Maximum Cable Distances

The maximum cable distance depends on resolution, frequency, and, for PC resolutions, the power of the graphics card
(when powered by the source). When the source is a PC, Extron recommends the UHD4K 101 be powered by an external
power supply.
Resolution
720p
1080i
1080p
1080p (8, 10, or 12 bit)
3840x2160 (UHD)
3840x2160 (UHD)
4096x2160 (4k)
For additional resolutions refer to the UHD4K 101 User Guide (available at www.extron.com).

Internal Settings

ATTENTION:
Use electrostatic discharge (ESD) precautions (be electrically grounded) when making connections.
•
Prenez des précautions contre les décharges électrostatiques (soyez électriquement relié à la terre) lorsque vous
•
effectuez des connexions.
Under most conditions, the UHD4K 101 works without adjustments. However, the quality of the image displayed may be
affected by a combination of the source, display, and cable length. If so, use the three sets of internal jumper switches to
adjust DDC buffer, Equalization (EQ), and Pre-emphasis.
Remove the cover of the unit, as described in the UHD4K 101 User Guide.
1.
Position the UHD4K 101 with the front panel (status LED) furthest from you and the rear panel (power input) closest to
2.
you.
In that orientation, the EQ jumpers are furthest from you and the Pre-emphasis jumpers are closest to you.
Set the jumper switches as shown in the table below and replace the cover to the unit.
3.
Jumper
J4 (EQ)
J5 (DDC Buffer)
J6 (Pre-emphasis) Adjusting this jumper can compensate for
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX +1.919.850.1001 FAX
© 2015 Extron Electronics — All rights reserved. All trademarks mentioned are the property of their respective owners.
Refresh (Hz)
24, 30, or 60 100 feet
30 or 60 100 feet
30 100 feet
60 75 feet
30 50 feet
60 (4:2:0) 50 feet
30 50 feet
Function
Adjusting this jumper can improve the image
for some applications with longer cable runs,
image artifacts, or both.
Some applications require that the DDC be
buffered for proper operation.
The Active setting for this jumper (connecting
pins 1 and 2) is required for proper operation
only for applications in which a source has a
weak or no pull up resistor.
signal degradation in applications with higher
data rate, higher resolution, or both. This
adjustment is recommended for resolutions of
2560x1600 @ 60 Hz or higher.
Extron Europe Extron Asia
+800.3987.6673 +65.6383.4400
(Inside Europe Only) +65.6383.4664 FAX
+31.33.453.4040
+31.33.453.4050 FAX
Maximum Distance
(30.5 meters)
(30.5 meters)
(30.5 meters)
(22.9 meters)
(15.2 meters)
(15.2 meters)
(15.2 meters)
Jumper
Pins 2 and 3
3
8.6 dB
3
Active,
no pull up
3
2.5 dB
Extron Japan Extron China
+81.3.3511.7655 +86.21.3760.1568
+81.3.3511.7656 FAX +86.21.3760.1566 FAX
Jumper No Jumper
Pins 1 and 2
1 3 1 3
4.3 dB
12.4 dB
Default
1 3 1 3
Active
Pass-
through
Default
1 3 1 3
None
1.6 dB
Default
