Foscam FI9831P Quick Installation Manual

Security Warning
Foscam cameras require good security practices to
safeguard your privacy. You can help protect your camera
by changing the default username and/or password.
Quick Installation Guide
You should update your camera regularly at
http://www.foscam.us/firmware.html. Make sure your camera
has the latest firmware installed for your specific camera
P2P HD IP Camera
model.
Model:FI9831P 1
Connect the IP Camera to the Internet
(Wired or Wireless)
Choose either of the following two ways (wired or wireless) to
quickly connect your cameras to the internet.
Wired Connection
① Mount the antenna and make it stand vertically (upright).
② Connect the camera to the LAN network (router or switch) via
White Black
network cable.
③ Connect the power adapter to the camera.
WPS Connection (Wireless Setup)
The WPS button on the back of the camera allows you to
Foscam Digital Technologies LLC automatically find and connect your camera wirelessly to your
router without having to manually login and set up any wireless
V1.3
settings.
Please make sure that your router supports the WPS function.
If the camera is already connected using a network (Ethernet)
cable to your router, please disconnect it.
① Mount the antenna and make it stand vertically (upright).
② Connect the power adapter to the camera.
③ Press and hold the WPS button for two seconds. The WPS button
is located on the back of the camera under the gold Wi-Fi
connector. The green LED indicator next to the Ethernet port will
begin flashing rapidly.
④ Next, press the WPS button on your wireless router within 60
seconds. This is usually located on the back of the router. Consult
Internet your router's user manual for detailed information on this feature.
⑤ The camera will automatically create a secure wireless
ANT
Router
AUDIO connection to your router in about 60 seconds. You will notice
SD
OUT IN
WPS
that the green LED indicator will flash at a slower rate once WPS
connection is established.
Note:
To set up your Foscam camera, only one of the two options above
need to be followed (wired or wireless connection). If your router
supports WPS functionality, we recommend using the second
option to set up your camera wirelessly. If your router does not
support WPS or if your WPS connection fails, please refer to the
"Wireless Settings" section in the FI9831P user manual located on
your installation CD to set up your camera wirelessly.
2
Access the IP Camera by Smart Phone
(Android or iOS devices)
If you use an Android or iOS smartphone, you can access the
IP camera using the official Foscam app. Once the camera is
connected to your smartphone, we recommend modifying
the user name and password.
① Download and Install the FREE Official Foscam App
On the Google Play Store for Android devices, search for the
app named: "Foscam Viewer".
On the App Store for iOS devices, search for the app named:
"Foscam Viewer".
For iPhone / iOS Devices
For Android
Foscam Viewer Foscam Viewer
② On the Foscam Viewer app Home Screen, click on the IPC icon
on the bottom of the screen. Next, tap on the Scan QR Code icon
( ). The QR Code scanning function will open. Simply line up
the QR Code Scanner with the QR Code printed on the bottom of
your Foscam IP Camera.
Click here
③ Once the QR Code scan is complete, you will be directed to a
new screen titled "Device Info". The "Device UID" field will
automatically populate with your camera's unique UID. This
value can also be entered manually, as the UID serial is located
under the QR code on the bottom of your camera.
You must also input a Device Name (of your choice), Username
(default is admin), and Password (left blank by default) for the
camera on the "Device Info" page. Click OK.
Once the camera has been added successfully, you can access the
live video stream by tapping on your camera on the "Device List"
page.
Click OK.
If you scan a QR code on the bottom of the camera
successfully, the UID will be displayed automatically.
Default username is admin with no password.
