- Page 1 User Guide HDMI HD 4K 101 Plus Cable Equalizer 68-2892-01 Rev. D 06 20...
- Page 2 Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad WARNING This symbol, , when used on the product, is intended avvertire l’utente della presenza di tensione non isolata pericolosa to alert the user of the presence of uninsulated dangerous voltage all’interno del contenitore del prodotto che può...
- Page 3 Copyright © 2016-2020 Extron Electronics. All rights reserved. www.extron.com Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks ( ® ), registered service marks ( ), and trademarks ( ) are the property of RGB Systems, Inc. or Terms of Use page at www.extron.com):...
- Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 5: Table Of Contents
Input Cable Lengths ..........3 Extron Warranty ........10 Securing the HDMI Connector ......4 HD 4K 101 Plus Rear Panel ......... 5 Powering Via the Input Source ......7 Internal Settings ........... 7 Connecting for Long Cable Runs ......8 HD 4K 101 Plus • Contents... - Page 6 HD 4K 101 Plus • Contents...
-
Page 7: Introduction
The HD 4K 101 Plus supports resolutions up to UHD (3840x2160 @ 60 Hz) or 4K (4096x2160 @ 60 Hz). It is also able to support a 225 MHz pixel clock rate with 1080p @ 60 Hz (8, 10, or 12-bit) or 1920x1200 @ 60 Hz resolution. HD 4K 101 Plus • Introduction... -
Page 8: Features
Enclosure — Compact 1-inch (2.5 cm) high, 1/8 rack wide, 3-inch deep enclosure. • • Rack and furniture mounting — The cable equalizer can be mounted on a rack shelf or under a desk or podium using optional mounting brackets. HD 4K 101 Plus • Introduction... -
Page 9: Panel Features
1080p (8 bit or deep color) 125 feet (38.1 meters) 3840x2160 (UHD) 24/30 75 feet (22.9 meters) 4096x2160 (4K) 24/30 75 feet (22.9 meters) 3840x2160 (UHD) 50 feet (15.2 meters) 4096x2160 (4K) 35 feet (10.7 meters) HD 4K 101 Plus • Panel Features... -
Page 10: Securing The Hdmi Connector
Loosely place the included tie wrap around the HDMI connector and the LockIt lacing bracket as shown. While holding the connector securely against the lacing bracket, tighten the tie wrap, and then remove any excess length. HD 4K 101 Plus • Panel Features... -
Page 11: Hd 4K 101 Plus Rear Panel
Slide the exposed ends of the wire into the captive screw connector and secure by tightening the screws. Use the supplied tie wrap to strap the power cord to the extended tail of the connector. HD 4K 101 Plus • Panel Features... - Page 12 12 feet (3.6 m). NOTE: Use the provided LockIt HDMI lacing bracket to secure the HDMI connector (see Securing the HDMI Connector on page 4 ). HD 4K 101 Plus • Panel Features...
-
Page 13: Powering Via The Input Source
Locate the four sets of jumper switches on the side of the circuit board (see figure 4). DDC CLK Buffer J4 DDC DATA Buffer Pre-emphasis J5 EQ Jumper Switches (4 sets) Rear Panel Set Jumper Switches (top removed) Figure 4. Locating the Jumper Switches HD 4K 101 Plus • Panel Features... -
Page 14: Connecting For Long Cable Runs
Short Cable Long Cable to Display from Source ( less than ( up to 175 feet (53.3m)) 15 feet (4.5m)) HD 4K 101 Plus Source Display Figure 5. Optimum Cable Lengths for the HD 4K 101 Plus HD 4K 101 Plus • Panel Features... -
Page 15: Mounting
HD 4K 101 Plus. Follow the instructions provided with the kit. Through Desk Mounting See the Extron website to find the optional through desk mounting kit suitable for the HD 4K 101 Plus. Follow the instructions provided with the kit. HD 4K 101 Plus • Mounting... -
Page 16: Extron Warranty
Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
