Summary of Contents for KOBE RA0230SQB-DC-5
- Page 1 KOBE Range Hoods Deluxe Series RA02 Series Model No. RA0230SQB-DC-5 / RA0230SQB-DC24-5 / RA0230SQB-DC48-5 (30”) RA0236SQB-DC-5 / RA0236SQB-DC24-5 / RA0236SQB-DC48-5 (36”) RA0242SQB-DC-5 / RA0242SQB-DC24-5 / RA0242SQB-DC48-5 (42”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 IMPORTANT READ THIS FIRST READ BEFORE INSTALLATION 1. Carefully check all contents of packages. 2. Thoroughly inspect the unit for any shipping damages, cosmetic damages or defects. 3. Have a certified contractor/electrician test the unit before installation. IF THERE IS ANY PROBLEM: 1.
-
Page 3: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION ........................... 4 OPERATION INSTRUCTIONS....................8 MAINTENANCE .......................... 9 SPECIFICATIONS ........................10 MEASUREMENTS & DIAGRAMS ..................... 12 PARTS LIST ..........................12 CIRCUIT DIAGRAM ........................16 TROUBLE SHOOTING ...................... -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
Duct Cover Mounting Bracket Screws Package M4 x 1-1/2” (2) Outer Duct Extension RA02DC-24 (Included in RA02 SQB-DC48-5 Only) Outer Duct Extension (Model No. RA02DC-24) FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.koberangehoods.com CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation Calculate the length of the installation, before installing the hood. (All calculation is measure in inches.) - FOR STAND ALONE - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood... - Page 8 Preparation before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. Decide the location of the venting pipe from the hood to the outside. (Figure 1) A straight, short venting run will allow the hood to perform more efficiently.
- Page 9 Hood Installation Figure 4 CAUTION: If required to move the cooking range to install the hood, turn off the power on an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE. 1. Using references in Table 1 and measurements on Page 12, mark the leveling locations point for hood-mounting bracket on the wall.
- Page 10 Duct Cover Installation Figure 7 6. Use 6” round steel pipe for 30” and 36” models or 8” round steel pipe for 42” model (follow building codes in your area) to connect the exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight.
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS This KOBE hood is equipped with two rotary controls with powerful centrifugal squirrel cage, baffle filters, and bright LED lights. The two rotary controls are Light Control & Speed Control. Refer to Figure 9. Figure 9 Note: For best results, turn hood to QuietMode™ prior to preparation or cooking to establish airflow in the kitchen. -
Page 12: Maintenance
MAINTENANCE For the optimal level of operation, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 13: Specifications
SPECIFICATIONS MODEL / SIZE RA0230SQB-DC-5 / 30” / Single Blower RA0236SQB-DC-5 / 36” / Single Blower RA0242SQB-DC-5 / 42” / Dual Blowers RA0230SQB-DC24-5 / 30” / Single Blower RA0236SQB-DC24-5 / 36” / Single Blower RA0242SQB-DC24-5 / 42” / Dual Blowers RA0230SQB-DC48-5 / 30”... - Page 14 1) 30” Stainless Steel Back Panel (W x D x H) Model No.: SSP30 (30” x 32”) 2) 36” Stainless Steel Back Panel Model No.: SSP36 (36” x 32”) Gross HOOD WEIGHT (lbs) RA0230SQB-DC-5 RA0236SQB-DC-5 RA0242SQB-DC-5 RA02DC-1 SPEED QuietMode™ High...
-
Page 15: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS *** All inch measurements are converted from millimeters. Inch measurements are estimated. *** All measurements in ( ) are millimeters. MODEL NO.: RA0230SQB-DC-5 (30”) RA0236SQB-DC-5 (36”) RA0242SQB-DC-5 (42”) Inner Duct Extension Model No.: RA02DC-24-1 Baffle Filter for RA02 SQB-5 Series *Included in RA02 SQB-DC24-5 and SQB-DC48-5 Series Outer Duct Extension Model No.: RA02DC-24... - Page 16 MODEL NO.: RA0230SQB-DC-5 / RA0230SQB-DC24-5 / RA0230SQB-DC48-5 (30”) RA0236SQB-DC-5 / RA0236SQB-DC24-5 / RA0236SQB-DC48-5 (36”) RA0242SQB-DC-5 / RA0242SQB-DC24-5 / RA0242SQB-DC48-5 (42”) DESCRIPTION MODEL /SIZE PART NO. RA0230SQB-DC-5 6” Round Plastic Exhaust L1-0505-0003 RA0236SQB-DC-5 8” Round Exhaust Plate RA0242SQB-DC-5 L1-0505-0004 Duct Cover...
- Page 17 Model No.: RA0230SQB-5 / RA0230SQB-DC24-5 / RA0230SQB-DC48-5 (30”) RA0236SQB-5 / RA0236SQB-DC24-5 / RA0236SQB-DC48-5 (36”)
- Page 18 Model No.: RA0242SQB-5 / RA0242SQB-DC24-5 / RA0242SQB-DC48-5 (42”)
-
Page 19: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: RA0230SQB-DC-5 / RA0230SQB-DC24-5 / RA0230SQB-DC48-5 (30”) RA0236SQB-DC-5 / RA0236SQB-DC24-5 / RA0236SQB-DC48-5 (36”) MODEL NO.: RA0242SQB-DC-5 / RA0242SQB-DC24-5 / RA0242SQB-DC48-5 (42”) -
Page 20: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After The power is not on. Make sure the circuit breaker and the Installation, unit’s power is ON. Use a voltage meter both motors to check the power supply. and lights are The wire connection is not secure. Check and tighten wire connection. not working. -
Page 21: Warranty
ONE-YEAR LIMITED LABOR WARRANTY ON KOBE DELUXE SERIES: For one year from the date of your original invoice from a KOBE authorized dealer, we will repair any parts or components free of charge that failed due to manufacturing defects. KOBE reserves the right to replace, rather than repair the product free of charge at our sole discretion. - Page 22 THIS WARRANTY WILL BE VOIDED WHEN: 1. Improper installation and failure to follow installation instructions. 2. Any repair, alteration, modification not authorized by KOBE. 3. Duct alteration, modification and connection. 4. Incorrect electric current, voltage or wiring. 5. Improper usage of the product such as commercially, outdoor or other usage other than its intended purpose which is residential indoor usage only.
-
Page 23: Product Registration
For warranty service or spare parts purchase in US, contact: KOBE Service Center Email (best): customer.service@koberangehoods.com Phone: 1-626-775-8880 ext. 103 Toll Free: 1-877-BUY-KOBE (289-5623) For Warranty service or spare parts purchase in Canada, contact: Email (best): customer.service@koberangehoods.com Toll Free: 1-626-775-8880 ext. 103... - Page 24 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
