Edision mini-triton 2 User Manual

User's Manual
mini-triton 2
GENERAL INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. Please read the following list of instructions. All safety and operating instructions
should be read and followed, before operating this product.
2. Keep these instructions - The safety and operating instructions should be retained for
future reference
3. Please pay attention to warning notices! All warning notices on the appliance should
be applied and followed at all times.
4. Follow all instructions - All operating and use instructions should be followed.
5. Do not use this appliance near water. The appliance should be kept away from water
and moisture environment eg. wet basement, near swimming pool, etc.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture's
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
9. If the provided AC plug cord does not fit in the existing outlet on the wall, please DO
NOT plug in the device and consult a qualified electrician.
10. Please protect the AC power cord from being stepped on, pierced, stressed or cut and
bent. This applies to it's full length, from the point it exits the device to it's end tip.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus
has been damaged in any way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
15. CAUTION: The servicing instructions are for use by qualified personnel only. To re-
duce the risk of electric shock, DO NOT perform any procedure other than the ones
stated in the operating instructions.
16. Please ensure sufficient ventilation of the device and do not cover the ventilation
openings with anything.
17. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture. The apparatus should not be exposed to dripping or splashing water
and any objects filled with liquids, such as vases, should not be placed on apparatus.
3
GENERAL INFORMATION
Main Features
• Automatic PAL/NTSC conversion
• At least 400 programmable TV and Radio channels
• Selection of different favourite groups
• Multi-language On Screen Display
• Fully supports up to 7-day Electronic Program
• Supports Picture in Graphics(PIG) Guide(EPG)
• 256-colour On Screen Display
• Automatic and Manual channel search
• Various channel editing functions(favorite, move, lock, rename and sort)
• Parental control for channels
• User friendly Automatic and Manual Menu System GMT Time setting
• Summer Time Zone support
• Subtitle support DVB EN300743 and EBU
• Teletext support DVB ETS300472 by VBI and OSD
• Memory of most recently selected channel
• Supports Logic Channel Number(LCN)
• Supports FAT16/FAT32/FAT12,NTFS(Option)
• Supports MP3/JPEG/BMP/AVI file format
• Info for Lock/Delete/Rename,Preview playback and Browse record functions
• Play/Pause/Stop functions
1
GENERAL INFORMATION
18. WARNING: Terminals marked with the symbol can cause electric shock. All wiring
regarding these terminals should be carried out by qualified technician, using only the
leads and cords supplied with the product.
19. CAUTION: Danger of explosion if battery is not properly replaced. Replace only with
the same or equivalent type, with respect to polarity.
20. WARNING: The power pack (battery, batteries or battery pack) shall not be exposed
to excessive heat such as sunshine, fire, heat sources etc.
21. WARNING: The mains plug is used only to disconnect the device from the AC power
line.
22. This device is a Class II (double insulated electrically) device. It has been de-
signed in such a way that it does not require a safety connection to electrical ground.
23. - The above symbols strongly indicate the risk of electric shock, due to presence of
non-insulated dangerous voltage inside the enclosure of the device.
- WARNING: DO NOT remove cover to avoid risk of electric shock. No user-servicea-
ble parts inside. Refer to qualified personnel only. Please read operating instructions
that are included in the product package box.
24. Please dispose of this product properly and not with other household waste. To
prevent possible harm to the environment or human health from uncontrolled waste
disposal, please recycle it responsibly to promote sustainability of resources. Please
contact local authorities, regarding recycling details.
25. Environmental working temperature: 0~35 C
4
GENERAL INFORMATION
For Your Safety
• To avoid electric-shock hazard, DO NOT open • Keep the receiver away from flower vases, tubs,
the cabinet, refer only to qualified personnel sinks and any source of water and moisture in
for repair and servicing. order to avoid damaging the equipment.
• Do not expose the receiver under direct • Do not block ventilation holes of the Receiver so
sunlight. Keep it away from any heat that air can circulate freely.
source.
• When any abnormal function occurs, please • Do not touch the receiver during thunder, since that
remove AC cord plug from mains socket might create electric-shock hazards.
immediately.
• Switch the receiver off when it remains out of • Before cleaning the receiver please proceed as
use for an extended period of time. following: Turn off the receiver, disconnect the AC
power cord from mains socket, wipe clean with a
soft, damp cloth and finally wipe completely dry
with a dry cloth.
2
GENERAL INFORMATION
Unpacking (Optional)
• Remote Control • Batteries
Rear Panel (Optional)
CONNECT TO TV
USING A SCART CABLE
CONNECT TO A DIGITAL AMPLIFIER
RF OUT: CONNECT TO TV ANT INPUT
CONNECT TO USB DEVICE
ANT IN: CONNECT TO ANTENNA
LOOP: CONNECT TO ANOTHER RECEIVER
• The above diagram is only for reference, please make sure it applies to your device.
5
