Edision proton T265 Manual

Congratulations on purchasing an EDISION proton T265
Please note that this information is valid at the time of publication.
Current information and detailed user manuals can be found on the Internet at: www.edision.gr
1
Unpacking
115mm
Receiver proton T265
Notes: The front is factory fitted with a protective foil which can be removed easily
and with caution. (Protective foil only for devices with display)
The scope of delivery may also include parts not listed here
Front Panel
1
/USB: Connection for USB storage devices
2 Infrared sensor for the reception of remote
control commands.
Back Panel
3 ANT IN: Input for connecting the signal from the antenna
4 HDMI: Connection to an HDTV quality TV
5 IR IN: Infrared connection port
6 AV OUT: For broadcasting video and sound signals
7 Connection for an adapter (DC 5V / 1,0A)
2
Connecting and switching on
Note: For trouble-free signal reception your antenna
and cable installation should be calibrated
and inspected by a qualified professional with a digital
TV-level-measuring instrument.
• Connect the receiver's HDMI-output
to the HDMI-input of your television set (TV).
• Then connect the coaxial cable from the terrestrial antenna
to the ANT IN input of the receiver.
• Insert the batteries into the remote.
Further information you will find at the back of this instruction manual.
• Connect the receiver to the mains power supply network, by means of it's power supply unit
included in the package.
• The receiver starts with the BOOT-process and will be ready for you to enjoy in a few minutes.
proton T265
FullHD DVB-T2/C Terrestrial & Cable Receiver (H.265)
