Extron electronics Equalizer HDMI 101 Specifications

Specifications — HDMI 101
N *Appropriate HDMI to DVI-D cables or adapters are required for DVI signal input/output.

Video

Maximum data rate 4 95 Gbps (1 65 Gbps per color)
Maximum pixel clock 165 MHz
Resolution range Up to 1920x1200 or 1080p @ 60 Hz
Formats RGB and YCbCr digital video
Standards DVI 1 0, HDMI 1 2

Video input

Number/signal type 1 single link HDMI (or DVI-D*)
Connectors 1 female HDMI type A
Equalization Automatic for up to -40 dB of cable loss
Input cable length Up to 200' (61 m) at 1080p or 1920x1200 @ 60 Hz
N The transmission distance varies greatly depending on the signal resolution and on the type of cable,
graphics card, and display used in the system.

Video output

Number/signal type 1 single link HDMI (or DVI-D*)
Connectors 1 female HDMI type A
Output cable length Up to 15' (5 m)

General

Power Supplied by an external power supply or by the 5 V signal from an HDMI
External power supply 100 VAC to 240 VAC, 50/60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements 12 VDC, 0 2 A from an external power supply or
Temperature/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling Convection, no vents

Mounting

Rack mount Yes, with optional 1U, 9 5" deep rack shelf (RSU 129, #60-190-01; RSB 129,
Furniture mount Yes, with optional MBU 125 Under-Desk Mounting Kit, #70-077-01
Enclosure type Metal
Enclosure dimensions 1 0" H x 2 2" W x 3 0" D (one eighth rack wide)
Product weight 0 4 lbs (0 2 kg)
Shipping weight 2 lbs (1 kg)
Vibration ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety CE, CUL, UL
Compliances CE, C-tick, FCC Class A, ICES ,VCCI
MTBF 30,000 hours
Warranty 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
Up to 250' (76 m) at 720p, 1080i, or 1024x768 @ 60 Hz
Longer distances are possible with lower rates and/or high quality cable
source (pin 18) or a DVI source (pin 14)
5 VDC, 0 05 A from an HDMI or DVI source
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
60-604-01); 1U, 6" deep rack shelf (RSU 126, #60-190-10; RSB 126, 60-604-10);
or 1U, 3 5" deep VersaTools
®
60-604-20)
(2 5 cm H x 5 6 cm W x 7 6 cm D)
Extron HDMI 101 Equalizer • Specifications
rack shelf (RSF 123, #60-190-20; RSB 123,
7.6-121008-D5
