Pioneer HTZ-BD52 Operating Instructions Manual

Blu-ray disc surround system blu-ray disc receiver speaker system speaker system
Hide thumbs

Advertisement

HTZ-BD52
HTZ-BD32
HTZ-BD92HW
HTZ-BD82HF
XV-BD422W
XV-BD122W
XV-BD922FSW
XV-BD822FSW
S-BD422W
S-BD122
S-BD922HW
S-BD822HF
S-BD922SW
Register your product on
http://www.pioneerelectronics.com (US)
http://www.pioneerelectronics.ca (Canada)
Protect your new investment
The details of your purchase will be on file for reference in the event of an
insurance claim such as loss or theft.
Receive free tips, updates and service bulletins on
your new product
Improve product development
Your input helps us continue to design products that meet your needs.
Receive a free Pioneer newsletter
Registered customers can opt in to receive a monthly newsletter.
Blu-ray Disc surround system
Système Home-Cinéma Blu-ray Disc
sistema surround de Blu-ray Disc
Blu-ray Disc receiver
Système Home-Cinéma Blu-ray Disc
receptor de Blu-ray Disc
Speaker System
Enceintes acoustiques
Sistemas de parlantes
Subwoofer
Enceinte d'extrêmes graves
Altavoz de subgraves
http://www.pioneerelectronics.com (US)
http://www.pioneerelectronics.ca (Canada)

Advertisement

loading

  Related Manuals for Pioneer HTZ-BD52

  Summary of Contents for Pioneer HTZ-BD52

  • Page 1 Receive free tips, updates and service bulletins on your new product Improve product development Your input helps us continue to design products that meet your needs. Receive a free Pioneer newsletter Registered customers can opt in to receive a monthly newsletter.
  • Page 2 Safety Information Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference.
  • Page 3 Only use attachments/accessories specified by Read these instructions. the manufacturer. Keep these instructions. Use only with the cart, stand, tripod, bracket, or Heed all warnings. table specified by the manufacturer, or sold with Follow all instructions. the apparatus. When a cart is used, use caution Do not use this apparatus near water.
  • Page 4 When you find it for a long period of time (for example, when on damaged, ask your nearest PIONEER authorized vacation). service center or your dealer for a replacement.
  • Page 5 WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE : THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
  • Page 6 Notes on Copyrights...
  • Page 7 Important Notice for TV colour system...
  • Page 8: Table Of Contents

    – Wall mounting the speaker for BCS-SB626 Table of Contents – Additional notes on speaker placement for BCS-SB626 – Positioning the system for BCS-SB626 – Speaker setup for BCS-FS525 Before you start – Wall mounting the speakers for BCS-FS525 – Additional notes on speaker placement for Introduction BCS-FS525 –...
  • Page 9 – Playing in the desired order (Programmed – Listening to the radio Play) – Presetting the radio stations – Making bookmarks – Deleting all the saved stations – Zoom – Improving poor FM reception – Playing photos as slideshows – Seeing information about a radio station Bluetooth®...
  • Page 10: Before You Start

    Before you start Chapter 1 Accessories of speaker box Before you start (BCS-727) Introduction Supplied accessories Speaker cables (4) Non-skid pads (1) Video cable (1) Remote control (1) Screws M4 x 16 (16) Screws M4 x 12 (8) (They are used to fix to the (They are used to fix the base and lower cabinet.) upper and lower cabinet.)
  • Page 11: Accessories Of Speaker (Bcs-Hf828)

    Before you start Accessories of speaker Accessories of speaker (BCS-HF828) (BCS-FS525) Small non-skid pads (1) Base (2) Stand arm (2) Speaker cable (3) Screw (Bind head) Screw (Flat head) Hexagonal nut (2) Small screws (8) Large non-skid pads (1) Bracket (2) Seal (1) Large screws (4) Speaker stand bases (2)
  • Page 12: Putting The Batteries In The Remote Control

    Close securely (a click should be heard). public institution's rules that apply in your country/ area. Software update Product information on this player is provided on the Pioneer website. Check this website for update and service information on your Blu-ray disc player. IN Europe: http://www.pioneer.eu/...
  • Page 13: Types Of Discs/Files That Can Be Played

    Before you start Types of discs/files that can be played Playable discs Discs with the logo marks below indicated on the disc label, package or jacket can be played. Caution Only the discs that have been finalized can be played. Application format Disc type Logo...
  • Page 14 Before you start "Blu-ray Disc", "Blu-ray" and "Blu-ray Disc" logo About audio formats are trademarks of Blu-ray Disc Association. The following audio formats are supported on is a trademark of DVD Format/Logo this player: Licensing Corporation. Dolby TrueHD Dolby Digital Plus Discs that cannot be played Dolby Digital HD DVDs...
  • Page 15 Before you start Playing DVDs "BONUSVIEW" is trademark of Blu-ray Disc Association. This label indicates playback compatibility with BD-LIVE functions such as downloading DVD-RW discs recorded in VR format (Video movie trailers or additional audio and Recording format). However, for discs recorded subtitle languages and playing on-line with a record-only-once encrypted program, games can be enjoyed over the Internet.
  • Page 16 Before you start Playing CDs About video, audio, and image files and folders Regarding copy protected CDs: This player is designed to conform to the specifications Audio and image files can be played on this of the Audio CD format. This player does not player when the folders on the disc or USB support the playback or function of discs that device are created as described below.
  • Page 17 Before you start Playable files Note ® Video, image and audio files recorded on BDs, This DivX Certified device must be registered in order to play DivX Video-on-Demand (VOD) DVDs, CDs or USB devices can be played. content. First generate the DivX VOD registration code for your device and submit it during the Caution registration process.
  • Page 18 Before you start Table of Playable Files Playable media BD-R/RE/-R DL/ Playable files RE DL/-R LTH, File specifications (Extensions) DVD-R/RW/-R DL/ USB devices Network +R/+RW/+R DL, CD-R/RW Sampling frequencies: Up to 48 kHz Bit rate: Up to 320 kbps (.mp3) Audio type: MPEG-1 Audio Layer 3 Sampling frequencies: Up to 48 kHz Bit rate: Up to 192 kbps...
  • Page 19: Trademarks And Licenses

    Before you start Trademarks and licenses HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. “x.v.Colour”, trademarks of Sony Corporation. Manufactured under license from Dolby Laboratories.
  • Page 20: Remote Control

    Before you start Remote control (STANDBY/ON): Press to turn the power on and off. FUNCTION: Changes the input source or function. When switching while viewing the display window on the player 1. The input source switches every time the FUNCTION is pressed. 2.
  • Page 21 Before you start VOL +/- : Adjusts speaker volume. Color buttons: Use these to navigate BD-ROM menus. SOUND RETRIEVER: Switches Sound Retriever setting. PROGRAM: Registers FM radio stations. CD/SACD: See page 59. BOOKMARK (RDS): Create a BOOKMARK (page USB REC: Records an audio. RDS information (page 72).
  • Page 22: Front Panel

    Before you start Front panel 1 Disc tray 3 MIC 2 Operation buttons 4 PORTABLE (STANDBY/ON) (PLAY/PAUSE) Switches the unit ON or OFF. 6 USB port Note 7 Volume control If the power does not turn OFF, pressing the 8 Remote control sensor (STANDBY/ON) button for more than 5 seconds Point the remote control to this, then reboots the unit and the operation becomes...
  • Page 23: Rear Panel

    Before you start Rear panel BCS-727/BCS-323 BCS-HW929/BCS-HF828/BCS-SB626/BCS-FS525 1 AC IN 8 iPod Plug into the power source. Connect to the furnished iPod cradle. 2 SPEAKERS connectors 9 OPTICAL IN 1/2 3 Cooling Fan a HDMI OUT 4 VIDEO OUT b HDMI IN 1/2 5 AUX IN (L/R) c LAN port 6 ADAPTER PORT...
  • Page 24: Connecting

    Connecting Chapter 2 3. Mount the front/surround speaker. 1 Pass the speaker cable through the Connecting cable hole on the side of the base. Assemble the speakers Speaker setup for BCS-727 Preparing the speakers 1. Connect the wires to the player. Insert the cables connected to the player to the same colored connector on the speaker.
  • Page 25: Wall Mounting The Speaker For Bcs-727

    Caution If you are unsure of the qualities and strength of the wall, consult a professional for advice. Pioneer is not responsible for any accidents or damage that result from improper installation. 5 mm 10 mm Caution Be careful not to tighten screws excessively.
  • Page 26: Additional Notes On Speaker For Bcs-727

    Connecting Front left speaker (L)/ Additional notes on speaker Front right speaker (R): for BCS-727 Place the front speakers to the sides of the monitor or screen and as flush with the screen Install the main front left and right speakers at surface as possible.
  • Page 27: Speaker Setup For Bcs-323

    To prevent the risk of electric shock when connecting or disconnecting the speaker cables, Pioneer is not responsible for any accidents or disconnect the power cord before touching any damage that result from improper installation.
  • Page 28: Additional Notes On Speaker For Bcs-323

    Connecting Front left speaker (L)/ Additional notes on speaker Front right speaker (R): for BCS-323 Place the front speakers to the sides of the monitor or screen and as flush with the screen Install the main front left and right speakers at surface as possible.
  • Page 29: Speaker Setup For Bcs-Hw929

    Connecting 2. Connect the wires to the player. Speaker setup for BCS-HW929 Insert the cables connected to the player to the same colored connector on the speaker. Preparing the speakers 1. Attach the non-skid pads to the base of each speaker. For front speaker: Use the supplied adhesive to attach six pads to the base (bottom) of speaker.
  • Page 30: Wall Mounting The Speaker For Bcs-Hw929

    If you are unsure of the qualities and strength of the wall, consult a professional for advice. Pioneer is not responsible for any accidents or damage that result from improper installation. 1 Remove the base plates. The base plates are held in position by the 5.
  • Page 31: Additional Notes On Speaker For Bcs-Hw929

    Pioneer logo is oriented as shown in the accompanying illustration.
  • Page 32: Speaker Setup For Bcs-Hf828

    Connecting 2. Fasten the speaker to the base use the Speaker setup for BCS-HF828 horizontal mounting screw from the back side of the base. Preparing the speakers For subwoofer: Horizontal mount Use the supplied adhesive to attach four large screw pads to the base of subwoofer.
  • Page 33 Connecting 3. Affix the seal on the screw head. Caution Do not connect any speakers other than those supplied to this system. Seal Do not connect the supplied speakers to any amplifier other than the one supplied with this system. Connection to any other amplifier may result in malfunction or fire.
  • Page 34: Wall Mounting The Speakers For Bcs-Hf828

    If you are unsure of the qualities and strength of the wall, consult a professional for advice. Open two holes in the wall 95 mm apart. Pioneer is not responsible for any accidents or damage that result from improper installation. 1. Use the vertical mounting screw to fasten the wall mounting fixture to the speaker system.
  • Page 35: Additional Notes On Speaker For Bcs-Hf828

    Connecting Additional notes on speaker Positioning the system for for BCS-HF828 BCS-HF828 Install the main front left and right speakers at The following illustration shows an example equal distance from the TV. of positioning the system. Note that the illustrations in these instructions differ from Precautions: the actual unit for explanation purposes.
  • Page 36: Connecting To Your Tv

    Connecting Connecting to Your TV HDMI connection If you have a HDMI TV or monitor, you can Make one of the following connections, connect it to this player using a HDMI cable depending on the capabilities of your existing (High Speed HDMI™ Cable). Connect the equipment.
  • Page 37: Arc (Audio Return Channel) Function

    Connecting ARC (Audio Return Channel) Video connection function Connect the VIDEO OUT terminal on the player to the video in terminal on the TV using a video The ARC function enables an HDMI capable TV cable. You can hear the sound through the to send the audio stream to HDMI OUT of this system’s speakers.
  • Page 38: Antenna Connection

    Connecting Antenna connection Connections with external device Connect the supplied antenna for listening to the radio. AUX connection You can enjoy the sound from an external component through the speakers of this system. Connect the analog audio output terminals of your component into the AUX L/R (INPUT) on this unit.
  • Page 39: Portable In Connection

    Connecting PORTABLE IN connection OPTICAL IN 1/2 connection You can enjoy the sound from your portable You can enjoy the sound from your component audio player through the speakers of this with a digital optical connection through the system. speakers of this system. Connect the headphones (or line out ) terminal Connect the optical output terminal of your of the portable audio player into the PORTABLE...
  • Page 40: Hdmi In 1/2 Connection

    Bluetooth® ADAPTER You can enjoy the pictures and sound from your component through this connection. Bluetooth ADAPTER (Pioneer Model Connect the HDMI OUT terminal of your No. AS-BT100 or AS-BT200) is connected to component into the HDMI IN 1 or 2 terminal this unit, a product equipped with Bluetooth on this unit.
  • Page 41: Connecting To Your Home Network

    Connecting Connecting to your Home Network Broadband service This player can be connected to a local area network (LAN) via the LAN port on the rear panel or the internal wireless module. By connecting the unit to a broadband home network, you have access to services such as BD-LIVE interactivity and Online content services.
  • Page 42: Wireless Network Connection

    Connecting Wireless network connection Wireless network setup Another connection option is to use an For the wireless network connection, the player Access Point or a wireless router. The network needs to be set up for network communication. configuration and connection method may vary This adjustment can be done from the [Setup] menu.
  • Page 43: Wps Setup (Wi-Fi Protected Setup)

    Connecting WPS setup Note (Wi-Fi Protected Setup) available on an access point or wireless router’s setting. If your access point or wireless WPS connection setting code of the key “No.1” to connect on your home network. An Access Point is a device that allows you to industry group for a function allowing settings connect to your home network wirelessly.
  • Page 44 Connecting 7. When connecting using PBC (Push Notes on Network Connection: Button), on the [ PBC] screen use / Many network connection problems during to select NEXT, then press ENTER. set up can often be fixed by re-setting the router or modem. After connecting the player point within 120 seconds.
  • Page 45: Usb Device Connection

    Connecting ADSL modem is required to use DSL service USB device connection and a cable modem is required to use cable modem service. Depending on the access This player can play movie, music and photo method of and subscriber agreement with files contained in the USB device.
  • Page 46: Getting Started

    HDMI OUT After Initial Setup format. terminal, language settings are imported After updating the player’s software. from the Pioneer Flat Screen TV’s language settings before Setup Navigator begins. Caution Before turning on the power, check that the 5.
  • Page 47: Operating The Tv With The Player's Remote Control

    Press the number buttons (0 to 9) to input the code while pressing TV CONTROL Note The factory default setting is 00 (PIONEER). If you make a mistake when inputting the code, release TV CONTROL then start over from the beginning.
  • Page 48: Tv Preset Code List

    Getting Started TV preset code list Manufacturer Code(s) PIONEER 00, 31, 32, 07, 36, FRONTECH 31, 42, 46 MAGNAVOX 07, 10, 03, 12, SALORA 31, 32, 42, 43 FRONTECH/PROTECH 32 SAMBERS 49 42, 51, 22 ACURA 44 FUJITSU 48 MANESTH 39, 46...
  • Page 49: Playback

    Playback Chapter 4 Note Playback Load the disc with the printed side facing up. Several dozen seconds are required to read the disc. Once reading is completed, the type of disc is displayed on the player's front panel Playing discs or files display.
  • Page 50: Forward And Reverse Scanning

    Playback Forward and reverse scanning Step forward and step reverse During playback, press REV or While playback is paused, press FWD. The scanning speed switches each time The picture moves a step forward or the button is pressed. The speed steps reverse each time the button is pressed.
  • Page 51: Playing In The Desired Order (Programmed Play)

    Playback Making bookmarks To cancel Repeat Play Press REPEAT several times during You can make bookmarks on the video Repeat Play. currently playing and play back the scene later. Note During playback, press BOOKMARK. The bookmark is made. Repeat Play is canceled in the following cases: –...
  • Page 52: Playing Photos As Slideshows

    Playback Playing photos as slideshows Switching the subtitles This function plays the photos, switching them For discs or files on which multiple subtitles automatically. are recorded, the subtitles can be switched during playback. During playback, press INDEX. Display the thumbnail of image files. The Caution maximum number is 12 at once.
  • Page 53: Switching The Audio

    Playback Switching the audio Displaying the disc information For discs or files on which multiple audio streams/channels are recorded, audio streams/ Press DISPLAY. channels can be switched during playback. The disc information appears on the TV screen. During playback, press AUDIO. To switch off the information display, press The current audio and total number of DISPLAY again.
  • Page 54: Enjoying Bonusview Or Bd-Live

    Playback Enjoying BONUSVIEW or Note BD-LIVE Operation of USB flash drives is not guaranteed. Playback of BD-LIVE function data differs This player is compatible with BD-Video depending on the disc used. For details, consult the user instructions supplied with the disc. To enjoy the BD-LIVE function, a network connection and settings are required (pages 47 and 80).
  • Page 55: Playback Functions

    Playback Playback functions The functions that can be used differ according to the type of disc and file. In some cases, some of the functions cannot be used. Check the usable functions on the table below. Disc/file type DVD-R Function BD-R DVD- /-RW...
  • Page 56: Using The Tools Menu

    Playback Using the TOOLS menu Item Description Ins Search Skip forward 30 seconds. Various functions can be called out according Ins Replay Skip backward 10 seconds. to the player's operating status. Slide Show Switch the playback speed while playing the picture slide show. 1.
  • Page 57: Playing A Specific Title, Chapter, Track Or File (Search)

    Playback Playing a specific title, chapter, Continuing playback from a track or file (Search) specified position (Continued Viewing Playback) 1. Select Title or Chapter (track/file). Use / to select, then press ENTER. This function allows you to continue playback from a position you specify to be played next 2.
  • Page 58: Playback From Home Media Gallery

    Playback from Home Media Gallery Chapter 5 The following files are allowed to be played from Home Media Gallery: Playback from Home – Media Gallery – – DLNA-compatible digital media servers (on PCs About Home Media or other components) Files stored in a PC or DMS (Digital Media Server) Gallery as described above can be played by Digital Media Player (DMP).
  • Page 59 Use or distribution of such technology outside suspended, interrupted, or discontinued at any of this product is prohibited without a license time without notice, and Pioneer disclaims any from Microsoft. liability in connection with such occurrences. Pioneer does not represent or warrant that...
  • Page 60: Dlna Search

    Playback from Home Media Gallery DLNA Search Disc/USB playback Playing back the files stored on the 1. Press HOME MEDIA GALLERY to components connected to the player via display the Home Media Gallery. network. The Home Media Gallery can also be displayed by selecting Home Media Gallery 1.
  • Page 61: Playing In The Desired Order (Playlist)

    Playback from Home Media Gallery Playing in the desired Playing the playlist order (Playlist) 1. Press HOME MEDIA GALLERY to display the Home Media Gallery. The discs that can add tracks and files to the The Home Media Gallery can also be Playlist are as shown below.
  • Page 62: Playing The Web Contents

    Third party content services may be changed, suspended, interrupted, or discontinued at any time without notice, and Pioneer disclaims any liability in connection with such occurrences. Pioneer does not represent or warrant that content...
  • Page 63: Other Operating

    Other Operating Chapter 7 7. Start recording. Use / / / to select [Start] and press Other Operating ENTER to start recording. 8. Exit CD recording display. Use / / / to select [Cancel] then press Recording Audio CD to a ENTER after recording has finished.
  • Page 64: Ipod/Iphone Playback

    Other Operating iPod/iPhone playback Note Pioneer does not guarantee that this unit plays Merely by connecting your iPod/iPhone to iPod/iPhone models other than the ones specified. this unit, you can enjoy high-quality sound Some functions may be restricted depending on from your iPod/iPhone.
  • Page 65: Playing Your Ipod/Iphone

    Other Operating Important Playing your iPod/iPhone If this unit cannot play your iPod/iPhone, Caution perform the following troubleshooting checks: and you wish to operate the iPod/iPhone directly, – Check whether the iPod/iPhone is be sure to hold the iPod/iPhone steady with the supported by this unit.
  • Page 66: Radio Operations

    Other Operating Radio Operations Improving poor FM reception Press AUDIO on the remote control. This will Be sure that FM aerial is connected. (Refer to change the tuner from stereo to mono and the page 44) usually improve the reception. Listening to the radio Seeing information about a 1.
  • Page 67: Bluetooth® Adapter For Wireless Enjoyment Of Music

    Pin code: 0000 This unit cannot be set with any PIN code Note other than 0000. Pioneer does not guarantee proper connection and 4. When the unit and a Bluetooth operation of this unit with all Bluetooth wireless technology enabled devices.
  • Page 68: Karaoke

    Other Operating Karaoke Note This unit does not support AVRCP . 1. Press KARAOKE on the remote control. This unit does not support Mono Headset Profile Karaoke Setup under Initial Setup will be (Hands Free Profile). displayed on the TV screen. A Bluetooth wireless technology enabled device cannot be operated by this unit.
  • Page 69: Sound

    Other Operating Sound Press SOUND on the remote control to display the sound select menu on the TV screen. Use cursor button to make a selection, then press ENTER. Setting Options Explanation Sound Retriever valid for files with the extension “.wma” or “.mp3”. The effect depends on the file.
  • Page 70: Advanced Settings

    Advanced settings Chapter 8 Operating the initial setup Advanced settings screen 1. When playback is stopped, display the Home Menu screen. Changing the settings Press HOME MENU. 2. Select and set Initial Setup. Use / to select, then press ENTER. 3.
  • Page 71 Advanced settings Setting Options Explanation DRC (Dynamic Range Select this to output audio signals without using the DRC function. Control) Select this to adjust the range between the loudest and softest sounds (dynamic range) for playback at average volume. Use this when it is hard to hear dialog or when watching movies at midnight.
  • Page 72 Advanced settings Setting Options Explanation IP Setting Select this to set the IP address of the player and DNS server (page 80). Proxy Server Only set the proxy server if so instructed by your Internet service provider (page 81). Information Displays the values of the MAC address, IP address, subnet mask, default gateway, DNS server (primary) and DNS server (secondary).
  • Page 73 Advanced settings Setting Options Explanation Change Password Register (change) the password for parental lock settings or for unlocking to play DVD-Videos with the parental lock feature (page 82). Parental Control Change the player's parental lock level (page 82). Country Code Change the Country/Area code (page 82).
  • Page 74 Advanced settings Adjusting the video Setting the IP address 1. Select and set Display Setting Video 1. Select and set Network IP Setting Adjust Next Screen. Next Screen. Use / to select, then press ENTER. Use / to select, then press ENTER. 2.
  • Page 75 Advanced settings Setting the proxy server Testing the network connection Only set the proxy server if so instructed by Select and set Network Connection your Internet service provider. Test Start. Use / to select, then press ENTER. 1. Select and set Network Proxy Server Next Screen.
  • Page 76 Advanced settings Registering or Changing the password Changing the Parental Lock level for viewing DVDs/BD-ROMs Use this procedure to register or change the code number required for the Parental Some DVD-Video discs containing scenes Lock settings. of violence, for example, have Parental Lock About default password of this unit levels (check the indications on the disc's jacket or elsewhere).
  • Page 77: Software Updating

    Internet). Product information on this player is provided Steps 6 to 8 are the operations performed on the Pioneer website. Check the website (automatically) by the player (they are intended to update the software). shown on page 10 for update and service information on your Blu-ray disc player.
  • Page 78: Restoring All The Settings To The Factory Default Settings

    USB flash drive or disc. Carefully read 2. When playback is stopped, display the the instructions on downloading update files Home Menu screen. provided on the Pioneer website. Press HOME MENU. Store the update file in the root directory of the USB flash drive or disc.
  • Page 79: Language Code Table And Country/Area Code Table

    Advanced settings Language code table and country/area code table Language code table Language name, language code, input code Abkhazian, ab/abk, 0102 French, fr/fra, 0618 Malagasy, mg/mlg, 1307 Slovenian, sl/slv, 1912 Afar, aa/aar, 0101 Galician, gl/glg, 0712 Malay, ms/msa, 1319 Somali, so/som, 1915 Afrikaans, af/afr, 0106 Georgian, ka/kat, 1101 Malayalam, ml/mal, 1312...
  • Page 80: Troubleshooting

    Sometimes the trouble may lie in another component. Inspect the other components and electrical appliances being used. If the trouble cannot be rectified even after checking the points below, ask your nearest Pioneer authorized service center or your dealer to carry out repair work.
  • Page 81: Sound

    Troubleshooting Sound Problem Check Remedy No sound is output. Is the disc played back in No sound is output during slow motion play and forward and reverse slow motion? scanning. Sound is not output properly. Is the disc played back in fast forward or fast reverse? Are the cables properly Connect the cable properly according to the connected devices...
  • Page 82: Control Function

    Control function are connected between the Control-compatible device and the player. See page 16. Even when connected to a Pioneer product compatible with the Control function, some of the functions may not work. Also refer to the operating instructions for the connected device.
  • Page 83: Others

    Troubleshooting Others Problem Check Remedy Power does not Is the power cord properly Plug the power cord securely into the power outlet. turned on. connected? Unplug the power cord, wait several seconds, then plug the power cord back in. Power turns OFF without Auto Power Off is set.
  • Page 84: Appendix

    Appendix Chapter 10 Appendix Specifications General for HTZ-BD52/HTZ-BD32 Power requirements AC 120 V, 50 Hz/60 Hz Power consumption 190 W (In Standby mode: Less than 0.5 W) Dimensions (W x H x D) Approx. 430 mm x 345 mm x 63 mm Net Weight (Approx.)
  • Page 85 Appendix Amplifier for HTZ-BD52/HTZ-BD32 Total 1100 W Front Center Sub-Woofer Amplifier for HTZ-BD92HW/HTZ-BD82HF Total 550 W Front Sub-Woofer System Laser Semiconductor laser Signal system Standard PAL/NTSC colour TV system LAN port Integrated IEEE 802.11n (2.4 GHz band) wireless networking Wireless LAN (internal antenna) access, compatible with 802.11b/g Wi-Fi networks.
  • Page 86 Appendix Speakers for HTZ-BD32 S-BD122 Net Dimensions Type 1 Way 95 mm x 80 mm x 90 mm (W x H x D) Net Weight 0.3 kg Center speaker Net Dimensions Type 1 Way 230 mm x 80 mm x 90 mm (W x H x D) Net Weight 0.7 kg...
  • Page 87: Maintenance

    Appendix Maintenance Notes on discs Handling discs Handling the unit Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints When shipping the unit do not get on the surface. Never stick paper or Please save the original shipping carton and tape on the disc.
  • Page 88: Important Information Relating To Network Services

    Content or Services should be made directly to the respective Content and Service Providers. Please note that PIONEER is not responsible for any Content or Services provided by the Service Provider or any changes to, removal of,...
