Polivac GAZ20 Instruction Manual

Hide thumbs Also See for GAZ20:

Advertisement

Quick Links

Download this manual
GAZ20 / GAZ24
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the GAZ20 and is the answer not in the manual?

Questions and answers

Related Manuals for Polivac GAZ20

Summary of Contents for Polivac GAZ20

  • Page 1 GAZ20 / GAZ24 INSTRUCTION MANUAL...
  • Page 2 MODELS  e.

  • Page 3: Unpacking The Machine

    UNPACKING THE MACHINE  appropriate. 1. Remove from pallet 2. Undo handle bolts and return to operating position. 3. Reconnect bolts when handle is in position 4. Re-attach dust bag to handle.
  • Page 4 SAFETY Important notice For safety reasons it is important you read this safety awareness manual prior to operating your LPG power product. L.P.G Safety Awareness Manual This Safety/Training Manual has been developed to encourage safe working habits of those Using engine powered equipment fuelled by Liquefied Propane Gas (LPG). Please be reminded, this manual is not designed to instruct you on how to maintain floors, But is designed to instruct you on how to avoid incidents that could be brought on by unsafe Actions, poor maintenance and the lack of accurate knowledge.

  • Page 5: Ready To Use

    READY TO USE  Place the gas bottle into the holder on the machine with the outlet facing forward.  Tighten the handle to hold the bottle in place.  Connect the machine hose to the gas bottle.  To release the gas turn the knob on the gas bottle. ...
  • Page 6 READY TO USE  In certain enviroments,you may need to prime the gas regulator, this is done by pressing the primer button on the outside of the regulator.  To start press the start button located the battery with you foot, hold until engine start running, then release.

  • Page 7: How To Use

    • Prepare your safety equipment. • Plan the work Path. Clear obstacles from in you path . • The gaz20/gaz24 burnishers work in a straight line , just walk slowly forward then complete a u-turn walk back overlapping the previous pass sufficiently , to give a uniform finish.

  • Page 8: Battery Maintenance

    BATTERY MAINTENANCE If you plan to leave the machine unused for a considerable period of time, disconnect the earth terminal on the battery to prevent battery discharge.

  • Page 9: Warranty

     In the case of proprietary components used by the manufacturer in his product, such as engines, electrical motors, chargers and the like Polivac will pass on any warranty given by the manufacture of these items.
  • Page 10 20G GAS Burnisher Main Body Assembly...
  • Page 11 20G GAS Burnisher Main Body Assembly Vacuum Box...
  • Page 12 20G GAS Burnisher Gas Bottle Holder 27 26 35 49...
  • Page 13 20G GAS Burnisher Dust Bag Gas Regulator Assembly...
  • Page 14 20G GAS Burnisher Main Body & Gas Bottle Holder - Part List -Page 1 of 3 Item Description Part No. Number Main Body GS6010 Gas Bottle Bracket Assembly GS6013 Handle GS6014/GS5012 Plastic Skirt GS6004 Pad Trimmer GS6020 Gas Bottle Bracket Brases GS6021 M16 Gas Bottle Lock Cam GZ001/5156...
  • Page 15 20G GAS Burnisher Main Body & Gas Bottle Holder - Part List -Page 2 of 3 Item Description Part No. Number Throttle Lever Washer GZ001/5141 Nylon Washer M6x32 GZ006/2104 M6x25 Coach Bolt GZ006/1929 M5x20 Pan Head GZ006/1618 M5 Nyloc GZ006/1704 M6 Nyloc AAA354 M6x12 Flat Washer...
  • Page 16 20G GAS Burnisher Main Body & Gas Bottle Holder - Part List -Page 3 of 3 Item Description Part No. Number 3/8" BSPTM x 3/8" Y Brass GSS047 Elbow 3/8" BSPTM x 3/8" Hose Tail GAS035 Filter Lock GGS022 Gas Bottle Hose 24.5 x 1/4" GS6016 Elbow 1/8"...
  • Page 17 20G GAS Burnisher Belt Tensioner...
  • Page 18 20G GAS Burnisher Belt Tensioner Item Description Part No. Number Belt Tensioner Large GGS016 M10x40 Hex Bolt GZ006/2536 Bearing 6203 2 RS VPA570 M12x25 Flat Washer GZ006/2992 M10 Spring Washer GZ006/2721 M12x50 Hex Bolt GZ006/3001 Bearing Sleeve GSS032 M10x25 Flat Washer VIB507 M12 Spring Washer GZ006/2372...
  • Page 19 20G GAS Burnisher Engine Sub-Assembly Parts 12 19...
  • Page 20 20G GAS Burnisher Engine Sub-Assembly Parts Item Description Part No. Number Cowl Angle Bracket GSS031BSB Screen Metal Basket GSS031BS Engine Dust Filter GSS028BS M5x20 Pan Head GZ006/1618 Rivet AS 6-4 AAK 829 Drain Plug 20mm x 1.5 GSS066 Valve Drain GSS068 Oil Drain Hose PPR039A...
  • Page 21 20G GAS Burnisher Vacuum Fan Plastic Assembly...
  • Page 22 20G GAS Burnisher Vacuum Fan Plastic Assembly Item Number Description Part Number Aluminium Vac Fan GSS004 Motor Pulley 127mm GSS019 1/4 x 2 1/4 Key Steel GSS103 Engine Retainer Washer GZ010/5128 7/16 UNF x 1 1/2 Hex Bolt GZ006/0720...
  • Page 23 20G GAS Burnisher Pad Holder Pulley Assembly...
  • Page 24 20G GAS Burnisher Pad Holder Pulley Assembly Part List Item Description Part No. Number Pulley Pad Holder 7" Alum GSS212 Bearing 6205 GSS035 Circlip GSS036 Pad 50cm P50 Jackaro M20x45x3.5 ZP Flat Washer AAG480 M20 Spring Washer GZ006/3562 5/16 x 1" SHCS AAA628 M20x50 ZP Hex GS6109...
  • Page 25 20G GAS Burnisher Pulley Bracket Assembly...
  • Page 26 20G GAS Burnisher Pulley Bracket Assembly Item Number Description Part No. Brush Pulley Bracket GS6019 Angle High GS5017 Angle Low GS5018 Bearing 6200 2RS SLB016 M10x20 Flat Washer GZ006/2715 M10x32 Flat Washer BAT270 M10x30 Hex Bolt GZ006/2646 M10 Nut GZ006/2711 Polyurethane Buffer GZ001/5115 Rivet AS 6-4...

This manual is also suitable for:

Gaz24
