Ubee UBC1303AB00
DOCSIS 3.1
Advanced Wireless Voice Gateway
Firmware Version: 1.4.2101.S15
Subscriber User Guide
June 2017
www.ubeeinteractive.com
Polarisavenue 77
2132 Hoofddorp
The Netherlands
Sales (email): eusales@ubeeinteractive.com
Support (email): eusupport@ubeeinteractive.com

Advertisement

Table of Contents
loading

Related Manuals for Ubee UBC1303

Summary of Contents for Ubee UBC1303

  • Page 1 Ubee UBC1303AB00 DOCSIS 3.1 Advanced Wireless Voice Gateway Firmware Version: 1.4.2101.S15 Subscriber User Guide June 2017 www.ubeeinteractive.com Polarisavenue 77 2132 Hoofddorp The Netherlands Sales (email): eusales@ubeeinteractive.com Support (email): eusupport@ubeeinteractive.com...
  • Page 2 United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to Ubee), except in accordance with applicable agreements, contracts, or licensing, without the express written consent of Ubee and the business management owner of the material.

  • Page 3: Table Of Contents

    Table of Contents 1 Introduction ..........1 1.1 Understanding Safety and Regulatory Information .
  • Page 4 2.2.3 Connecting a Telephone Line ........18 2.3 Troubleshooting the Installation .
  • Page 5 6.2.2 Using the DHCPv6 Option ......... . . 44 6.2.3 Using the DHCP Lease Option .
  • Page 6 6.6.3 Using the Factory Default Option ........83 6.6.4 Using the Client List Option .

  • Page 7: Introduction

    Introduction Welcome to the Ubee family of data networking products. This guide is specific to the UBC1303AB00 Advanced Wireless Voice Gateway for Service Provider subscribers and serves the following purposes:  Provides instructions on how to install, connect, and operate the UBC1303AB00 ...

  • Page 8: Understanding Eco-Environmental Statements

    Gateway meets the requirements for compliance in relation to the following directives:  2002/95/EC (The RoHS Directive) restricting the use of hazardous substances in all Electrical and Electric Equipment. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 9  EN 301 489-17  EN 50385  EN 50160  EN 55022  EN 55024  EN 55032  EN 61000-2-4  EN 61000-3-2  EN 61000-3-3  EN 60950-1 Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 10: Understanding Connections And Applications

    The package for the UBC1303AB00 contains the following items: Item Description 1 - RJ45 Cable (Ethernet Cat 6 UTP) Length ~ 1.5m Sample image, actual appearance subject to change. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 11 Desktop + AC power cord, standard EU plug Sample image, actual appearance subject to change. 1 - External Power Supply Unit Output: 12VDC / 3.5A, 42 Watts Sample image, actual appearance subject to change. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 12: Understanding The Device Panels, Connections And Leds

    The following images represent the UBC1303AB00 front and rear panels. Connection descriptions are provided in section 1.5.2., and LED descriptions are provided in section 1.5.3. Front Panel Rear Panel Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 13: Understanding The Device Connections

    Description USB Port USB 3.0 host port to support Linux applications for Ubee and 3rd party applications. Restores the settings of the device including wireless and custom gateway settings. Use a pointed object to push down the reset button. The device reboots if the RESET button RESET is pushed for less than 5 seconds.
  • Page 14 UBC1303AB00 using RJ-45 cables. Each ETHERNET Orange Ethernet port on the back panel of the device has an LED to indicate its status when an Ethernet device is connected. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 15: Understanding Specifications, Standards, And Firmware

     Frequency Range: 5MHz ~ 85MHz/204MHz switchable  Modulation: QPSK or 8/16/32/64/128 QAM and OFDMA: 4096QAM  Maximum EuroDOCSIS 3.1 Data Rate: 2x96MHz OFDMA channels provide capacity up to 2Gbps @ 4096 QAM Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 16  DTMF tone relay (RFC2833)  Caller ID basic and extended CLASS features  Voice Active Detection  Packet Tone Generation (e.g. DTMF, call progress tones)  Modem support Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 17: Understanding Default Values And Logins

     Storage Temperature: -20°C ~ 70°C  Humidity: 5~95% (non-condensing) Understanding Default Values and Logins The UBC1303AB00 is pre-configured with the default parameters for your Service Provider. Local Port Address: 192.168.100.1 Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 18  Standard Web User Interface Login  Username: admin  Password: random password, 8 characters in length (case sensitive). The password can be found on the device label. Example password = nxmtukrq Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 19: Understanding The Device Label

    H/W Version Displays the internal version number that identifies the hardware design. Made in Displays the country in which the device was assembled. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 20: Installing The Ubc1303Ab00

     Place the device in a location that has an operating temperature of 0˚C to ~ 40˚C. Refer to Understanding Safety and Regulatory Information on page 1 for more safety information. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 21: Wall Mount Installation

    2.6 +/- 0.15 19.0 +/- 1.2 To mount the UBC1303AB00 on a wall: 1. Install the two screws horizontally on a wall 140mm apart. See the figure below. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 22: Connecting Devices To The Network

    3. Open a Web browser and go to any Web site to validate network/Internet connectivity (for example, http://www.wikipedia.org). 4. If the connected device is a gaming console, perform any online task supported by the Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 23: Connecting A Wireless Device

    It will revert to this default when a factory reset is performed through the Web UI. See Using the Factory Default Option on page Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 24: Connecting A Telephone Line

    3. Make a phone call and/or have someone call you to verify a successful connection. Troubleshooting the Installation Use the following tips to troubleshoot the installation.  None of the LEDs are on when I power on the UBC1303AB00. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 25  Try a different cable. The Ethernet cable may be damaged.  If none of these suggestions work, contact your service provider for further assistance. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 26: Using The Web User Interface

    1. Launch an Internet browser, such as Internet Explorer, from your computer. 2. Enter the following IP address in the address bar of the browser window and press the Enter key. http://192.168.100.1 The following screen is displayed. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 27 Password: random password (8 characters in length, found on the device label) After logging in, the Cable Modem Information (CM Info) Status screen displays device information about the UBC1303AB00. For screen field descriptions, Using the Status Option on page Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 28: Logging Out Of The Web User Interface

    After logging out, you are returned to the login screen, where you can log back into the device by clicking ‘Please click here to login.’ See the example below: Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 29 Ubee Interactive Logging Out of the Web User Interface Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 30: Understanding The Cable Modem Menu

     Using the Event Log Option on page 29 4.1.1 Using the Status Option The Status option displays the device’s software version, uptime, CM MAC and IP addresses. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 31 Defines the unique manufacturer serial number of the device. CM certificate Indicates if the cable modem certificate is installed. Status System Up Time Displays how long the device has been connected. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 32: Using The Connection Option

    (upstream channels). To view connection information: 1. Click CM Info from the left side menu. 2. Click Connection under CM Info. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 33 Ubee Interactive Using the CM Info Option Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 34 CM Downstream Channel Info Channel Numbers the downstream channels. Lock Status Displays if the device has locked successfully to a downstream channel. Channel Type Displays the channel type. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 35: Using The Event Log Option

    To view event log information: 1. Click CM Info from the left side menu. 2. Click Event Log under CM Info. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 36 Ubee Interactive Using the CM Info Option Label Description Time Displays the date and time of the event. Priority Displays the priority of the event. Description Describes the event. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 37: Understanding The Telephony Menu

    Using the Status Option The Status option displays telephony startup procedure and line state information. To view telephony status information: 1. Click MTA from the left side menu. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 38: Using The Dhcp Option

    Displays the time the current connection will re-register. 5.1.2 Using the DHCP Option Use the DHCP (Dynamic Host Control Protocol) option to monitor the UBC1303AB00 lease parameters, timers, and PacketCable DHCP Option 122. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 39 Displays the time left on the rebinding lease. Rebinding is when the Rebind Time Remaining client tries to renew the DHCP lease on the same server before trying to connect to a new DHCP server. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 40: Using The Qos Option

    Field descriptions are listed below the screen example. Label Description Error Codewords Unerrored Codewords Displays the number of codewords passed without error. Correctable Codewords Displays the number of codewords corrected. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 41: Using The Provisioning Option

    Use the Provisioning option to view the MTA configuration file and enterprise MIB settings. To view telephony provisioning details: 1. Click MTA from the left side menu. 2. Click Provisioning funder MTA. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 42 Ubee Interactive Using the MTA Option Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 43: Using The Event Log Option

    Displays the priority level of the displayed event. Displays an identification number for the event. Text Defines the event with a detailed textual description. Endpoint Displays the endpoint name to which the event is related. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 44: Understanding The Gateway Menu

    Using the WAN Options Use the WAN option to view information regarding the WAN interface of the UBC1303AB00. To view WAN interface information: 1. Click Gateway from the main menu. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 45: Using The Setup Option

    Displays the WAN interface’s hardware address. Duration Displays the accumulated time since successfully acquiring a WAN public IP address. Expires Displays the remaining time before the WAN IP address expires, if applicable. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 46: Using The Operation Mode Option

    To configure the router operation mode: 1. Click WAN from the left side menu. 2. Click Operation Mode under WAN. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 47: Using The Lan Options

    Using the DHCPv4 Option The DHCPv4 screen allows you configure IPv4 DHCP (dynamic host configuration protocol) behavior. To configure DHCPv4 settings: 1. Click LAN from the left side menu. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 48 Check if you want to disable the use of a DHCP server. Server Enable DHCP Server Check if you want to enable the use of a DHCP server. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 49 MAC and IP Addresses for the new lease. Click Apply when once information has been added. After clicking apply, the information appears in the orange table on the DHCPv4 screen (see below). Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 50: Using The Dhcpv6 Option

    IPv6 network. To configure DHCPv6 settings: 1. Click LAN from the left side menu. 2. Click DHCPv6 under LAN. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 51 MAC and Windows 7 devices that turn off the network interface when they go into standby mode. This results in slow Web browsing until the device gets a new IPv6 address via DHCPv6. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 52: Using The Dhcp Lease Option

    MAC Address Displays the IP address of the client. IP Address Displays the MAC address of the client. Expires in Displays the time until the DHCP lease expires. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 53: Using The Wlan Option

    2.4GHz and 5GHz radio bands simultaneously. Both radios are enabled by default. To configure basic wireless settings: 1. Click WLAN from the left side menu. 2. Click Basic under WLAN. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 54 Sets the wireless networking standard. Available modes for selection are:  802.11 mode 2.4GHz: B/G/N-mix (default), G/N-mix, B/G-mix, and N-only  5GHz: A/N/AC-mix (default), N/AC-mix, AC-only, A-only, N-only Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 55: Using The Security Option

    2.4GHz and 5GHz radio bands. To configure wireless security: 1. Click WLAN from the left side menu. 2. Click Security under WLAN. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 56 NOTE: AES is the most secure and efficient. You should only enable TKIP if you have a very old device that cannot support AES. TKIP will also compromise the security of your device, and will result in reduced throughput. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 57: Using The Wps Option

    (SSID), or pre-shared key. To connect via WPS: 1. Click WLAN from the left side menu. 2. Click WPS under WLAN. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 58: Using The Access Control Option

    5GHz wireless networks. To configure wireless access: 1. Click WLAN from the left side menu. 2. Click Access Control under WLAN. Descriptions follow the screen sample below. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 59 Deny creates a list of wireless clients that you do not want to have access to your wireless network. Enter the MAC addresses of these clients in the MAC Addresses fields. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 60: Using The Wmm Option

    54Mbps (802.11g max speeds). To configure WMM: 1. Click WLAN from the left side menu. 2. Click WMM under WLAN. Descriptions follow the screen sample below. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 61 The Traffic Schedule will control access to the common queue, so that we can control what to do when reaching over-capacity. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 62: Deploying And Troubleshooting The Wireless Network

    UBC1303AB00. This value can significantly impact wireless speeds/performance. It is determined by:  Materials (for example, open air, concrete, trees)  Distance between wireless clients and the wireless cable gateway  Wireless capabilities of the client devices Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 63 Note 2: The attenuation caused by trees varies significantly depending upon the shape and thickness of the foliage. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 64 UBC1303AB00. Instructions for checking speeds are provided for both a Windows and Mac computer in the table below. If the wireless computer is not connected, refer to Connecting a Wireless Device on page Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 65 This feature allows you to choose the best band for your device to ensure stability with your local and Internet connection. The table below provides a comparison between the 2.4GHz and 5GHz bands. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 66 22MHz wide. Since channels overlap, it is best to choose channels that have the least overlap (typically 1, 6, and 11 in the Americas, and 1, 5, 9, and 13 in Europe). Overlapping channels can cause wireless network performance issues. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 67: Using The Advanced Settings Options

    Using the Firewall option on page 63  Using the IP Filter Option on page 64 Using the MAC PassThrough Option on page 65   Using the MAC Filter Option on page 66 Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 68: Using The Options Option

    ALG (Application Layer Gateway) of the device. To configure ALG protocols: 1. Click Advanced Settings from the left side menu. 2. Click Options under Advanced Settings. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 69: Using The Firewall Option

    The Firewall screen allows you to select firewall settings and enable firewall options. To configure firewall settings: 1. Click Advanced Settings from the left side menu. 2. Click Firewall under Advanced Settings. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 70: Using The Ip Filter Option

    NOTE: You may also filter by the MAC address which does not require setting a static lease. Refer to Using the MAC Filter Option on page To set up IP Filters: 1. Click Advanced Settings from the left side menu. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 71: Using The Mac Passthrough Option

    To configure a MAC PassThrough Address: 1. Click Advanced Settings from the left side menu. 2. Click MAC PassThrough under Advanced Settings. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 72: Using The Mac Filter Option

    You must note the MAC addresses of the devices that you want to deny Internet access. Be sure all devices to which you potentially deny Internet access are connected to the UBC1303AB00 network. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 73 To remove a MAC address from the MAC filtering table, check the “Remove” box to the right of Remove the MAC address, then click the Remove button at the bottom of the screen. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 74: Using The Port Forwarding Option

    Click Gateway from the top main menu. c. Click LAN from the left menu. d. Click DHCPv4 under the LAN menu. e. Check the Enable UPnP box. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 75 1. Click Advanced Settings from the left side menu. 2. Click Port Forwarding under Advanced Settings. 3. Click the Create Entry button to begin setting up port forwarding. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 76 It is common and safer to enter the same port number as the start and end of the range. Protocol Selects the protocol type. Options are TCP, UDP or TCP/UDP. Description Specifies the forwarding rule name. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 77: Using The Port Trigger Option

    LAN host to a specific destination port number. The port the LAN host is required to listen to by the application is called the target port. The server returns responses to these ports. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 78 3. Click the Create button to begin setting up port triggers. 4. Enter information in the port trigger fields as shown in the screen shot below. Field descriptions follow. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 79 Label Description Edit Displays fields for the rule selected in order to change values. Remove All Deletes all entries in the forwarding table. Remove Deletes the selected rule. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 80: Using The Dmz Option

    Internet from a PC connected to the Home Gateway, or make calls from a VoIP phone. Label Description DMZ Host IP Address Allows you to enter the IP address of the host to be exposed. Save/Apply Saves changes. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 81: Using The Ddns Option

    Displays the interface for the DDNS account. User Name Displays the user name for the DDNS account. Password Displays the password for the DDNS account. Apply/Save Saves changes. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 82: Using The Dns Override Option

    The NTP (Network Time Protocol) option lets you set the UBC1303AB00 to automatically synchronize with Internet Time servers via Simple Network Time Protocol (SNTP). SNTP is a protocol for synchronizing the clocks of computing devices over networks. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 83: Using The Parental Control Option

    Select the appropriate time zone from the drop-down menu. Apply/Save Applies the changes. Using the Parental Control Option Use the Parental Control option to configure access policies for the UBC1303AB00. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 84: Using The Tod Filter Option

    3. Click the Create button to begin setting up time of day filters. 4. Enter information in the Time of Day Filter fields as shown in the screen shot below. Field descriptions follow. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 85 Label Description Edit Displays fields for the rule selected in order to change values. Remove All Deletes all entries in the forwarding table. Remove Deletes the selected rule. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 86: Using The Management Option

    To change the user name and password: 1. Click Management from the left side menu. 2. Click Account under Management. Field descriptions are listed below the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 87: Using The Backup/Restore Option

    Backing Up the Current Configuration To backup and save the current device configuration, click the Backup button. The file will be saved to your Downloads folder titled ‘GatewaySettings.conf.’ Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 88 The File Upload dialog box appears and allows you to select the previously saved backup file. Highlight the file and click ‘Open’. The backed up filename appears in the box to the right of the Choose File button. Click the Restore button. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 89: Using The Factory Default Option

    To reset the device to factory settings: 1. Click Management from the left side menu. 2. Click Factory Default under Management. Field descriptions follow the screen example. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 90: Using The Client List Option

    Description CPE Interface Status Interface Displays the interface. Status Allows you to select whether the CPE Interface is Enabled or Disabled. Apply/Save Saves the CPE Interface Status changes. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 91: Using The Diagnostics Option

    You can also confirm the size of data sent is the same as the size of data received. 1. Choose Ping from the drop-down menu. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 92 Resolve Host names box, Traceroute tries to find which name matches the address. Some hosts have no names, and might still be shown as IP addresses, even if this option is active. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 93: Using The Home Topology Option

    Using the Home Topology Option Use the Home Topology option to view the current wireless network connections for the UBC1303AB00 Advanced Wireless Voice Gateway. In the following screen example: Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 94  The lines indicate the connections between the interfaces. NOTE: When you hover over a node, it displays the MAC addresses of the connected devices, as shown below. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

  • Page 95: Glossary

    Equipment such as telephones, routers, and modems located at a user’s location to enable access to communication services. Default Gateway The routing device used to forward all traffic that is not addressed to a computer on the local subnet. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 96 A standard network protocol that specifies how data is placed on and retrieved from a common transmission medium. It forms the underlying transport vehicle used by several upper-level protocols, including TCP/IP, HTTP, and FTP. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 97 A system that facilitates the transfer of messages in the form of text. ISP (Internet Service Provider) A company that provides individuals and companies access to the Internet and other related services. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 98 PPTP (Point-to-Point Tunneling Protocol) A method for ensuring secure communication between virtual private networks. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 99 A protocol for synthesizing the clocks of computing devices over networks. STBC (Space-Time Block Code)) A technique used in wireless communications to transmit multiple copies os a data stream across a number of antennas. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 100 UDP (User Datagram Protocol) A communications protocol that offers a limited amount of service when messages are exchanged between computers in a network that uses the Internet Protocol. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...
  • Page 101 A markup language that defines a set of rules for encoding documents in a format that is both human-readable and machine readable. XPress™ XPress™ is a standards-based frame-bursting approach to improve 802.11g wireless LAN performance developed by Broadcom. Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017...

Table of Contents
