See Figure 28, items C and D). NOTE: The stationary seal is brittle. Prying or hammering on the seal plate can shatter the seal.

  • Page 33: Pump Assembly With Type 1 Seal

    Waukesha Cherry-Burrell Maintenance Pump Assembly with Type Backplate Assembly 1 Seal 1. Lightly lubricate both sides of the L-gasket (Figure 30, item D) with a sanitary lubricant and insert into the backplate seal cavity. 2. Place the stationary seal into the L-gasket. (See Figure 30, items C and D).
  • Page 34 Maintenance Waukesha Cherry-Burrell 10. If your system has a water cascade, thread the water cas- cade hose through the guard and install the cascade block on the backplate (See Figure 33, items A and B). 11. Slide the motor shims onto the shaft. Use the same number of shims that were removed when the pump was disassem- bled.

  • Page 35: Pump Disassembly With Type 4 Double Seal

    Waukesha Cherry-Burrell Maintenance Pump Disassembly with The Type 4 Seal is essentially two Type 1 seals assembled back Type 4 Double Seal to back in a chamber which bolts to the backplate in place of the stationary seat retainer. Except for the additional components, (e.g.

  • Page 36: Removal Of The Water Cascade

    Maintenance Waukesha Cherry-Burrell Removal of the Water Cascade If your system is equipped with a water cascade system, remove it before proceeding: 1. Loosen the socket head screws holding the water cascade block on the stationary seat retainer and remove the plastic hose.
  • Page 37 Waukesha Cherry-Burrell Maintenance 8. Use the backplate to slide the rotary seal up the impeller shaft approximately 1-1/2 inches. See Figure 39. Figure 39 - Moving the Rotary Seal up the Shaft 9. With the backplate resting on the impeller, push the rotary seal toward the backplate until the o-ring is free.

  • Page 38: Pump Assembly With Type 4 Double Seal

    Maintenance Waukesha Cherry-Burrell Pump Assembly with Type 4 Double Seal Figure 41 - Type 4 Seal Components Table 16: Callouts for Figure 41 A. Impeller F. O-ring L. Rotary Seal S. Stationary Seal B. Backplate G. Washer M. O-ring T. L-gasket C.
  • Page 39 Waukesha Cherry-Burrell Maintenance 6. Temporarily put 0.03" shims between the impeller vane and back plate to preset clearance. Be sure to remove shims before final assembly. See Figure 42. Figure 42 - Place Shims Between Impeller and Backplate 7. Place the o-ring (Figure 41, item F) on the shaft and use a spring retainer to push o-ring into the rotary seal.
  • Page 40 Maintenance Waukesha Cherry-Burrell 20. Install the original shims on the motor adapter shaft. 21. Install the backplate with the seal assembly and impeller on the motor shaft. 22. Check the impeller/backplate clearance with the backplate held firmly in position against motor adapter. Check the space between the back of the impeller and the backplate with a feeler gauge (.030 nominal) while holding the back- plate tight against the bearing housing flange.

  • Page 41: Disassembly Of Modular Base Mounted Pumps

    Waukesha Cherry-Burrell Maintenance Disassembly of Modular Refer to see “Pump Disassembly with Type 1 Seal” on page 30 Base Mounted Pumps and “Pump Disassembly with Type 4 Double Seal” on page 35 for information on disassembling the pump seal items. 1.

  • Page 42: Disassembling The Outer Seal Assemblies

    Maintenance Waukesha Cherry-Burrell Disassembling The Outer Seal Assemblies 1. Using a 1/8" hex wrench, loosen the set screws (Figure 50, item A). NOTE: The set screws are located opposite the grease fittings in the adapter or end cap. 2. Remove the impeller end of the bearing housing. (Figure 50, item B).

  • Page 43: Pre-Assembled (Cartridge) Seals

    Waukesha Cherry-Burrell Maintenance Pre-assembled (Cartridge) Pre-assembled (Cartridge) seals have all the seal components Seals mounted to a flange, and are pre-adjusted at the factory. Follow the seal manufacturer's (John Crane, A. W. Chesterton, etc.) rec- ommendations regarding application, operation, and mainte- nance.

  • Page 44: Assembly Of A Pump With Pre-Assembled (Cartridge) Seals

    Maintenance Waukesha Cherry-Burrell Assembly of a Pump With Pre-assembled (Cartridge) Seals 1. Place the shims, backplate and impeller on the shaft assem- bly. Hand tighten the impeller retainer bolt on the shaft. 2. Check the impeller/backplate clearance with the backplate held firmly in position against the motor adapter.
  • Page 45 Waukesha Cherry-Burrell Maintenance 11. Install the impeller key. (Figure 60, item A). 12. Install the o-ring on the impeller retainer bolt. (Figure 60, item 13. Install the impeller retainer nut and tighten. (Figure 60, item Figure 60 - Installing Impeller Assembly 14.

  • Page 46: Pedestal Base Mounted Pump Housing Lubrication

    Maintenance Waukesha Cherry-Burrell Pedestal Base Mounted Waukesha Series S200 Pedestal Pumps are lubricated with NLGI Pump Housing Lubrication grade 2 Lithium Complex Grease. Use only NLGI grade 2 Lithium Complex thickened greases to replenish the bearing grease sup- ply. The location of the grease fittings is indicated in Figure 63. NOTE: Mixing greases that will not mix with the above products can change the viscosity/consistency of the grease resulting in bearing damage.

  • Page 47: Standard Seal Dimensions

    Waukesha Cherry-Burrell Maintenance Standard Seal Dimensions Figure 64 - Installed Seal Length (For Aid of Assembly) 12/2010 95-03080 Page 47...

  • Page 48: Cartridge Seal Dimensions

    Maintenance Waukesha Cherry-Burrell Cartridge Seal Dimensions The following pictorial list of cartridge seals is provided to assist in identifying some of the seals provided with the Model S200 centrifugal pumps. Use of these cartridges requires a cartridge seal adapter. Figure 65 - Installed Cartridge Seal A.

  • Page 49: Parts Lists

    Waukesha Cherry-Burrell Parts Lists Parts Lists Seal Kits Basic Seal Kit - Type 1 Seal - Sanitary Pump Model MODEL KIT CONTAINS S2045 S2065* S2075 S2085* S2092 CARBON SEAL (FKM & EPDM) 9-225A 9-225A 9-225A 9-225A 9-225A SEAL O-RING (FKM)

  • Page 50: Basic Seal Kit - Type 4 Seal - Sanitary Pump Model

    Parts Lists Waukesha Cherry-Burrell Basic Seal Kit - Type 4 Seal - Sanitary Pump Model MODEL KIT CONTAINS S2045 S2065* S2075 S2085* S2092 CARBON SEAL (FKM & EPDM) 9-225A 9-225A 9-225A 9-225A 9-225A SEAL O-RING (FKM) V70224 V70224 V70224 V70224...

  • Page 51: Class Vi Elastomer Kits

    Waukesha Cherry-Burrell Parts Lists Class VI Elastomer Kits SINGLE DOUBLE MODEL EPDM EPDM S2045 118023 118069 118028 118074 S2065 118024 118070 118029 118075 S2075 118025 118071 118030 118076 S2085 118025 118071 118030 118076 S2092 118026 118072 118031 118077 **Class VI Elastomers are only sold as kits**...

  • Page 52: Seal Components All Pumps

    Parts Lists Waukesha Cherry-Burrell Seal Components All Pumps Page 52 95-03080 12/2010...
  • Page 53 Waukesha Cherry-Burrell Parts Lists Seal Components All Pumps TYPE 1/1C TYPE 4 DESCRIPTION ITEM # PART # SEAL QTY SEAL QTY Deflector 69-1 Stationary Seal Purbide (1.75") 23-17 Silicone Carbide (1.75") 23-17A Ceramic (1.75") 23-17E Tungsten Carbide (1.75") 23-17F Seal Retainer 23-78 1/4 -20 x 1/2"...

  • Page 54: S2045 Components (Close Coupled)

    Parts Lists Waukesha Cherry-Burrell S2045 Components (Close Coupled) DESCRIPTION ITEM # 20RA 15RA 15RA EP 20RA EP S2045 1515 Solid Bar Casing S-Line CENTPT00501 CENTPT00015 CENTPT00014 CENTPT00016 Buttweld CENTPT00502 CENTPT00018 CENTPT00017 CENTPT00019 150# Flange CENTPT00503 CENTPT00021 CENTPT00020 CENTPT00022 DIN CENTPT00504...
  • Page 55 Waukesha Cherry-Burrell Parts Lists S2045 Components (Close Coupled) DESCRIPTION ITEM # PART # O-ring V70214 EPDM E70214 FFKM T80214 Adapter, motor 2-235 Seal guard (Type 1 Seal) 70-27 3/8-16 x 3/4" Hex screw 30-30X 3/8" Lock washer 43-28 O-ring V70252...

  • Page 56: S2065/S2065Lv/S2065Hv Components (Close Coupled)

    Parts Lists Waukesha Cherry-Burrell S2065/S2065LV/S2065HV Components (Close Coupled) DESCRIPTION ITEM # 20RA 15RA 15RA EP 20RA EP S2065LV 1515 Solid Bar Casing S-Line CENTPT00483 CENTPT00039 CENTPT00038 CENTPT00040 Buttweld CENTPT00509 CENTPT00042 CENTPT00041 CENTPT00043 150# Flange CENTPT00510 CENTPT00045 CENTPT00044 CENTPT00046 DIN CENTPT00511 CENTPT00048 CENTPT00047 CENTPT00049...
  • Page 57 Waukesha Cherry-Burrell Parts Lists S2065/S2065LV/S2065HV Components (Close Coupled) DESCRIPTION ITEM # PART # V70220 EPDM E70220 O-ring Silicone S75220 FFKM K75220 143-184JM Motor Frame 2-168 213-215JM Motor Frame 2-169 Adapter 254-256JM Motor Frame 2-170 284-326JM Motor Frame 2-196 143-215 Motors 70-23 Seal Guard (Type 1 Seal) 254-256 Motors...

  • Page 58: S2075 Components (Close Coupled)

    Parts Lists Waukesha Cherry-Burrell S2075 Components (Close Coupled) ITEM # DESCRIPTION 20RA 15RA 15RA EP 20RA EP S2075 3015 Solid Bar Casing S-Line CENTPT00487 CENTPT00486 CENTPT00485 CENTPT00488 Buttweld CENTPT00687 CENTPT00688 CENTPT00689 CENTPT00690 150# Flange CENTPT00691 CENTPT00692 CENTPT00693 CENTPT00694 DIN CENTPT00695 CENTPT00696 CENTPT00697 CENTPT00698...
  • Page 59 Waukesha Cherry-Burrell Parts Lists S2075 Components (Close Coupled) DESCRIPTION ITEM # PART # O-ring V70220 EPDM E70220 Silicone S75220 FFKM K75220 Adapter 143-184JM Motor Fram e 2-171 213-215JM Motor Fram e 2-172 254-256JM Motor Fram e 2-173 284JM and Larger Motor Fram e 2-174 Seal Guard 143-215JM Motors...

  • Page 60: S2085/2085Lv Components (Close Coupled)

    Parts Lists Waukesha Cherry-Burrell S2085/2085LV Components (Close Coupled) DESCRIPTION ITEM # 20RA 15RA 15RA EP 20RA EP S2085LV 2015 Solid Bar Casing S-Line CENTPT00300 CENTPT00087 CENTPT00086 CENTPT00088 Buttweld CENTPT00523 CENTPT00090 CENTPT00089 CENTPT00091 150# Flange CENTPT00524 CENTPT00093 CENTPT00092 CENTPT00094 DIN CENTPT00525 CENTPT00096 CENTPT00095 CENTPT00097 S2085 3025 Solid Bar Casing S-Line CENTPT00526 CENTPT00099 CENTPT00098 CENTPT00100 Buttweld CENTPT00527 CENTPT00102 CENTPT00101 CENTPT00103...
  • Page 61 Waukesha Cherry-Burrell Parts Lists S2085/2085LV Components (Close Coupled) DESCRIPTION ITEM # PART # O-ring V70220 EPDM E70220 Silicone S75220 FFKM K75220 Adapter 143-184JM Motor Frame 2-171 213-215JM Motor Frame 2-172 254-256JM Motor Frame 2-173 284JM and Larger Motor Frame 2-174 Seal Guard 143-215JM Motors 70-23...

  • Page 62: S2092 Components (Close Coupled)

    Parts Lists Waukesha Cherry-Burrell S2092 Components (Close Coupled) DESCRIPTION ITEM # 20RA 15RA 15RA EP 20RA EP S2092 3020 Solid Bar Casing S-Line CENTPT00534 CENTPT00123 CENTPT00122 CENTPT00124 Buttweld CENTPT00535 CENTPT00126 CENTPT00125 CENTPT00127 150# Flange CENTPT00536 CENTPT00129 CENTPT00128 CENTPT00130 DIN CENTPT00537 CENTPT00132 CENTPT00131 CENTPT00133...
  • Page 63 Waukesha Cherry-Burrell Parts Lists S2092 Components (Close Coupled) DESCRIPTION ITEM # PART # O-ring V70220 EPDM E70220 Silicone S75220 FFKM K75220 Adapter 143-184JM Motor Frame 2-171 213-215JM Motor Frame 2-172 254-256JM Motor Frame 2-173 284JM and Larger Motor Frame 2-174 Seal Guard 143-215JM Motors 70-23...

  • Page 64: Pedestal Mounted Pumps - Small Bore

    Parts Lists Waukesha Cherry-Burrell Pedestal Mounted Pumps - Small Bore Page 64 95-03080 12/2010...
  • Page 65 Waukesha Cherry-Burrell Parts Lists Pedestal Mounted Pumps - Small Bore DESCRIPTION ITEM # STYLE MOTOR PART # Bearing housing S2045 68-6 S2065 68-7 S2075-S2085-S2092 68-8 Shaft 62-528X Bearing 6309 23-101 Bearing 6209 23-100 Retaining ring 43-139 Seal outer 23-90 Seal inner...
  • Page 66 Parts Lists Waukesha Cherry-Burrell Pedestal Mounted Pumps - Small Bore, cont’d Page 66 95-03080 12/2010...
  • Page 67 Waukesha Cherry-Burrell Parts Lists Pedestal Mounted Pumps - Small Bore, cont’d DESCRIPTION ITEM # STYLE MOTOR PART # 1.0 4J 11-95 1.0 5S 143/184 11-94 Coupling half 1.0 6S 213/215 33217 1.0 7S 254/256 33222 3/8-16 x 1" 56/145 30-30X 1/2-13 x 1"...

  • Page 68: Pedestal Mounted Pumps - Large Bore

    Parts Lists Waukesha Cherry-Burrell Pedestal Mounted Pumps - Large Bore Page 68 95-03080 12/2010...
  • Page 69 Waukesha Cherry-Burrell Parts Lists Pedestal Mounted Pumps - Large Bore DESCRIPTION ITEM # STYLE MOTOR PART # Bearing housing S2065 68-9 S2075-S2085-S2092 68-10 Shaft 62-539X Bearing 5311 23-98 Retaining ring 43-138 Seal outer 23-95 Seal inner motor end 23-94 Seal inner motor impeller end 23-93 035 O-ring inner N70035...
  • Page 70 Parts Lists Waukesha Cherry-Burrell Pedestal Mounted Pumps - Large Bore, cont’d Page 70 95-03080 12/2010...
  • Page 71 Waukesha Cherry-Burrell Parts Lists Pedestal Mounted Pumps Large - Bore, cont’d DESCRIPTION ITEM # STYLE MOTOR PART # 1.375 6S 213-215 33220+ 1.625 7S 254-256 33227+ 1.875 7S 284/286 33229+ Coupling half 2.125 8S 324-326 33237+ 2.375 8S 11-107 2.375 8S 11-107 6JES 213/215...

  • Page 72: Motor Mounts

    Parts Lists Waukesha Cherry-Burrell Motor Mounts Leg Kits 143-145JM 110256+ 182-184JM 110255+ 213-215JM 110254+ 254-256JM 110253+ 284-286JM 110252+ 324-326JM 110251+ Page 72 95-03080 12/2010...

  • Page 73: Troubleshooting

    Waukesha Cherry-Burrell Troubleshooting Troubleshooting PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Pump not primed Prime pump. Install a priming system if Not Enough Liquid Delivered possible. Suction or discharge plugged or Open suction. If plugged, shut down pump closed and remove blockage. Air leak in supply or at seal area Check system for air leaks and repair as necessary.
  • Page 74 Troubleshooting Waukesha Cherry-Burrell PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Motor Overload Faulty electrical connections Check wiring and repair/replace as necessary. Unrestricted discharge resulting in Add discharge restriction to lower flow rate. too high a flow rate Impeller interference Disassemble pump and inspect for damage. Remove interference if still present.
  • Page 75 Waukesha Cherry-Burrell Troubleshooting PROBLEM POSSIBLE CAUSE SUGGESTED ACTION Vibration/Noise Starved suction/supply line too Shorten system supply line. long Starved suction/supply line too Install larger supply lines. small Excessive air in material Adjust system to remove excess air from material before it reaches the pump. Rapid Seal Wear Incorrect impeller shaft location;...
  • Page 76 Troubleshooting Waukesha Cherry-Burrell Notes Page 76 95-03080 12/2010...
  • Page 78 P: (262) 728-1900 or (800) 252-5200 F: (262) 728-4904 or (800) 252-5012 E: wcb@spx.com SPX reserves the right to incorporate our latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing.
